Validation Controlled By The Printer - TransAct Ithaca 90PLUS Series Operator's Manual

56
Series 90PLUS Operator's Guide

Validation Controlled by the Printer

1. The host system sends a validation transaction to the printer.
2. The printer opens the validation clamp, so the form can be inserted. The
FORM light flashes, and the READY light shines orange.
3. Insert the form into the printer.
Use the green form guide on the right side of the validation slot to align the
form. Push the form all the way down until the READY light turns green.
When the READY light changes from orange to green, the form is
properly positioned, and the printer clamps the form automatically.
4. The printer prints on the form.
When printing is complete, the host releases the form.
5. Remove the form.
Green
Forms Guide
READY
Light
