8. Configure the cFP-1808
Launch Measurement & Automation Explorer (MAX) to configure the cFP-1808.
For information about configuring the cFP-1808 in software, refer to the
Measurement & Automation Explorer Help for FieldPoint (Start»Programs»
National Instruments»FieldPoint»FieldPoint Help).
Compact FieldPoint Safety Information
The following section contains important safety information that you must follow
when installing and using Compact FieldPoint products.
Do not operate Compact FieldPoint products in a manner not specified in the user
manual or operating instructions. Misuse of the product can result in a hazard. You
can compromise the safety protection built into the product if the product is
damaged in any way. If the product is damaged, return it to National Instruments
for repair.
Do not substitute parts or modify Compact FieldPoint products. Use the products
only with the modules, accessories, and cables specified in the installation
instructions.
You must connect the protective earth (PE) ground terminal on the cFP-1808 to the
system safety ground. The backplane PE ground terminal has the following
symbol stamped beside it: . Connect the backplane PE ground terminal to the
system safety ground using 14 AWG (1.6 mm) wire with a ring lug. Use the
5/16 in. panhead screw shipped with the backplane to secure the ring lug to the
backplane PE ground terminal.
