Parameter list
Setup Screen
[SETUP] button
Setting
Value
Video
These are the video-related settings.
Input
Shows the HDMI Input screen.
Item
Upper row
HDMI
Middle row
Lower row
Still Image
–
Sets what happens when you switch the HDMI 4 video source (HDMI 4-1 through HDMI 4-4).
* If "HDCP" is enabled, the "Normal" operation is used, regardless of the setting.
Normal
HDMI4 Fast Switching
Fast
When there is no video input, this sets the image to show in the preview area of the multi-view screen.
When this is set to "Color Matte" or "Sample Image", you can check the screen layout even when there is no
video input.
* You can't output the "Color Matte" or "Sample Image" view.
HDMI No Signal Image
Black
Color Matte
Sample Image
Output
Format
–
HDMI 1, 2
–
USB
–
This sets the function for the [OUTPUT FADE] button when in PGM/PST mode.
* When in dual mode, the [OUTPUT FADE] button function is always "Fade", regardless of the setting.
Output Fade
(PGM/PST Mode)
Fade
Freeze
This selects the video to be output from the HDMI HD OUT jack.
* The same audio as the audio output from the MAIN connectors is outputted.
HDMI HD Output Bus
LCD Left
LCD Right
Cropping Guide
–
Audio
Configure the audio settings here.
Knob Assign
Input 5
Mic
5, Line 1, HDMI
Input 6
Mic
6, Line 2, USB
Others
0–127
Touch Beep
Internal Speaker
0–127
System
These settings configure the overall system settings for this unit.
Configures the system mode for this unit. The scene output method switches depending on the system mode.
PGM/PST
System Mode
Dual
Explanation
(bold text: default value)
HDMI 1–3, 4-1–4-4
HDMI 1–4
HDMI 1–4
4-1–4-4
Displays the Still Image screen (p. 37).
A black screen is shown when you switch between video sources (HDMI 4-1 through HDMI 4-4).
HDMI 4-1 through HDMI 4-4 input
other video sources are temporarily shut off.
The video sources (HDMI 4-1 through HDMI 4-4) switch without interruption. With this setting, the
presence of a video signal is recognized quicker than with the "Normal" setting.
HDMI 4-1 through HDMI 4-4 input
Shows a black image.
Shows a single-color image. The color differs for each layer.
Shows the sample image for the scene.
* You can't change or edit the sample image.
Displays the Video Output Setup screen (p. 35).
Fades the audio and program out video in/out.
Temporarily freezes (pauses) the program output video (freeze function).
Outputs the same video as the left monitor on this unit.
Outputs the same video as the right monitor on this unit.
Displays the Video Output Setup screen (p. 35).
Sets the audio source to be controlled by the INPUT [5] knob.
Sets the audio source to be controlled by the INPUT [6] knob.
Sets the volume of the operating sound you hear when touching the built-in monitor.
* The touch operating sound is output from the internal speakers. You must turn up the volume on the
internal speakers using the "Internal Speaker" parameter to hear the touch operating sound.
Adjusts the volume of the built-in speakers.
* The touch operating sound for the built-in monitor, as well as the same audio signal as the audio
from the PHONES jack are output from the internal speakers.
Selects the next scene to be program output (preset scene) and switches the scene for program
output by means of the take operation.
* You can add mix and wipe effects that are applied when switching between scenes.
Use the left-right monitors to respectively select the scene to output for programs 1 and 2. You can
output two different scenes at the same time.
* Scene switching is always performed as a freeze-frame cut.
Explanation
Displays the Video Input Setup screen (p. 35).
Shows the input video.
Displays information about the incoming video (format, size, etc.).
Selects the video source for HDMI 4.
state: Only the selected video source is shown, and the inputs for
state: All video sources are input.
Multi-view screen
Preview area
Preview area
33
