104.78 mm
(4.1 in.)
63.50 mm
127.00 mm
(2.5 in.)
(5.0 in.)
22.23 mm
(0.9 in.)
Caution
described in this document. If you decide to use a custom mounting
solution, make sure that the screws you use are short enough to fit in the
holes in the backplane. The screw holes are 5 mm (0.2 in.) deep.
cFP-1808 Quick Start Guide
NI recommends that you use one of the mounting systems
440.94 mm
(17.4 in.)
