Alcatel-Lucent OmniSwitch 6450-P10S Hardware User's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Part No. 060351-10, Rev. F
January 2015
OmniSwitch 6450 Hardware Users
Guide
www.alcatel-lucent.com

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent OmniSwitch 6450-P10S

Summary of Contents for Alcatel-Lucent OmniSwitch 6450-P10S

  • Page 1 Part No. 060351-10, Rev. F January 2015 OmniSwitch 6450 Hardware Users Guide www.alcatel-lucent.com...
  • Page 2 This user guide documents OmniSwitch 6450 hardware, including chassis and associated components. The specifications described in this guide are subject to change without notice. Copyright © 2015 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.

  • Page 3: Table Of Contents

    Contents About This Guide ......................ix Supported Platforms ......................ix Who Should Read this Manual? ..................x When Should I Read this Manual? ..................x What is in this Manual? ...................... x What is Not in this Manual? ....................x How is the Information Organized? ..................
  • Page 4 OmniSwitch 6450-P10 Rear Panel ................2-6 OmniSwitch 6450-P10 Internal AC Power Supply ..........2-6 OmniSwitch 6450-P10S ....................2-8 Front Panel .......................2-8 OmniSwitch 6450-P10S Rear Panel ..............2-10 OmniSwitch 6450-P10S Internal AC Power Supply ..........2-11 OmniSwitch 6450-24 ....................2-13 Chassis Features .....................2-13 Front Panel ......................2-13 OmniSwitch 6450-24 Rear Panel ................2-14 OmniSwitch 6450-24 Internal AC Power Supply ..........2-14...
  • Page 5 Contents OmniSwitch 6450 External Backup Power Supplies ............2-36 PS-550W-AC-P External 550W AC PoE Power Supply ........2-36 PS-900AC-P External 900W AC PoE Power Supply ..........2-36 Installing Expansion Modules ..................2-37 Removing Expansion Modules ..................2-39 Installing Power Supplies ....................2-41 Removing Power Supplies ..................2-43 AC Power Cords ......................2-45 Specifications ......................2-45 Console Port ........................2-46...
  • Page 6 Contents Connecting Chassis to Power Source ................3-15 AC Power Supply Connections ................3-15 Powering On a Chassis ..................3-15 Chapter 4 Booting OmniSwitch 6450 Switches ................4-1 Booting an OmniSwitch ...................4-1 Console Port ........................4-2 Serial Connection Default Settings ................4-2 Modifying the Serial Connection Settings ...............4-2 Monitoring the Chassis ....................4-4 Checking the Overall Chassis Status ................4-4 Checking the Temperature Status ................4-4...
  • Page 7 Contents ................6-1 Chapter 6 Managing OmniSwitch 6450 Stacks In This Chapter ........................6-1 OmniSwitch 6450 Stacking Specifications ..............6-2 OmniSwitch 6450 Stack Overview .................6-2 Expansion Modules and Stacking Mode .................6-3 Swapping Expansion Modules .................6-3 OmniSwitch 6450-10 Mode ..................6-3 Roles Within the Stack ....................6-4 Primary and Secondary Management Modules ............6-4 Primary Management Module Selection ............6-7 Secondary Management Module Selection .............6-10...
  • Page 8 Contents .............A-1 Appendix A Regulatory Compliance and Safety Information Declaration of Conformity: CE Mark ................A-1 China RoHS: Hazardous Substance Table ..............A-2 Waste Electrical and Electronic Equipment (WEEE) Statement ........A-4 Standards Compliance ....................A-5 Safety Standards ...................... A-5 EMC Standards .......................

  • Page 9: About This Guide

    This OmniSwitch 6450 Hardware Users Guide describes your switch hardware components and basic switch hardware procedures. Supported Platforms The information in this guide applies to the following products: • OmniSwitch 6450-10(L) • OmniSwitch 6450-P10(L) OmniSwitch 6450-P10S • OmniSwitch 6450-24(L) • OmniSwitch 6450-P24(L) • OmniSwitch 6450-48(L) •...

  • Page 10: Who Should Read This Manual

    Who Should Read this Manual? About This Guide Who Should Read this Manual? The audience for this users guide is network administrators and IT support personnel who need to config- ure, maintain, and monitor switches and routers in a live network. However, anyone wishing to gain knowledge on the OmniSwitch 6450 hardware will benefit from the material in this guide.

  • Page 11: How Is The Information Organized

    About This Guide How is the Information Organized? How is the Information Organized? This users guide provides an overview of OmniSwitch 6450 switches, specifications of the hardware components, steps for setting up and managing OmniSwitch 6450 switches, and an overview and proce- dures for managing Power over Ethernet (PoE).
  • Page 12 Documentation Roadmap About This Guide Stage 3: Integrating the Switch Into a Network Pertinent Documentation: Network Configuration Guide When you are ready to connect your switch to the network, you will need to learn how the OmniSwitch implements fundamental software features, such as 802.1Q, VLANs, and Spanning Tree. The Network Configuration Guide contains overview information, procedures and examples on how standard network- ing technologies are configured in the OmniSwitch.

  • Page 13: Related Documentation

    Includes SFP transceiver specifications and product compatibility information. Technical Tips, Field Notices • Includes information published by Alcatel-Lucent’s Customer Support group. Release Notes and Upgrade Instructions • Includes open problem reports, feature exceptions, and other important information on the features supported in the current release and any limitations to their support.

  • Page 14: Published / Latest Product Documentation

    About This Guide Published / Latest Product Documentation All user guides for the OmniSwitch Series are included on the Alcatel-Lucent public website. This website also includes user guides for other Alcatel-Lucent Enterprise products. The latest user guides can be found on our website at: http://enterprise.alcatel-lucent.com/UserGuides...

  • Page 15: Omniswitch 6450 Switches

    1 OmniSwitch 6450 Switches Alcatel-Lucent OmniSwitch 6450 Stackable Gigabit Ethernet LAN switches include 10-port, 24-port and 48-port models. OmniSwitch 6450-10 offer Fast and Gigabit Ethernet for classroom, workgroup and small enterprise applications and provide low-power consumption and fanless operation. OmniSwitch 6450-24 and OmniSwitch 6450-48 fixed configuration gigabit switches offer optional upgrade paths for 10 Gigabit Ethernet (GigE) stacking, 10 GigE uplinks and metro Ethernet services.

  • Page 16: Chassis Configurations

    AC power supply. • OmniSwitch 6450-P10S: Provides eight (8) 10/100/1000BaseT Power Over Ethernet ports (with ports 1 through 4 supporting HPoE at up to ~75W and ports 5 through 8 supporting 802.3at), two (2) fixed SFP ports, and an internal AC power supply. This switch also supports IEEE 1588 Precision Time Protocol (PTP).

  • Page 17: 48-Port Models

    OmniSwitch 6450 Switches Chassis Configurations 48-Port Models OmniSwitch 6450-48: Provides 48 10/100/1000 BaseT ports, 2 fixed SFP+ ports and one expansion • slot for optional stacking or uplink modules. The chassis provides three fans and internal AC power with optional internal AC or DC backup power. •...

