- Page 1 060355-10 Rev. B May 2012 OmniSwitch 6250/6450 Transceivers Guide www.alcatel-lucent.com OmniSwitch 6250/6450 Transceivers Guide May 2012...
- Page 2 Failure to comply with these matrices is not guaranteed for proper performance and may result in voiding the warranty for the affected platforms. Copyright © 2012 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.
-
Page 3: Table Of Contents
SFP Transceiver Installation and Removal ..............1-3 Gigabit Ethernet Transceivers ..................1-5 100 Mbit Ethernet Transceivers ..................1-10 Dual-Speed Ethernet Transceivers ................1-14 10-Gigabit SFP+ Transceivers ..................1-15 Chapter 2 SFP Compatibility Matrix ..................1-18 OmniSwitch 6250 ......................1-18 OmniSwitch 6450 ......................1-19 OmniSwitch 6450 Transceivers Guide May 2012... - Page 4 Contents OmniSwitch 6450 Transceivers Guide May 2012...
-
Page 5: About This Guide
About This Guide This OmniSwitch Transceivers Guide provides specifications and compatibility information on the supported transceivers for the OmniSwitch 6250 and OmniSwitch 6450. Supported Platforms The information in this guide applies to the following products: • OmniSwitch 6250 • OmniSwitch 6450... -
Page 6: Who Should Read This Manual
Read this guide as soon as you are ready to integrate your OmniSwitch into your network and you are ready to provide connectivity using the supported transceivers. You should have already stepped through the first login procedures and read the brief software overviews in the appropriate OmniSwitch 6250/6450 Getting Started Guide and OmniSwitch 6250/6450 Hardware Guide. -
Page 7: Documentation Roadmap
CLI-to-MIB variable mapping information for all CLI commands supported by the switch. This guide can be consulted anytime during the configuration process to find detailed and specific information on each CLI command. OmniSwitch 6250/6450 Transceivers Guide May 2012 page vii... -
Page 8: Related Documentation
OmniSwitch 6250/6450 Transceivers Guide Includes transceiver specifications and product compatibility information. • Technical Tips, Field Notices Includes information published by Alcatel-Lucent’s Customer Support group. • Release Notes Includes critical open Problem Reports, feature exceptions, and other important information on the features supported in the current release and any limitations to their support. -
Page 9: Product Documentation
Support web page, you’ll be able to view and update any case (open or closed) that you have reported to Alcatel-Lucent’s technical support, open a new case or access helpful release notes, technical bulletins, and manuals. For more information on Alcatel-Lucent’s Service Programs, see our web page at service.esd.alcatel-lucent.com, call us at 1-800-995-2696, or email us at esd.support@alcatel-lucent.com. - Page 10 Technical Support About This Guide page x OmniSwitch 6250/6450 Transceivers Guide May 2012...
-
Page 11: Small Form-Factor Pluggables (Sfps)
“10-Gigabit SFP+ Transceivers” on page 1-15 For information on installing and managing OmniSwitch hardware, see the appropriate Hardware Users Guide. For information on OmniSwitch SFP compatibility, see “SFP Compatibility Matrix” on page 2-18. OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-1... -
Page 12: Sfp Msa Specification
For information on installing SFPs, refer to the documentation included with the transceiver. This diagram is a representation only; the physical appearance of the actual module may vary slightly. Small Form Factor Pluggable (SFP) page 1-2 OmniSwitch 6250/6450 Transceivers Guide May 2012... -
Page 13: Sfp Transceiver Installation And Removal
When inserting a SFP, be sure that the hinged face is closed. Slide the SFP straight into the slot until the module clicks firmly into place. SFP Module SFP - Hinged OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-3... - Page 14 Once disengaged, use the clip end of the ejector tool to carefully pull the transceiver straight out and away Ejector from the NI module. Dust Cover SFP - Ejector Button page 1-4 OmniSwitch 6250/6450 Transceivers Guide May 2012...
-
Page 15: Gigabit Ethernet Transceivers
Optical Power Output -9.5 to -3 dBm Receiver Sensitivity -20 dBm ∼ Transmission Distance 10 km Operating Temperature -40 ºC to 85 ºC / 0 ºC to 70 ºC Digital Diagnostic Monitoring Not Supported OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-5... - Page 16 1000Base-LH70 Fiber Type Wavelength 1550 nm Optical Power Output 0 to +5 dBm Receiver Sensitivity -22 dBm Transmission Distance ~70 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Supported page 1-6 OmniSwitch 6250/6450 Transceivers Guide May 2012...
