Reference Manual
Version 1.5 and later
Contents
Menu List (Setup Screen) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
System (Video, Audio, and Unit) Settings . . . . . . . . . . . . . . . . . . . . . . 2
AUTO MIXING Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ECHO CANCEL Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
MEMORY SELECT Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MEMORY LOAD Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audio Channel 1-4 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Audio Channel 5/6 and 7/8 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Settings for Main Output Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
BUS SELECT Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AUDIO FOLLOW Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HDMI Audio Channel 1- 4 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 12
USB Input/Output Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
USB FROM PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
USB TO PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
USER Button Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MUTE SELECT Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SOLO SELECT Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
USER Button Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
AUTO SCAN Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MEMORY LOAD SW Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MUTE GROUP Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SOLO GROUP Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
GPO Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
RS-232 Command Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specification of the RS-232 Connector . . . . . . . . . . . . . . . . . . . . . . . 19
Overview of Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Received Commands (Controller g VR-4HD) . . . . . . . . . . . . . . . . . . 20
Sent Commands (VR-4HD g Controller) . . . . . . . . . . . . . . . . . . . . . . 21
Control Using the TALLY/GPIO Connector . . . . . . . . . . . . . . . . . . . . . . . 22
Specification of the TALLY/GPIO Connector . . . . . . . . . . . . . . . . . . . 22
Inputting a Control Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Outputting a Tally Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Outputting a Control Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
MIDI Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
