PLC Setup Settings
Programming Console address
Word Bit
162 0 to 15
8 to 15
164
0 to 7
12
165 8 and 9
0 to 7
DM Setup Area Settings for Serial Communication Board's Ports
Setup Area word
Port 1 Port 2
D32002 D32012
D32004 D32014
D32005 D32015
Function
• TXD(236) reads N bytes of data from words S to S+(N 2)-1 and outputs the raw data in no-protocol
mode from the CPU Unit's built-in RS-232C port or one of the Serial Communications Board's serial
ports. (The output port is specified with bits 8 to 11 of C.)
The start and end codes specified for no-protocol mode are added to the data before the data is
output. The start and end codes are specified in the PLC Setup (for the CPU Unit's RS-232C port) or
the allocated DM Setup Area (for the Serial Communications Board's ports).
• The following send-message frame format can be set in the PLC Setup (for the CPU Unit's RS-232C
port) or the allocated DM Setup Area (for the Serial Communications Board's ports).
1) Start code: None or 00 to FF hex.
2) End code: None, CR+LF, or 00 to FF hex.
The data will be sent with any start and/or end codes specified in the PLC Setup or the allocated DM
Setup Area. If start and end codes are specified, the codes will be added to the send data (N). In this
case, the maximum number of bytes that can be specified for N is 256 bytes.
• Data is sent in the order specified in C.
• If RS signal control is specified in C, bit 15 of S will be used as the RS signal.
• If ER signal control is specified in C, bit 15 of S will be used as the ER signal.
If RS and ER signal control is specified in C, bit 15 of S will be used as the RS signal and bit 14 of S
will be used as the ER signal.
If 1, 2, or 3 hex is specified for RS and ER signal control in C, TXD(236) will be executed regardless
of the status of the Send Ready Flag (A392.05, A356.05, or A356.13 depending on the port being
used).
• Up to 259 bytes can be sent, including the send data (N = 256 bytes max.), the start code, and the
end code.
• Specify the size of the send data, not including the start code and end code, in N.
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Name
No-protocol Mode Send Delay
No-protocol Mode Start Code
No-protocol Mode End Code
No-protocol Mode Start Code Specifier
No-protocol Mode End Code Specifier
No-protocol Mode Number of Bytes of Data
Bit Name
No-protocol Mode Send Delay Specifier
15
No-protocol Mode Send Delay Time
0 to 14
8 to 15 No-protocol Mode Start Code
0 to 7 No-protocol Mode End Code
No-protocol Mode Start Code Specifier
12 to 15
No-protocol Mode End Code Specifier
8 to 11
Number of Bytes of Data
0 to 7
3. Instructions
Settings
0000 to 210F hex,
0 to 99,990 ms decimal (in 10-ms units)
00 to FF hex
00 to FF hex
0: None
1: Use start code.
0 hex: None
1 hex: Use end code.
2 hex: Use CR+LF.
00 hex: 256 bytes (default)
01 to FF hex: 1 to 255 bytes
Settings
0: Default (0 ms)
1: Use delay in bits 1 to 14.
0000 to 7530 hex
0 to 300,000 ms decimal (in 10-ms units)
00 to FF hex
00 to FF hex
0 hex: None
1 hex: Use start code.
0 hex: None
1 hex: Use end code.
2 hex: Use CR+LF.
00 hex: 256 bytes (default)
01 to FF hex: 1 to 255 bytes
