3. Instructions
SCL3
Instruction
SCALING 3
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
S Source word
P1 First parameter word
R Result word
P1: First Parameter Word
15
P1
Offset of linear function
8000 to 7FFF (signed binary)
15
P1+1
0001 to 9999 (BCD)
15
P1+2
8000 to 7FFF (signed binary)
15
P1+3
Maximum conversion
8000 to 7FFF (signed binary)
15
P1+4
Minimum conversion
8000 to 7FFF (signed binary)
672
Mnemonic Variations
SCL3 @SCL3
Block program areas Step program areas
OK OK
Description
0
0
X
0
Y
0
0
Function
code
Converts signed BCD data into signed binary data
487 according to the specified linear function. An offset
can be input in defining the linear function.
SCL3
SCL3(487)
S: Source word
S
P1: First parameter word
P1
R R: Result word
Subroutines Interrupt tasks
OK
Data type
WORD
WORD
INT
Note P1 to P1+4 must be in the same area.
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Function
SFC action or
transition programs
OK OK
Size
1
5