  • Page 18: Omniswitch 6450 Feature Overview

    “HPoE” on the chassis front panel. Note. PoH is supported on OmniSwitch 6450-P10S models only. PoE support of up to 30W per port is provided on PoE ports 5 through 8. The maximum PoE power budget available for all ports on the OmniSwitch 6450-P10S is 280W.

  • Page 19: Availability Features

    OmniSwitch 6450 Feature Overview Availability Features OmniSwitch 6450 switches incorporate advanced Alcatel-Lucent Operating System (AOS) protocols to ensure high availability for mission critical applications. Availability features are hardware- and software- based safeguards that help to prevent the loss of data flow in the unlikely event of a subsystem failure.

  • Page 20: Hardware Monitoring

    OmniSwitch 6450 Feature Overview OmniSwitch 6450 Switches Hardware Monitoring Automatic Monitoring Automatic monitoring refers to the switch’s built-in sensors that automatically monitor operations. If an error is detected (e.g., over-threshold temperature), the switch immediately sends a trap to the user. The trap is displayed on the console in the form of a text error message.
  • Page 21 OmniSwitch 6450-P10(L) Ten port 10/100/1000BaseT Power Over Ethernet model. (OS6450-P10/OS6450-P10L) Available in 10/100 “L” model. OmniSwitch 6450-P10S Ten port 10/100/1000BaseT Power Over Ethernet model. (OS6450-P10S) Provides ~75W PoH power on ports 1 through 4. Provides support for additional features like IEEE 1588 Precision Time Protocol (PTP).

  • Page 22: Chapter 2 Omniswitch 6450 Chassis And Hardware Components

    OmniSwitch 6450-10 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-10 Chassis Features System status LEDs Internal AC Power Supply (8) Non-combo 10/100/1000Base-T ports Console port (RJ-45) (2) Non-combo 100/1000BaseX ports USB port (USB 2.0) (2) Combo 10/100/1000Base-T or Fanless design 100/1000BaseX ports Front Panel OS6450-10...

  • Page 23: Omniswitch 6450-10 Rear Panel

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-10 OmniSwitch 6450-10 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-10 Rear Panel Item Description Power Supply Connector...
  • Page 24 OmniSwitch 6450-10 OmniSwitch 6450 Chassis and Hardware Components OS6450-10 Specifications 10/100/1000BaseT ports Total combo ports SFP uplink ports 802.3at PoE ports Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 8.50 inches (21.5 cm) Chassis Height 1.73 inches (4.40 cm) Chassis Depth 11.50 inches (29.21 cm)

  • Page 25: Omniswitch 6450-P10

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10 OmniSwitch 6450-P10 Chassis Features System status LEDs Internal AC Power Supply (8) Non-combo 10/100/1000Base-T PoE ports Console port (RJ-45) (2) Non-combo 100/1000BaseX ports USB port (USB 2.0) (2) Combo 10/100/1000Base-T or Fanless design 100/1000BaseX ports Front Panel OS6450-P10...

  • Page 26: Omniswitch 6450-P10 Rear Panel

    OmniSwitch 6450-P10 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-P10 Rear Panel Item Description Power Supply Connector...
  • Page 27 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10 OS6450-P10 Specifications Total non-combo 10/100/ 8 (1-8) 1000BaseT PoE ports per switch Total combo ports per switch 2 (9-10) Total non-combo SFP ports per 2 (11-12 in Uplink mode) switch Flash memory size 128 MB RAM memory size 256 MB SDRAM...

  • Page 28: Omniswitch 6450-P10S

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10S The OmniSwitch 6450-P10S is a standalone switch with eight (8) 10/100/1000 Base-T PoE ports and two (2) fixed SFP ports. (Refer to the OmniSwitch 6250/6450 Transceivers Guide for SFP specifications and compatibility information.) OmniSwitch 6450-P10S switches support IEEE 1588 Precision Time Protocol (PTP).
  • Page 29 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10S Item Description Four (4) 10/100/1000BaseT RJ-45 PoH Ports Port numbers 1 through 4. Each port provides ~75W of PoH power. (These ports are labeled “HPoE” on the chassis front panel.) Four (4) 10/100/1000BaseT RJ-45 PoE Ports Port numbers 5 through 8.

  • Page 30: Omniswitch 6450-P10S Rear Panel

    OmniSwitch 6450-P10S OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10S Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-P10S Rear Panel...

  • Page 31: Omniswitch 6450-P10S Internal Ac Power Supply

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10S OmniSwitch 6450-P10S Internal AC Power Supply P/S Component Description Maximum System Power 40 W Maximum PoE Power 280 W Total Maximum Output Power 320 W Input Range 100-240V~, 50-60Hz, 4A OmniSwitch 6450 Hardware Users Guide...
  • Page 32 OmniSwitch 6450-P10S OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P10S Specifications Chassis Width 8.50 inches (21.5 cm) Chassis Height 1.73 inches (4.40 cm) (1 RU) Chassis Depth 11.50 inches (29.21 cm) Chassis Weight 5.14 lbs (2.33 kg) Maximum System Power...

  • Page 33: Omniswitch 6450-24

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-24 OmniSwitch 6450-24 Chassis Features System status LEDs Internal AC Power Supply (24) Non-combo 10/100/1000Base-T ports Console port (RJ-45) (2) Non-combo SFP/SFP+ ports USB port (USB 2.0) Expansion Module Stacking LED Front Panel OmniSwitch 6450-24 Front Panel Item Description...

  • Page 34: Omniswitch 6450-24 Rear Panel

    OmniSwitch 6450-24 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-24 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-24 Rear Panel Item Description Grounding Block...
  • Page 35 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-24 OS6450-24 Specifications RJ-45 10/100/1000BaseT ports SFP+ Gigabit/10Gigabit uplink ports Ports per expansion module Max. chassis per stack Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 17.32 inches (44.00 cm) Chassis Height 1.73 inches (4.40 cm) Chassis Depth...

  • Page 36: Omniswitch 6450-P24

    OmniSwitch 6450-P24 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P24 Chassis Features System status LEDs Internal AC Power Supply (24) Non-combo 10/100/1000Base-T 802.3at PoE Backup Power Supply (BPS) Connector ports (2) Non-combo SFP/SFP+ ports Console port (RJ-45) Expansion Module USB port (USB 2.0) Stacking LED Front Panel OmniSwitch 6450-10 Front Panel...

  • Page 37: Omniswitch 6450-P24 Rear Panel

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P24 OmniSwitch 6450-P24 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-P24 Rear Panel Item Description Grounding Block...
  • Page 38 OmniSwitch 6450-P24 OmniSwitch 6450 Chassis and Hardware Components OS6450-P24 Specifications RJ-45 10/100/1000BaseT 802.3at PoE ports SFP+ Gigabit/10Gigabit uplink ports Ports per expansion module Max. chassis per stack Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 17.32 inches (44.00 cm) Chassis Height 1.73 inches (4.40 cm)

  • Page 39: Omniswitch 6450-48

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-48 OmniSwitch 6450-48 Chassis Features System status LEDs Internal AC Power Supply (48) Non-combo 10/100/1000Base-T ports Console port (RJ-45) (2) Non-combo SFP/SFP+ ports USB port (USB 2.0) Expansion Module Stacking LED Front Panel OmniSwitch 6450-48 Front Panel Item Description...

