8
AIS FUNCTION
■ About the Detail screen
The Detail screen displays the information about the selected AIS target or waypoint. The
contents may diff er, depending on the selected target.
L When a Danger target is selected,
L When a Friend target is selected,
z Push the Software Key below for your next operation.
Displays the "Compose Non-Distress" screen to
DSC :
send an Individual call. (p. 25)
Starts navigation to the selected target. (p. 67)
NAV :
Sets the selected target as a Friend. (p. 56)
Friend :
L A beep sounds and a popup screen is displayed
when the memory is full.
Displays the Individual ID entry screen. (p. 8)
MMSI :
L A beep sounds and a popup screen is displayed
when the memory is full, or the ID has been
already added.
D Contents list
NOTE: The contents may diff er, depending on the received data.
Class A and SAR vessel
AIS class
MMSI code
Ship name
Country name
Call sign
Vendor ID
IMO number
CPA (Closest Point of Approach)
TCPA (Time to CPA)
Position (Latitude, Longitude)
SOG (Speed Over Ground)
COG (Course Over Ground)
HDG (Heading)
PA (Position Accuracy (H: High, L: Low))
Range
Bearing
ROT (Rate Of Turn)
Bow to antenna distance
Stern to antenna distance
Port side to antenna distance
Starboard side to antenna distance
Length
Beam
Draught
57
is displayed.(p. 55)
is displayed. (p. 55)
Type of ship
NAV Status
Destination
Estimated time of arrival
Elapsed time
Class B
AIS class
MMSI code
Ship name
Country name
Call sign
Vendor ID
CPA (Closest Point of Approach)
TCPA (Time to CPA)
Position (Latitude, Longitude)
SOG (Speed Over Ground)
COG (Course Over Ground)
HDG (Heading)
PA (Position Accuracy (H: High, L: Low))
Range
Bearing
Bow to antenna distance
Stern to antenna distance
Port side to antenna distance