- Page 17 Supported SFP-GIG-T Gigabit SFP Copper Transceiver. Connector Type RJ-45 Standards Supported 802.3z, SFP MSA Connections supported 10/100/1000Base-T Cable Type CAT5, CAT5e, CAT6 ∼ Transmission Distance 100 m Digital Diagnostic Monitoring Not Supported OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-7...
- Page 18 Average Power Output -9 to -3 dBm Receiver Sensitivity -19.5 dBm Transmission Distance ~10 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Supported Notes Designed for use with SFP-GIG-BX-D page 1-8 OmniSwitch 6250/6450 Transceivers Guide May 2012...
- Page 19 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610 Optical Power Output -2 to +3 dBm Receiver Sensitivity -24 dBm Transmission Distances ~62 km Operating Temperature -5 ºC to 70 ºC Digital Diagnostic Monitoring Not Supported OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-9...
-
Page 20: 100 Mbit Ethernet Transceivers
Average Power Output -14 to -8 dBm Receiver Sensitivity -32 dBm Transmission Distance ~20 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Supported Notes Designed for use with SFP-100-BX20LT page 1-10 OmniSwitch 6250/6450 Transceivers Guide May 2012... - Page 21 Average Power Output -14 to -8 dBm Receiver Sensitivity -32 dBm Transmission Distance ~20 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Supported Notes Designed for use with SFP-100-BXLC-D OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-11...
- Page 22 Fiber Type Wavelength (nm) 1310 nm Optical Power Output -15 to -8 dBm Receiver Sensitivity -34 dBm Transmission Distance ~15 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Not Supported page 1-12 OmniSwitch 6250/6450 Transceivers Guide May 2012...
- Page 23 Fiber Type Wavelength 1310 nm Optical Power Output -15 to -8 dBm Receiver Sensitivity -34 dBm Transmission Distances ~40 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Not Supported OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-13...
-
Page 24: Dual-Speed Ethernet Transceivers
Transmit: 1310 nm Receive: 1550 nm Average Power Output -9 to -3 dBm Receiver Sensitivity -18.7 dBm Transmission Distances ~ 10 km Operating Temperature 0 ºC to 70 ºC Digital Diagnostic Monitoring Not Supported page 1-14 OmniSwitch 6250/6450 Transceivers Guide May 2012... -
Page 25: 10-Gigabit Sfp+ Transceivers
10GBase-LR Fiber Type Wavelength 1310 nm Optical Power Output -8.2 to 0.5 dBm Receiver Sensitivity -12.6 dBm Transmission Distance ~ 10 km Operating Temperature 0 ºC to 70ºC Digital Diagnostic Monitoring Supported OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-15... - Page 26 10GBase-LRM Fiber Type Wavelength 1310 nm Optical Power Output -6.5 to .5 dBm Receiver Sensitivity -6.5 dBm Transmission Distance ~ 220 m Operating Temperature 0 ºC to 70ºC Digital Diagnostic Monitoring Supported page 1-16 OmniSwitch 6250/6450 Transceivers Guide May 2012...
- Page 27 10-Gigabit SFP+ Copper Transceiver. Connector Type Direct Attached Standards Supported 802.3ae Cable Length 60cm, 1m, 3m, 7m Wire Gauge 24AWG Bend Radius 1.25 in. Digital Diagnostic Monitoring Not Supported Check for availability of lengths. OmniSwitch 6250/6450 Transceivers Guide May 2012 page 1-17...
-
Page 28: Sfp Compatibility Matrix
OmniSwitch 6250 SFP Compatibility Matrix 2 SFP Compatibility Matrix OmniSwitch 6250 The following table shows the Ethernet transceiver configurations and the minimum release required for support on the OmniSwitch 6250: OS6250 SFP-GIG-SX 6.6.1 SFP-GIG-LX 6.6.1 SFP-GIG-LH40 6.6.1 SFP-GIG-LH70 6.6.1 SFP-GIG-EXTND 6.6.1... -
Page 29: Omniswitch 6450
1. 6450-U24 supports 10/100/1000 on user ports and combo ports. All models 1G/10G uplink ports and expansion modules support 1G speed. 2. Supported on 6450-U24 user ports and combo ports. Not supported on 1G/10G uplink ports or expan- sion modules. OmniSwitch 6250/6450 Transceivers Guide May 2012 page 2-19... - Page 30 OmniSwitch 6450 SFP Compatibility Matrix page 2-20 OmniSwitch 6250/6450 Transceivers Guide May 2012...