  • Page 40: Omniswitch 6450-48 Rear Panel

    OmniSwitch 6450-48 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-48 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-48 Rear Panel Item Description Grounding Block...
  • Page 41 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-48 OS6450-48 Specifications Total non-combo 10/100/ 1000BaseT ports per switch Total non-combo SFP/SFP+ ports per switch Total expansion modules per switch Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 17.32 inches (44.00 cm) Chassis Height 1.73 inches (4.40 cm)

  • Page 42: Omniswitch 6450-P48

    OmniSwitch 6450-P48 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P48 Chassis Features System status LEDs Backup Power Supply (BPS) Connector (48) Non-combo 10/100/1000Base-T PoE ports Console port (RJ-45) (2) Non-combo SFP/SFP+ ports USB port (USB 2.0) Expansion Module Stacking LED Internal AC Power Supply Front Panel OmniSwitch 6450-P48 Front Panel...

  • Page 43: Omniswitch 6450-P48 Rear Panel

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-P48 OmniSwitch 6450-P48 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-P48 Rear Panel Item Description Grounding Block...
  • Page 44 OmniSwitch 6450-P48 OmniSwitch 6450 Chassis and Hardware Components OS6450-P48 Specifications Total non-combo 10/100/ 1000BaseT 802.3at PoE ports per switch Total non-combo SFP/SFP+ ports per switch Total expansion modules per switch Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 17.32 inches (44.00 cm) Chassis Height...

  • Page 45: Omniswitch 6450-U24

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24 OmniSwitch 6450-U24 Chassis Features System status LEDs Internal AC Power Supply (22) Non-combo SFP ports Console port (RJ-45) (2) Combo 10/100/1000BaseT or SFP USB port (USB 2.0) (2) Non-combo SFP/SFP+ ports Stacking LED Expansion Module Front Panel OmniSwitch 6450-U24 Front Panel...

  • Page 46: Omniswitch 6450-U24 Rear Panel

    OmniSwitch 6450-U24 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-U24 Rear Panel Item Description Grounding Block...
  • Page 47 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24 OS6450-U24 Specifications Total non-combo SFP ports per switch Total RJ45/SFP combo ports per switch Total non-combo SFP/SFP+ ports per switch Total expansion modules per switch Flash memory size 128 MB RAM memory size 256 MB SDRAM Chassis Width 17.32 inches (44.00 cm)

  • Page 48: Omniswitch 6450-U24S

    OmniSwitch 6450-U24S OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24S The OmniSwitch 6450-U24S provides 22 SFP ports, two (2) RJ45/SFP combo ports, two (2) fixed SFP+ ports and a slot (located on the rear panel) for two (2) optional SFP+ stacking/expansion ports. (Refer to the OmniSwitch 6250/6450 Transceivers Guide for SFP specifications and compatibility information.) OmniSwitch 6450-U24S switches support IEEE 1588 Precision Time Protocol (PTP).
  • Page 49 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24S Item Description USB Port High speed USB 2.0 port. SFP Ports 22 SFP ports. Port numbers 1 through 22. Fixed SFP+ Ports Port numbers 25 and 26. Refer to the OmniSwitch 6250/6450 Transceivers Guide for SFP specifications and compatibility information. Refer to “OmniSwitch 6450 LED Status”...

  • Page 50: Omniswitch 6450-U24S Rear Panel

    OmniSwitch 6450-U24S OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24S Rear Panel Note The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OmniSwitch 6450-U24S Rear Panel Item Description Grounding Block...
  • Page 51 OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450-U24S OmniSwitch 6450-U24S Specifications Chassis Width 17.32 inches (44.0 cm) Chassis Height 1.73 inches (4.40 cm) (1 RU) Chassis Depth 12.3 inches (31.24 cm) Chassis Weight 9.0 lbs (4.08 kg) Power Consumption Operating Humidity 5% to 95% Storage Humidity 5% to 95%...

  • Page 52: Omniswitch 6450 Led Status

    OmniSwitch 6450 LED Status OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450 LED Status State Description Solid Green The switch has passed hardware diagnostic tests and the system software is operational Blinking Green Normal diagnostics and/or Remote Config Load in progress Solid Amber System fan failure or temperature threshold exceeded Solid Green...

  • Page 53: Expansion Modules

    OmniSwitch 6450 Chassis and Hardware Components Expansion Modules Expansion Modules OS6450-GNI-C2 The OS6450-GNI-C2 is an optional uplink module that supports two RJ45 Gigabit ports. The module inserts into the expansion slot at the rear of 24- and 48-port OS6450 switches, Item Description Captive Screws...

  • Page 54: Os6450-Xni-U2

    Expansion Modules OmniSwitch 6450 Chassis and Hardware Components OS6450-XNI-U2 The OS6450-XNI-U2 is an optional 10 Gigabit stacking module that supports two SFP+ 10 Gigabit ports. The module inserts into the expansion slot at the rear of 24- and 48-port OS6450 switches. Note.

  • Page 55: Omniswitch 6450 Internal Backup Power Supplies

    OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450 Internal Backup Power Supplies OmniSwitch 6450 Internal Backup Power Supplies Backup power supplies are fully operational and may share the load with the primary power supply, remaining operational in the event the primary power supply fails unexpectedly. If a failover occurs, the backup power supply automatically takes up the full power load without disrupting the switch.

  • Page 56: Omniswitch 6450 External Backup Power Supplies

    OmniSwitch 6450 External Backup Power Supplies OmniSwitch 6450 Chassis and Hardware Components OmniSwitch 6450 External Backup Power Supplies Backup power supplies are fully operational and may share the load with the primary power supply, remaining operational in the event the primary power supply fails unexpectedly. If a failover occurs, the backup power supply automatically takes up the full power load without disrupting the switch.

  • Page 57: Installing Expansion Modules

    OmniSwitch 6450 Chassis and Hardware Components Installing Expansion Modules Installing Expansion Modules The expansion module slot is located at the right-hand side of the chassis rear panel. Refer to the rear panel diagrams in the sections above for additional information. If a blank cover plate is in place over the expansion module slot, remove the cover plate by loosening the two screws at the left and right sides of the cover plate.
  • Page 58 Installing Expansion Modules OmniSwitch 6450 Chassis and Hardware Components When the module is seated in the chassis slot, hand tighten the thumb screws at the left and right sides of the module’s front plate. Install transceivers and connect network cables as required. Refer to the OmniSwitch 6250/6450 Transceivers Guide for additional information.

