3. Instructions
Differences between Interlocks and Jumps
The following table shows the differences between interlocks (created with IL(002)/ILC(003),
MILH(517)/MILC(519), or MILR(518)/MILC(519)) and jumps created with JMP(004)/JME(005).
Item
Instruction execution
Output status in instructions
Bits in OUT, OUT NOT,
OUTB(534)
Status of timer instructions
(except (TTIM(087),
TTIMX(555), MTIM(543), and
MTIMX(554))
176
Treatment in IL(002)/ILC(003),
MILH(517)/MILC(519), or
MILR(518)/MILC(519))
Except OUT, OUT NOT, OUTB(534), and
timer instructions, all instructions are not
executed.
Except for outputs in OUT, OUT NOT,
OUTB(534), and timer instructions, all out-
puts retain their previous status.
OFF
Reset
Treatment in
JMP(004)/JME(005)
No instructions are executed.
All outputs retain their previous status.
All outputs retain their previous status.
Operating timers (TIM, TIMX(550),
TIMH(015), TIMHX(551), TMHH(540),
TMHHX(552), TIMU(541), TIMUX(556),
TMUH(544), TMUHX(557) only) continue
timing because the PVs are updated even
when the timer instruction is not being exe-
cuted.
