Description of controls and screens

3.6.1

Handlebars

6
7
Figure 54: Detailed view of handlebars with BOSCH Kiox 300, example
1, 7 Handle
2 Rear wheel handbrake (behind handlebars)
3 Main beam switch
4 Display Kiox300
5 LED Remote control panel
MY23I0a - 42_1.0_22.01.2024
5 4
8
3
6 Front wheel handbrake (behind handlebars)
8 Bell
9 Twist shifter
Description
2
1
9
77