  • Page 59: Removing Expansion Modules

    OmniSwitch 6450 Chassis and Hardware Components Removing Expansion Modules Removing Expansion Modules If applicable, remove any attached network cables from the module. Loosen the thumb screws at the left and right sides of the module’s front plate. When the thumb screws are loosened and the module front plate is free from the chassis, grasp the thumbscrews and pull the module straight out of the chassis.
  • Page 60 Removing Expansion Modules OmniSwitch 6450 Chassis and Hardware Components If the expansion module is not being replaced with another module, be sure to install a blank plate over the slot opening. page 2-40 OmniSwitch 6450 Hardware Users Guide January 2015...

  • Page 61: Installing Power Supplies

    OmniSwitch 6450 Chassis and Hardware Components Installing Power Supplies Installing Power Supplies Insert the power supply into the back of the chassis, as shown. Slide the power supply back until it is securely seated in the chassis backplane.When the power supply is fully seated, hand-tighten the thumb screws.
  • Page 62 Installing Power Supplies OmniSwitch 6450 Chassis and Hardware Components Plug the power cord (provided) into the power supply’s socket. Completed Installation page 2-42 OmniSwitch 6450 Hardware Users Guide January 2015...

  • Page 63: Removing Power Supplies

    OmniSwitch 6450 Chassis and Hardware Components Installing Power Supplies Removing Power Supplies When removing a power supply, first disconnect the power cord from the power source. Once the power cord is disconnected, pull the power cord out of the power supply housing. Loosen the thumb screws at the left and right sides of the power supply face plate.
  • Page 64 Installing Power Supplies OmniSwitch 6450 Chassis and Hardware Components Slide the power supply out of the chassis. Note. If you are not replacing the power supply, be sure to install a blank cover panel over the empty power supply bay. page 2-44 OmniSwitch 6450 Hardware Users Guide January 2015...

  • Page 65: Ac Power Cords

    OmniSwitch 6450 Chassis and Hardware Components AC Power Cords AC Power Cords Since the power cord is the switch’s only disconnect device, it should be plugged into an easily accessible outlet. In the event that your power cord is lost or damaged, refer to the specifications below. Specifications The power cord included with this product contains three (3) insulated #18AWG stranded copper wires and is rated between 85-265 VAC (region dependent), 10 amps with a nominal length of 2 meters.

  • Page 66: Console Port

    Console Port OmniSwitch 6450 Chassis and Hardware Components Console Port The console port, located on the chassis front panel, provides a console connection to the switch and is required when logging into the switch for the first time. By default, this RJ-45 connector provides a DTE console connection.

  • Page 67: Port Pinouts

    OmniSwitch 6450 Chassis and Hardware Components Port Pinouts Port Pinouts RJ-45 Console Port – Connector Pinout Pin Number Signals as DTE Console Port Ground Ground 10/100 Ethernet Port – RJ-45 Pinout (non-PoE) Pin Number Description not used not used not used not used Gigabit Ethernet Port –...

  • Page 68: 10/100/1000 Mbps Power Over Ethernet Port - Rj-45 Pinout

    Overtemp Condition OmniSwitch 6450 Chassis and Hardware Components 10/100/1000 Mbps Power over Ethernet Port – RJ-45 Pinout Pin Number Description RX+ (-VDC) RX- (-VDC) TX+ (+VDC) TX- (+VDC) Overtemp Condition The OmniSwitch is designed to operate within a specified operating temperature as noted under the specifications section.

  • Page 69: Dying Gasp

    OmniSwitch 6450 Chassis and Hardware Components Dying Gasp Dying Gasp If the switch loses all power it will maintain power long enough to send a Dying Gasp message before completely shutting down. An SNMP trap, Syslog message and Link OAM PDUs will be generated. Scenarios A Dying Gasp event will be generated in the following scenarios: Primary power supply failure (if only power supply present).

  • Page 70: Link Oam Pdu

    Dying Gasp OmniSwitch 6450 Chassis and Hardware Components Link OAM PDU As soon as the power failure is detected an 802.3ah OAM Information PDU is sent to all ports for which link OAM is enabled and the LinkOAM port status is operational. The PDU will have the Dying Gasp bit set.

  • Page 71: Mounting Omniswitch 6450 Switches

    3 Mounting OmniSwitch 6450 Switches This chapter covers different mounting and installation options. OmniSwitch 6450 switches may be either table- or rack-mounted. 24- and 48-port OmniSwitch 6450 switches are rack mounted using factory- installed rack mount flanges. 10-port (1/2 width) switches may be rack mounted using available rack mounting kits.

  • Page 72: General Installation Recommendations

    General Installation Recommendations Mounting OmniSwitch 6450 Switches General Installation Recommendations Airflow Recommendations To ensure proper airflow, be sure that your switch is placed in a well-ventilated area and provide minimum recommended clearance at the front, back and sides of the switch, as shown below. Restricted airflow can cause your switch to overheat, which can lead to switch failure.
  • Page 73 Mounting OmniSwitch 6450 Switches General Installation Recommendations 6 inches minimum at rear of chassis. 2 inches minimum at left and right sides. 6 inches minimum at front of chassis. 10-Port Chassis Types Note. Clearance is not required at the top and bottom of the chassis. Clearance recommendations at the front and rear of chassis are for access to cabling and components only and are not intended as a specific airflow requirement.

  • Page 74: Mechanical Loading

    Table-Mounting OS6450 Switches Mounting OmniSwitch 6450 Switches Mechanical Loading Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading of the circuit might have on overcurrent protection and supply wiring.

  • Page 75: Rack-Mounting 10-Port Os6450 Switches

    It is recommended that two people install the switch assembly on the rack—one person to hold the chassis and position it on the rack, and a second person to secure the chassis to the rack using attachment screws. (Please note that Alcatel-Lucent does not provide rack-mount screws. Use the screws supplied by the rack vendor.) To prevent a rack from becoming top heavy, it is recommended that you install heavier equipment at •...

  • Page 76: Installing Available Rack Mounting Kits

    Installing Available Rack Mounting Kits Mounting OmniSwitch 6450 Switches Installing Available Rack Mounting Kits Note. Some factory-installed screws may need to be removed prior to mounting, depending on the kit being used. Installing the OS6450-RM-19-L Rack Mount Kit A single chassis can also be mounted into a standard 19-inch rack using L-brackets, as shown in the figure below.

  • Page 77: Installing The Os6450-Dual-Mnt Rack Mount Kit

    Mounting OmniSwitch 6450 Switches Installing Available Rack Mounting Kits Installing the OS6450-DUAL-MNT Rack Mount Kit Plate and Screws Slot -bracket Power Supply Tray Rear Bracket (Not used) Two chassis can be assembled side-by-side for mounting into a standard 19-inch rack as show in the figure below.
  • Page 78 Installing Available Rack Mounting Kits Mounting OmniSwitch 6450 Switches Align the chassis and slide both front and rear center brackets together. Slide chassis together Slide Chassis Together Place bracket plate over front and rear brackets and secure with thumb screws. Bracket Plate and Screws Secure Front and Back with Bracket Plate Attach rack mount brackets to both sides of the front of the chassis.
  • Page 79 Mounting OmniSwitch 6450 Switches Installing Available Rack Mounting Kits Align the holes in the flanges with the rack holes and insert rack mount screws (not provided) through the bottom hole of each flange and then the top of each flange. Tighten both screws until they are secure. When rack mounting, a clearance of 0.875 inches is recommended above the chassis.

