C: Control Data
C
0000 hex Starts comparison.
0001 hex Stops comparison.
0002 hex Changes the PV.
0003 hex Stops pulse output.
NV: First Word with New PV
If C is 0002 hex (i.e., when changing a PV),
NV and NV+1 contain the new PV. Any
values in NV and NV+1 are ignored when C
is not 0002 hex.
Operand Specifications
Word addresses
Area
CIO WR HR
P, C --- --- ---
NV OK OK OK
Flags
Name Label
Error Flag ER
Function
INI(880) performs the operation specified in C for the port specified in P. The possible combinations of
operations and ports are shown in the following table.
P: Port specifier
0000 or 0001 hex: Pulse output
0010 or 0011 hex: High-speed counter input
0100, 0101, 0102, or 0103 hex:
Interrupt input in counter mode
1000 or 1001 hex: PWM (891) output
Starting Comparison (C = 0000 hex)
If C is 0000 hex, INI(880) starts comparison of a high-speed counter's PV to the comparison table
registered with CTBL(882).
Note A target value comparison table must be registered in advance with CTBL(882). If INI(880) is executed with-
out registering a table, the Error Flag will turn ON.
Stopping Comparison (C = 0001 hex)
If C is 0001 hex, INI(880) stops comparison of a high-speed counter's PV to the comparison table
registered with CTBL(882).
CS/CJ/NSJ Series Instructions Reference Manual (W474)
AR T C DM EM
--- --- --- ---
---
OK OK OK OK
• ON if the specified range for P, C, or NV is exceeded.
• ON if the combination of P and C is not allowed.
• ON if a comparison table has not been registered but starting comparison is specified.
• ON if a new PV is specified for a port that is currently outputting pulses.
• ON if changing the PV of a high-speed counter is specified for a port that is not specified for a high-speed counter.
• ON if a value that is out of range is specified as the PV for an interrupt input in counter mode.
• ON if INI(880) is executed in an interrupt task for a high-speed counter and an interrupt occurs when CTBL(882) is
executed.
• ON if executed for a port not set for an interrupt input in counter mode.
• OFF in all other cases.
INI(880) function
15
Lower word of new PV
NV
Upper word of new PV
NV+1
For Pulse Output or High-speed Counter Input:
0000 0000 to FFFF FFFF hex
For Interrupt Input in Counter Mode:
0000 0000 to 0000 FFFF hex
Indirect DM/EM
addresses
Con-
stants
@DM *DM
DR
@EM *EM
--- --- OK
---
OK OK ---
Operation
C: Control data
0000 hex: Start 0001 hex: Stop
comparison comparison
Not allowed. Not allowed.
OK OK
Not allowed. Not allowed.
Not allowed. Not allowed.
3. Instructions
0
Registers Flags
Pulse
bits
Indirect
IR TK CF
using IR
---
--- --- ---
OK
0002 hex: 0003 hex: Stop
Change PV pulse output
OK
OK Not allowed.
OK Not allowed.
Not allowed.
3
TR
bits
--- ---
OK
OK
