5.5
Assembly instructions for online
sales
Your specialist dealer will complete assembly and
commissioning for this pedelec. The pedals were
unscrewed and the handlebars repositioned
before transportation. You need these instructions
to get your pedelec roadworthy and ready for use
after transportation.
CAUTION
!
Crash caused by incorrectly adjusted torques
If a screw is fastened too tightly, it may break. If a
screw is not fastened enough, it may loosen. This
will cause a crash with injuries.
Always observe the indicated torques on the
screw, the component and in the operating
instructions.
Prior knowledge is required for assembly. If
you don't have any prior knowledge, contact
specialist dealer.
Crash and crushing hazard caused by
unintentional activation
There is a risk of injury if the drive system is
activated unintentionally.
Remove the battery.
5.5.1
Unpacking
The packaging material consists of cardboard.
The packaging has to be disposed of in
accordance with the regulations of the
authorities.
MY23I0a - 42_1.0_22.01.2024
Scope of delivery
1 pedelec with battery
2 pedals (already greased)
1 charger
1 set of operating instructions on CD
5.5.2
Preparing
Assemble the pedelec in a clean, dry environ-
ment. The work environment temperature
should be between 15 °C and 25 °C.
Secure the pedelec in a fitting stand. The fitting
stand used must be approved for a maximum
weight of least 30 kg.
Alternatively, you can get another person to
hold the pedelec.
Read the operating instructions for your
pedelec.
5.5.3
Required tools
The following tools are required to assemble the
pedelec:
Screw wrench
15 mm
Torque wrench
Working range: 5- 40 Nm
by,schulz handlebars:
Torx bits: 4 mm, 5 mm and 6 mm
If not:
Hexagon bits: 4 mm, 5 mm and 6 mm
Table 23: Tools required for assembly
Assembly
107