  • Page 80: Rack-Mounting 24 And 48-Port Os6450 Switches

    19-inch rack-mount installations. These flanges must be attached to the chassis before the switch can be rack mounted. Note. If you are installing the switch in a 23-inch-wide rack, Alcatel-Lucent offers optional 23-inch rack- mounting hardware. For more information, contact your Alcatel-Lucent representative.

  • Page 81: Rack Mounting Steps

    Mounting OmniSwitch 6450 Switches Rack-Mounting 24 and 48-Port OS6450 Switches Rack Mounting Steps Attach rack mount brackets to both sides of the chassis as shown. Mark the holes on the rack where the switch is to be installed. Lift and position the switch until the rack-mount brackets are flush with the rack post, then align the holes in the brackets with the rack holes that were marked at step 1.
  • Page 82 Rack-Mounting 24 and 48-Port OS6450 Switches Mounting OmniSwitch 6450 Switches Once the screws at the bottom of each bracket are secure, install the remaining two rack mount screws. Be sure that all screws are securely tightened. page 3-12 OmniSwitch 6450 Hardware Users Guide January 2015...

  • Page 83: Installing External Poe Power Supplies

    Mounting OmniSwitch 6450 Switches Installing External PoE Power Supplies Installing External PoE Power Supplies The following external power supplies provided PoE and backup system power for OmniSwitch 6450 PoE-ready switches: PS-550W-AC-P (OS6450-P24) • • PS-900AC-P (OS6450-P48) These power supplies may be rack mounted above or below the chassis for a 2RU configuration. The following sections describe how to rack-mount a power supply shelf and connect the power supply to the chassis with a cable.

  • Page 84: Connecting The Power Supply Cable

    Installing External PoE Power Supplies Mounting OmniSwitch 6450 Switches Lift and position the shelf until the rack-mount flanges are flush with the rack post. Align the holes in the flanges with the rack holes that were marked earlier. Once the holes are aligned, insert a rack mount screw (not provided) through the bottom hole of each flange.

  • Page 85: Dc Power Supply Considerations

    Mounting OmniSwitch 6450 Switches Connecting Chassis to Power Source DC Power Supply Considerations DC power supplies have the following additional considerations: Connect to a -48V or -60V reliably grounded DC SELV source. • • Use common DC return connections for the DC power supplies. The DC return terminal conductor should be connected to the equipment frame.
  • Page 86 Connecting Chassis to Power Source Mounting OmniSwitch 6450 Switches page 3-16 OmniSwitch 6450 Hardware Users Guide January 2015...
  • Page 87 If any of the LED state differs from the states shown in the table above, refer to page 2-5 for more information. Contact Alcatel-Lucent Customer Support if the LED state persists. For information on logging in and configuring your switch, refer to the OmniSwitch 6450 Getting Started Guide.

  • Page 88: Booting Omniswitch 6450 Switches

    Console Port Booting OmniSwitch 6450 Switches Console Port The console port, located on the chassis front panel, provides a console connection to the switch and is required when logging into the switch for the first time. By default, this RJ-45 connector provides a DTE console connection.
  • Page 89 Booting OmniSwitch 6450 Switches Console Port To change the stop bits value, enter boot serialstopbits, followed by the number of stop bits. Options include 1 (default) and 2. For example: Boot > boot serialstopbits 2 Verify your current changes by entering show at the boot prompt: Boot >...

  • Page 90: Monitoring The Chassis

    Monitoring the Chassis Booting OmniSwitch 6450 Switches Monitoring the Chassis The OmniSwitch can be monitored and managed via the console port using Command Line Interface (CLI) commands. The switches can also be monitored and managed via the Ethernet using CLI commands, WebView, SNMP, and OmniVista.

  • Page 91: Viewing The Power Supply Status

    Booting OmniSwitch 6450 Switches Monitoring the Chassis Viewing the Power Supply Status To check the status of the power supply, use the show power command. For example: -> show power Slot Wattage Type Status Location ----+----+---------+------+-----------+---------- Internal Additional Monitoring Commands CLI Commands Used for Monitoring a Chassis show cmm Displays the basic hardware and status information for primary and...
  • Page 92 Monitoring the Chassis Booting OmniSwitch 6450 Switches page 4-6 OmniSwitch 6450 Hardware Users Guide January 2015...

  • Page 93: Managing Power Over Ethernet (Poe)

    OmniSwitch 6450 chassis. Important. Alcatel-Lucent recommends that PoE-enabled switches with attached IP telephones should have operational power supply redundancy at all times for 911 emergency requirements. In addition, both the switch and the power supply should be plugged into an Uninterruptible Power Source (UPS).

  • Page 94: In This Chapter

    Note. You can also monitor all chassis components and manage many chassis features, including Power over Ethernet, with WebView, Alcatel-Lucent’s embedded web-based device management application. WebView is an interactive and easy-to-use GUI that can be launched from the OmniVista or a web browser.

  • Page 95: Power Over Ethernet Specifications

    Power over Ethernet Specifications The table below lists general specifications for Alcatel-Lucent’s Power over Ethernet support. For more detailed power supply and Power Source Equipment (PSE) specifications, refer to Chapter 2, “OmniSwitch 6450 Chassis and Hardware Components.” IEEE 802.3at IEEE Standards supported* HPoE and IEEE 802.3at on OS6450-P10S only,...

  • Page 96: Viewing Poe Power Supply Status

    Viewing PoE Power Supply Status Managing Power over Ethernet (PoE) Viewing PoE Power Supply Status To view the current status of power supplies installed, use the show power command, as shown below: -> show power Slot Wattage Type Status Location ----+----+---------+------+-----------+---------- Internal External...

  • Page 97: Poe Class Detection

    PoE Class Detection Powered devices can be classified into different classes as shown in the table below. Class detection allows for automatic maximum power adjustment based on the power class detected. This will prevent the switch from delivering more than the maximum power allowed based on a device’s class. During class detection the switch will allocate the maximum amount of power allowed based on the class detected.

  • Page 98: Configuring The Total Power Available To A Port

    Configuring Power over Ethernet Parameters Managing Power over Ethernet (PoE) Configuring the Total Power Available to a Port By default, each port is authorized by the system software to use up to a maximum amount of milliwatts to power any attached device. You can either increase or decrease this value based on the range in the specifications table.

  • Page 99: Setting Port Priority Levels

    Setting Port Priority Levels As not all Powered Devices (PDs) connected to the switch have the same priority within a customer network setting, the switch allows the user to specify priority levels on a port-by-port basis. Priority levels include low, high, and critical. The default priority level for a port is low. Low.

