FieldPoint
FP-AI-112 and cFP-AI-112
16-Channel, 16-Bit Analog Input Modules
These operating instructions describe how to install and use the
FP-AI-112 and cFP-AI-112 analog input modules (referred
to inclusively as the [c]FP-AI-112). For information about
configuring and accessing the [c]FP-AI-112 over a network, refer
to the user manual for the FieldPoint network module you are
using.
Features
The [c]FP-AI-112 is a FieldPoint analog input module with the
following features:
•
16 analog voltage input channels
Eight voltage input ranges: 0–1 V, 0–5 V, 0–10 V, ±60 mV,
•
±300 mV, ±1 V, ±5 V, and ±10 V
•
16-bit resolution
•
50 and 60 Hz filter settings
•
250 V
CAT II continuous channel-to-ground isolation,
rms
verified by 2,300 V
•
–40 to 70 °C operation
•
Hot swappable
Installing the FP-AI-112
The FP-AI-112 mounts on a FieldPoint terminal base (FP-TB-x),
which provides operating power to the module. Installing the
FP-AI-112 onto a powered terminal base does not disrupt the
operation of the FieldPoint bank.
Operating Instructions
,1 minute dielectric withstand test
rms
Advertisement
Table of Contents
Related Manuals for National Instruments FieldPoint FP-AI-112
Summary of Contents for National Instruments FieldPoint FP-AI-112
- Page 1 [c]FP-AI-112 over a network, refer to the user manual for the FieldPoint network module you are using. Features The [c]FP-AI-112 is a FieldPoint analog input module with the following features: • 16 analog voltage input channels Eight voltage input ranges: 0–1 V, 0–5 V, 0–10 V, ±60 mV,...
- Page 2 1. Slide the terminal base key to either position X (used for any module) or position 1 (used for the FP-AI-112). 2. Align the FP-AI-112 alignment slots with the guide rails on the terminal base. 3. Press firmly to seat the FP-AI-112 on the terminal base. When the FP-AI-112 is firmly seated, the latch on the terminal base locks it into place.
- Page 3 5 cFP Backplane 3 cFP Controller Module Figure 2. Installing the cFP-AI-112 Wiring the [c]FP-AI-112 The FP-TB-x terminal base has connections for each of the 16 input channels and for an optional external power supply to power field devices. The cFP-CB-x connector block provides the same connections.
- Page 4 Table 1 lists the terminal assignments for the signals associated with each channel. The terminal assignments are the same for the FP-TB-x terminal bases and the cFP-CB-x connector blocks. Table 1. Terminal Assignments Terminal Numbers Channel FP-AI-112 and cFP-AI-112 ni.com...
- Page 5 FieldPoint bank. Measuring Voltage with the [c]FP-AI-112 Figure 3 shows how to connect a voltage source without an external power supply to one channel of the [c]FP-AI-112. Input Circuitry Voltage >100 MΩ...
-
Page 6: Input Ranges
You can select a fundamental frequency of 50, 60, or 500 Hz. At the 50 and 60 Hz settings, the [c]FP-AI-112 applies 95 dB of rejection at the fundamental frequency and at least 60 dB of rejection at each of the harmonics. -
Page 7: Status Indicators
Status Indicators The [c]FP-AI-112 has two green status LEDs, POWER and READY. After you insert the [c]FP-AI-112 into a terminal base or backplane and apply power to the connected network module, the green POWER indicator lights and the [c]FP-AI-112 informs the network module of its presence. -
Page 8: Isolation And Safety Guidelines
[c]FP-AI-112 to any circuits that may contain hazardous voltages. This section describes the isolation of the [c]FP-AI-112 and its compliance with international safety standards. The field wiring connections are isolated from the backplane and the inter-module communication bus. -
Page 9: Specifications
• Do not use the [c]FP-AI-112 as the only isolating barrier between human contact and working voltages higher than 250 V •... - Page 10 25 °C........... 400 pA typ, 1 nA max 70 °C........... 3 nA typ, 15 nA max A characteristic of an ADC in which the digital code output always increases as the value of the analog input to it increases. FP-AI-112 and cFP-AI-112 ni.com...
- Page 11 For example, for the ±10 V input range, full scale is 10 V and ±0.01% of full scale is 1 mV. Gain error drift........±20 ppm/°C Offset error drift........ 6 µV/°C © National Instruments Corp. FP-AI-112 and cFP-AI-112...
- Page 12 Physical Characteristics Indicators .......... Green POWER and READY indicators Weight FP-AI-112........142 g (5.0 oz) cFP-AI-112......... 113 g (4.0 oz) Power Requirements Power from network module .... 350 mW Isolation Voltage Channel-to-ground isolation Continuous ......... 250 V Installation Category II Dielectric withstand....
- Page 13 Emissions.......... EN 55011 Class A at 10 m; FCC Part 15A above 1 GHz Immunity........... EN 61326:1997 + A2:2001, Table 1 CE, C-Tick, and FCC Part 15 (Class A) Compliant For EMC compliance, operate this device with Note shielded cabling. © National Instruments Corp. FP-AI-112 and cFP-AI-112...
- Page 14 Certification column. Mechanical Dimensions Figure 5 shows the mechanical dimensions of the FP-AI-112 installed on a terminal base. If you are using the cFP-AI-112, refer to the Compact FieldPoint controller user manual for the dimensions and cabling clearance requirements of the Compact FieldPoint system.
-
Page 15: Where To Go For Support
National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United... - Page 16 FieldPoint™, National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents .
