BOSCH LED Remote on-board computer
The on-board computer on the handlebars is used as a control panel. It controls the system and all
indicators on the display screen using six buttons.
Figure 55: Overview of BOSCH LED Remote on-board computer
1
Selected level of assistance indicator
2
ABS indicator (optional)
3
Battery level indicator (on-board computer)
4
Select button
5
On-Off button (on-board computer)
6
Ambient light sensor
7
Increase brightness button/
>
forward button
MY23I0a - 42_1.0_22.01.2024
6
5
7
8
9
10
4
3
2
11
8
Decrease brightness button/
<
back button
9
Plus button/
+
light button
10
Minus button/
–
push assist button
11
Diagnosis connection (for maintenance
purposes only)
12
Mount