  • Page 100: Understanding Priority Disconnect

    Understanding Priority Disconnect Managing Power over Ethernet (PoE) Understanding Priority Disconnect The priority disconnect function differs from the port priority function described on page 5-7 in that it applies only to the addition of powered devices (PDs) in tight power budget conditions. Priority disconnect is used by the system software in determining whether an incoming PD will be granted or denied power when there are too few watts remaining in the PoE power budget for an additional device.
  • Page 101 Priority Disconnect is Enabled; Same Priority Level on All PD Reminder. Priority disconnect examples are applicable only when there is inadequate power remaining to power an incoming device. When a PD is being connected to a port with the same priority level as all other in the slot, the physical port number is used to determine whether the incoming PD will be granted or denied power.

  • Page 102: Monitoring Power Over Ethernet Via Cli

    Monitoring Power over Ethernet via CLI Managing Power over Ethernet (PoE) Priority Disconnect is Disabled Reminder. Priority disconnect examples are applicable only when there is inadequate power remaining to power an incoming device. When priority disconnect is disabled, power will be denied to any incoming PD, regardless of its port priority status (i.e., low, high, and critical) or physical port number (i.e., 1/1).

  • Page 103: Managing Omniswitch 6450 Stacks

    5-41. Note. You can also manage and monitor OmniSwitch 6450 stacks through WebView, Alcatel-Lucent’s embedded web-based device management application. WebView is an interactive and easy-to-use GUI that can be launched from OmniVista or a web browser. Please refer to WebView’s online documentation for more information.

  • Page 104: Omniswitch 6450 Stacking Specifications

    OmniSwitch 6450 Stack Overview Managing OmniSwitch 6450 Stacks OmniSwitch 6450 Stacking Specifications Models Supporting Stacking Maximum Switches in a Stack OmniSwitch 6450-10 - 4 All other models - 8 Required Stacking Module OmniSwitch 6450-10 - N/A (Uses built-in stacking ports) All other models - OS6450-XNI-U2 Required Transceiver Type Direct Attach Copper...

  • Page 105: Expansion Modules And Stacking Mode

    Managing OmniSwitch 6450 Stacks Expansion Modules and Stacking Mode Expansion Modules and Stacking Mode The switch’s stacking mode (stackable versus standalone) is configured through auto-detection for 24-port and 48-port models. During the boot process, the switch determines the type of expansion module installed and sets the stacking mode accordingly.

  • Page 106: Roles Within The Stack

    Roles Within the Stack Managing OmniSwitch 6450 Stacks Roles Within the Stack In order to operate as a virtual chassis, switches within an OmniSwitch 6450 stack are assigned specific roles. These roles include primary and secondary management roles, idle status, and pass-through. For detailed descriptions of each of these roles, including their practical functions within the virtual chassis, refer to the sections below.
  • Page 107 Managing OmniSwitch 6450 Stacks Roles Within the Stack Note. For management module redundancy to work effectively, the software on all switches operating in the stack must be synchronized at all times. Refer to “Synchronizing Switches in a Stack” on page 5-37 for more information.
  • Page 108 Roles Within the Stack Managing OmniSwitch 6450 Stacks A stack of two OmniSwitch 6450 switches is operating normally. The stack consists of a pri- Primary mary module and a secondary module. (The Secondary software on both elements in the stack is syn- chronized.) The primary management module fails or is Offline...

  • Page 109: Primary Management Module Selection

    Managing OmniSwitch 6450 Stacks Roles Within the Stack Primary Management Module Selection For a stack of OmniSwitch 6450 switches to operate as a virtual chassis, there must be a mechanism for dynamically selecting the switch within the stack that will assume the primary management role. OmniS- witch 6450 switches use three different methods for selecting the primary switch.
  • Page 110 Roles Within the Stack Managing OmniSwitch 6450 Stacks Using Saved Slot Information The saved slot number is the slot number the switch will assume following a reboot. This information is stored in a switch’s boot.slot.cfg file; the switch reads its slot number assignment from this file at bootup and assumes the specified slot number within the stack.
  • Page 111 Managing OmniSwitch 6450 Stacks Roles Within the Stack Using Switch Uptime A user can override both the MAC address and saved slot methods for determining a stack’s primary management module. This is done by controlling the uptime of switches in the stack. If all elements of a stack are powered off, the user can force a particular switch to become primary by powering on that switch and waiting a minimum of 15 seconds before powering on any other switches.

  • Page 112: Secondary Management Module Selection

    Roles Within the Stack Managing OmniSwitch 6450 Stacks Secondary Management Module Selection In order to provide effective management module redundancy, all OmniSwitch 6450 stacked configura- tions dynamically assign a backup, or secondary, management module during the boot process. OmniS- witch 6450 stacks use two different methods for selecting the secondary switch. These methods are: Stacking connection to the primary switch •...
  • Page 113 Managing OmniSwitch 6450 Stacks Roles Within the Stack Using Saved Slot Information If a stack with preassigned slot information for each switch is booted, the switch with the second lowest slot value is assigned the secondary management role. For example, if a stack of four switches is booted and the preassigned slot values for each switch are 1, 2, 3, and 4, the switch with the slot value of 2 is assigned the secondary role.

  • Page 114: Idle Module Role

    Roles Within the Stack Managing OmniSwitch 6450 Stacks Idle Module Role Switches that are not assigned either the primary or secondary role in a stack are, by default, assigned the role of idle modules. These idle modules operate similarly to Network Interface (NI) modules in a chassis- based switch.

  • Page 115: Pass-Through Mode

    Managing OmniSwitch 6450 Stacks Roles Within the Stack Pass-Through Mode The pass-through mode is a state in which a switch has attempted to join a stack but has been denied primary, secondary, and idle status. When a switch is in the pass-through mode, its Ethernet ports are brought down (i.e, they cannot pass traffic).

  • Page 116: Recovering From Pass-Through Mode (Duplicate Slot Numbers)

    Roles Within the Stack Managing OmniSwitch 6450 Stacks To avoid a pass-through condition following a reboot, make sure that all saved slot values for the stack are unique. Use the stack set slot command. For example, change the saved slot value for the idle switch in slot 3 from 2 to 3: ->...
  • Page 117 Managing OmniSwitch 6450 Stacks Roles Within the Stack To resolve this pass-through condition, simply assign slot 1001 a new saved slot value and reboot the module. This can be done in either of two ways: Use the stack set slot command to assign the new value, then use the reload pass-through command...
  • Page 118 Roles Within the Stack Managing OmniSwitch 6450 Stacks In some pass-through conditions (for example, larger stacks where multiple switches are in pass-through mode), it might be desirable to correct any duplicate saved slot assignments and then reboot the entire stack. The recovery from pass-through can be accomplished with fewer steps than reassigning slot numbers and rebooting modules on a slot-by-slot basis.

  • Page 119: Stack Cabling

    Managing OmniSwitch 6450 Stacks Stack Cabling Stack Cabling Switches in a stack are connected to each other by stacking cables. These stacking cables provide high- speed, dual-redundant links between switches in a stack. Stacking cables for OmniSwitch 6450 switches must be connected in an A-B pattern. In other words, the cable connected to stacking port A of one switch must be connected to stacking port B of the adjacent switch.

