IL/ILC
Instruction
INTERLOCK
INTERLOCK CLEAR
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Flags
Name
Error Flag
Equals Flag
Negative Flag
*1 In CJ2, CS1-H, CJ1-H, CJ1M, and CS1D (for Single-CPU System) CPU Units, the Equals and Negative Flags are left unchanged.
In CS1D CPU Units for Duplex Systems, CS1 CPU Units, and CJ1 CPU Units, these are turned OFF.
Function
When the execution condition for IL(002) is OFF, the outputs for all instructions between IL(002) and
ILC(003) are interlocked. When the execution condition for IL(002) is ON, the instructions between
IL(002) and ILC(003) are executed normally.
The following table shows the treatment of various outputs in an interlocked section between IL(002)
and ILC(003).
Bits specified in OUT, OUT NOT, or OUTB(534)
TIM, TIMX(550), TIMH(015), TIMHX(551), TMHH(540),
TMHHX(552), TIML(542), and TIMXL(553)
TIMU(541), TIMUX(556), TMUH(544), and TMUHX(557)
Bits/words specified in all other instructions (See note.)
Note Bits and words in all other instructions including TTIM(087), TTIMX(555), MTIM(543), MTIMX(554), SET,
RSET, CNT, CNTX(546), CNTR(012), CNTRX(548), SFT, and KEEP(011) retain their previous status.
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Mnemonic Variations
IL ---
ILC ---
IL
IL(002)
Block program areas Step program areas
Not allowed Not allowed
Label
ER *1
Unchanged
= *1
Unchanged
N *1
Unchanged
Instruction
Execution
condition ON
Execution
condition
Interlocked section
of the program
Function
code
Interlocks all outputs between IL(002) and
002 ILC(003) when the execution condition for IL(002)
is OFF.
003 Indicates the end of the interlock range.
Subroutines
OK
Operation
Completion Flag
PV
Cannot be referenced.
Execution
condition OFF
Normal Outputs
execution interlocked.
3. Instructions
Function
ILC
ILC(003)
SFC action or
Interrupt tasks
transition programs
OK OK
Treatment
OFF
OFF (reset)
Time set value (reset)
Retain previous status.
3
179
