5.3.2
Adjusting the suspension system to body weight
Not included in price
Seat post and forks are components that may be
§
replaced after approval by the vehicle or parts
manufacturer.
Replacing with different sizes and hardnesses
within a product series is permitted for seat
posts.
Steel suspension in suspension forks and seat
posts are designed to bear the rider's body
weight. If the body weight is exceeded or not
reached, the suspension system will no longer
function as intended. This has no effect on the
suspension fork's or seat post's approved load
capacity but the suspension system will no longer
function perfectly or it won't work at all.
Adjust all components such as suspension
forks or suspension seat posts with steel
springs to the rider's body weight.
MY23I0a - 42_1.0_22.01.2024
5.3.2.1 Adjusting SR Suntour suspension
elements
Not included in price
SR SUNTOUR steel suspension forks and
parallelogram seat posts are available in three
different hardness types for different body
weights:
Coil spring model
Max. bodyweight [kg]
Table 22: Suspension hardness and body weight
Unless specified otherwise, SR Suntour forks and
seat posts are supplied with medium hardness ex
factory.
A harder and a softer suspension hardness are
available so that the suspension fork can be
adjusted to the rider's body weight.
Figure 74: SR Suntour coil spring hard
1 Ask about body weight before selling the
pedelec.
2 Compare with Table
Tabelle 22 auf Seite
3 If the body weight differs from the
specifications, order suitable spring elements
from SR Suntour and install them.
Assembly
Soft
Medium
Rigid
50... 75
70... 95
90... 120
100.
100