  • Page 120: Redundant Stacking Cable Connection

    Stack Cabling Managing OmniSwitch 6450 Stacks Redundant Stacking Cable Connection OmniSwitch 6450 switches allow redundant stacking cable connections between the top-most and bottom- most switches in a stack. Note. For a stacked configuration to have effective redundancy, a redundant stacking cable must be installed between the upper-most and bottom-most switch in the chassis at all times.

  • Page 121: Checking Redundant Stacking Cable Status

    Managing OmniSwitch 6450 Stacks Stack Cabling Redundant stacking cables provide a form of dual redundancy. As shown in the figure above, the redun- dant cable allows traffic to flow in the event of a stacking link failure. The redundant cable also provides failover if a switch goes down within the stack.

  • Page 122: Slot Numbering

    Slot Numbering Managing OmniSwitch 6450 Stacks Slot Numbering For a stack of OmniSwitch 6450 switches to operate as a virtual chassis, each module in the stack must be assigned a unique slot number. To view the current slot assignments for a stack, use the show ni show module...

  • Page 123: Dynamic Slot Number Assignment

    Managing OmniSwitch 6450 Stacks Slot Numbering Dynamic Slot Number Assignment Dynamic slot number assignment occurs when there are no boot.slot.cfg files present in the switches’ /flash directories. This is the case for new, “out of the box,” switches that have not been previously booted.
  • Page 124 Slot Numbering Managing OmniSwitch 6450 Stacks If the switch with the lowest MAC address happens to be the bottom-most module in the stack, slot numbering will not resume from the top of the stack. Instead, the system software will select the second- ary module using the standard method (i.e., the switch connected to the primary’s stacking port A), then continue to number the stack from the bottom up.

  • Page 125: Manual Slot Number Assignment

    Managing OmniSwitch 6450 Stacks Slot Numbering Manual Slot Number Assignment To manually assign slot numbers to one or more modules in a stack, use the stack set slot command. This command writes slot information to the boot.slot.cfg file located in a switch’s /flash directory. It is this saved slot information that the switch will assume following a reboot.

  • Page 126: Reverting To The Dynamic Slot Numbering Model

    Slot Numbering Managing OmniSwitch 6450 Stacks When the stack comes up following the reboot, the manually-configured slot numbers display as follows: Slot 1 - Primary Slot 2 - Secondary Slot 3 - Idle Slot 4 - Idle Stack Numbering Before Manual Assignment The stack set slot command can also be used to manually correct duplicate saved slot assignments within the stack topology.

  • Page 127: Hot-Swapping Modules In A Stack

    Managing OmniSwitch 6450 Stacks Hot-Swapping Modules In a Stack Hot-Swapping Modules In a Stack As with chassis-based switches, NI modules within an OmniSwitch 6450 virtual chassis are hot-swappa- ble. NI modules are essentially those modules operating in the stack in idle mode. These modules can be removed from, or added to, an existing stack without disrupting other modules in the stack.

  • Page 128: Merging Stacks

    Hot-Swapping Modules In a Stack Managing OmniSwitch 6450 Stacks Merging Stacks Merging stacks involves connecting two or more operational stacks and attempting to reboot them as a single virtual chassis. In most cases, errors will result. To merge stacks without causing errors, select one stack that is to remain up and running and then add modules from the other stack(s) by following the steps below: Make sure all switches are running the same software version.

  • Page 129: Reloading Switches

    Managing OmniSwitch 6450 Stacks Reloading Switches Reloading Switches Reloading is essentially a soft boot of a switch. Users can reload stacked modules operating in any role— i.e., primary, secondary, idle, and pass-through. Refer to the sections below for more information. Reloading the Primary Management Module If the switch with the primary management role is reloaded, the switch with the secondary role automati- cally takes over primary management functions.
  • Page 130 Reloading Switches Managing OmniSwitch 6450 Stacks If there are only two switches in the stack, the switch that was reloaded (the former primary) assumes the secondary role when it comes back up. In this stack of two OmniSwitch 6450 switches, the slot Primary - Slot 1 1 switch is the primary management module.

  • Page 131: Reloading The Secondary Management Module

    Managing OmniSwitch 6450 Stacks Reloading Switches Reloading the Secondary Management Module If the switch with secondary management role is reloaded, the idle switch with the lowest slot number will automatically assume the secondary role. The reloaded switch (the former secondary) will assume an idle role when it comes back up.
  • Page 132 Reloading Switches Managing OmniSwitch 6450 Stacks If there are only two switches in the stack, the switch that was reloaded (the former secondary) resumes the secondary role when it comes back up. In this stack of two OmniSwitch 6450 switches, the slot Primary - Slot 1 1 switch is the primary management module.

  • Page 133: Reloading Switches With Idle Roles

    Managing OmniSwitch 6450 Stacks Reloading Switches Reloading Switches with Idle Roles Similar to reloading Network Interface (NI) modules on chassis-based switches, modules operating in idle status within a stack can be reloaded via the CLI. Note. Any traffic being passed on the module’s Ethernet will be interrupted during the reboot. Other modules within the stack will continue to operate without interruption.

  • Page 134: Reloading All Switches In A Stack

    Reloading Switches Managing OmniSwitch 6450 Stacks Reloading All Switches in a Stack Reloading all switches in the stack is essentially a full reboot of the virtual chassis. This can be useful in restoring a stack’s previously configured topology—i.e., the stack’s saved slot numbers and management roles.
  • Page 135 Managing OmniSwitch 6450 Stacks Reloading Switches No Switches In the Stack Have Saved Slot Information If a full reload is issued and no switches in the stack have unique slot numbers, slot numbers will be assigned beginning with the switch with the lowest MAC address. (This can occur if the boot.slot.cfg file has been deleted from each switch’s /flash directory—e.g., by issuing the stack clear slot command for all...

  • Page 136: Avoiding Split Stacks

    Reloading Switches Managing OmniSwitch 6450 Stacks Avoiding Split Stacks The term “splitting” a stack refers to the creation of isolated modules within the virtual chassis. A split stack can result from the following conditions: Two or more non-adjacent switches are reloaded simultaneously •...

  • Page 137: Changing The Secondary Module To Primary

    Managing OmniSwitch 6450 Stacks Changing the Secondary Module to Primary Changing the Secondary Module to Primary OmniSwitch 6450 stacks allow users to manually force the secondary switch to assume the primary management role. This is referred to as “takeover.” The behavior of a takeover is similar to that of reload- ing the primary management module (see page 5-27).
  • Page 138 Changing the Secondary Module to Primary Managing OmniSwitch 6450 Stacks If there are only two switches in the stack, the former primary switch resumes the secondary role when it comes back up following the takeover. In this stack of two OmniSwitch 6450 switches, the slot Primary - Slot 1 1 switch is the primary management module.

  • Page 139: Synchronizing Switches In A Stack

    Managing OmniSwitch 6450 Stacks Synchronizing Switches in a Stack Synchronizing Switches in a Stack Management module synchronization refers to the process of copying all files in the /flash/working and /flash/certified directories of the primary management module to the /flash/working and /flash/certified directories of all the other switches in the stack.

