Removal and replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
CAUTION:
Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the tablet or void the warranty.
CAUTION:
This tablet does not have user-replaceable parts. Only HP authorized service providers should
perform the removal and replacement procedures described here. Accessing the internal part could damage
the tablet or void the warranty.
Component replacement procedures
NOTE:
Details about your tablet, including model, serial number, product key, and length of warranty, are on
the service tag at the bottom of the tablet. See
NOTE:
HP continually improves and changes product parts. For complete and current information on
supported parts for your tablet, go to http://partsurfer.hp.com, select your country or region, and then follow
the on-screen instructions.
There are as many as 49 screws that must be removed, replaced, and/or loosened when servicing Authorized
Service Provider only parts. Make special note of each screw size and location during removal and replacement.
Kickstand
Description
Kickstand
Before removing the kickstand, follow these steps:
1.
Shut down the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2.
Disconnect all external devices connected to the tablet.
3.
Disconnect the power from the tablet by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
Remove the kickstand:
CAUTION:
Before turning the tablet upside down, make sure the work surface is clear of tools, screws, and any
other foreign objects. Failure to follow this caution can result in damage to the display panel.
1.
Position the tablet with the display panel side down and the bottom edge toward you.
2.
Swing the kickstand (1) into the released position.
3.
Remove the four Torx4 M2.0×2.5 screws (2) that secure the kickstand to the hinges.
4.
Slide the kickstand (3) back to release it from the hinges.
Labels on page 17
for details.
Spare part number
L03259-001