  • Page 140: Stack Split Detection (Ssp)

    Stack Split Detection (SSP) Managing OmniSwitch 6450 Stacks Stack Split Detection (SSP) In the case of a stack split due to a stacking link failure or the failure of one of the stack elements, both of the resulting stacks could end up having the same system MAC and IP addresses. Since there is no communication between these individual stacks due to the stacking link failure they end up communicat- ing with the rest of the network devices using the same MAC and IP addresses.

  • Page 141: Basic Operation

    Managing OmniSwitch 6450 Stacks Stack Split Detection (SSP) Basic Operation When stack split detection is enabled, a proprietary protocol runs on a configured link aggregate to carry the stack information necessary for stack split detection. Stack elements share a link aggregate with an OmniSwitch that can act as a helper to assist in the stack split detection.
  • Page 142 Stack Split Detection (SSP) Managing OmniSwitch 6450 Stacks Use the stack split-protection guard-timer and the stack split-protection commands to configure the guard timer and enable/disable SSP. Automatic Recovery If the stacking link recovers and the sub-stack reconnects to the active stack the sub-stack will automati- cally reboot.

  • Page 143: Monitoring The Stack

    Managing OmniSwitch 6450 Stacks Monitoring the Stack Monitoring the Stack As shown in the previous sections, monitoring the current status and operation of all elements in a stack can help users avoid unexpected stack conditions. The table below includes CLI commands that are useful in monitoring stack conditions.
  • Page 144 Monitoring the Stack Managing OmniSwitch 6450 Stacks CLI Commands Supported on Both Primary and Secondary Management Modules Although most CLI commands are executed when logged into the switch with the primary management role, there is a group of commands that is supported when logged in to either the primary or secondary management module.

  • Page 145: Regulatory Compliance And Safety Information

    A Regulatory Compliance and Safety Information This appendix provides information on regulatory agency compliance and safety for the OmniSwitch 6450 switches. Declaration of Conformity: CE Mark This equipment is in compliance with the essential requirements and other provisions of Directive 2004/108/EC (EMC), 2006/95/EC (LVD), 91/263/EEC (Telecom Terminal Equipment, if applicable), 1999/5/EC (R&TTE, if applicable).

  • Page 146: China Rohs: Hazardous Substance Table

    对销售之日的所售产品,本表显示, 阿尔卡特朗讯公司供应链的电子信息产品可能包含这些物质。注意:在所售产 品中可能会也可能不会含有所有所列的部件。 This table shows where these substances may be found in the supply chain of Alcatel-Lucent electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 147 Regulatory Compliance and Safety Information China RoHS: Hazardous Substance Table Products are packaged using one or more of the following packaging materials: Corrugated Cardboard Corrugated Fiberboard Low-Density Polyethylene OmniSwitch 6450 Hardware Users Guide January 2015 page A-3...

  • Page 148: Waste Electrical And Electronic Equipment (Weee) Statement

    Waste Electrical and Electronic Equipment (WEEE) Statement Regulatory Compliance and Safety Information Waste Electrical and Electronic Equipment (WEEE) Statement The product at end of life is subject to separate collection and treatment in the EU Member States, Norway and Switzerland and therefore marked with the symbol: Treatment applied at end of life of the product in these countries shall comply with the applicable national laws implementing directive 2002/96EC on waste electrical and electronic equipment (WEEE).

  • Page 149: Standards Compliance

    Regulatory Compliance and Safety Information Standards Compliance Standards Compliance Safety Standards • UL 60950-1, 2nd Edition CAN/CSA-C22.2 No. 60950-1-07, 2nd Edition • EN 60950-1 with Amendment II • IEC 60950-1 2nd Edition • AS/NZS TS-001 and 60950, Australia • • UL-AR, Argentina TUV,UL-GS Mark, Germany •...

  • Page 150: Fcc Class A, Part 15

    Standards Compliance Regulatory Compliance and Safety Information FCC Class A, Part 15 This equipment has been tested and found to comply with the limits for Class A digital device pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful inter- ference when the equipment is operated in a commercial environment.This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions in this guide, may cause interference to radio communications.

  • Page 151: Korea Emissions Statement

    Regulatory Compliance and Safety Information Standards Compliance Korea Emissions Statement A 급 기기 ( 업무용 방송통신 기자재 ) Class A Equipment (Business equipment) This equipment is registered for Electromagnetic Conformity 이 기기는 업무용 (A 급 ) 전자파적합기기로서 판 Registration as business equipment (A), not home equipment. 매자...

  • Page 152: Translated Safety Warnings

    Translated Safety Warnings Regulatory Compliance and Safety Information Translated Safety Warnings Chassis Lifting Warning Two people are required when lifting the chassis. Due to its weight, lifting the chassis unassisted can cause personal injury. Also be sure to bend your knees and keep your back straight when assisting with the lift- ing of the chassis.

  • Page 153: Invisible Laser Radiation Warning

    Regulatory Compliance and Safety Information Translated Safety Warnings Invisible Laser Radiation Warning Lasers emit invisible radiation from the aperture opening when no fiber-optic cable is connected. When removing cables do not stare into the open apertures. In addition, install protective aperture covers to fiber with no cable connected.

  • Page 154: Proper Earthing Requirement Warning

    Translated Safety Warnings Regulatory Compliance and Safety Information Proper Earthing Requirement Warning To avoid shock hazard: The power cord must be connected to a properly wired and earth receptacle. • • Any equipment to which this product will attached must also be connected to properly wired recep- tacles.

  • Page 155: Read Important Safety Information Warning

    Regulatory Compliance and Safety Information Translated Safety Warnings Read Important Safety Information Warning This guide contains important safety information about which you should be aware when working with hardware components in this system. You should read this guide before installing, using, or servicing this equipment.

  • Page 156: Wrist Strap Warning

    Français: L'électricité statique (ESD) peut endommager les composants du commutateur. Pour cette raison Alcatel-Lucent joint à l'envoi du châssis un bracelet antistatique à brancher sur la prise mise à la terre située en bas à droite du commutateur. Vous devrez mettre ce bracelet avant toute intervention hard- ware.

  • Page 157: Instrucciones De Seguridad En Español

    Deseche las baterías usadas según las instrucciones del fabricante. Las instrucciones del fabricante son como sigue: Devuelva el módulo con la batería del litio a Alcatel-Lucent. La batería del litio será substitu- ida en la fábrica de Alcatel-Lucent.

  • Page 158: Advertencia Sobre Una Apropiada Conexión A Tierra

    Instrucciones de seguridad en español Regulatory Compliance and Safety Information Advertencia sobre una apropiada conexión a tierra Para evitar peligro de descargas: El cable de alimentación debe estar conectado a una toma de alimentación adecuadamente cableada • y con toma de tierra. Cualquier equipo al cual se conecte este producto debe estar también conectado a tomas de alimentación adecuadamente cableadas.
