Quick Start Guide
Compact FieldPoint cFP-1808
What You Need to Get Set Up
• cFP-1808 Network Interface
• Mounting hardware (DIN rail,
panel-mount, or rack-mount
accessory)
• I/O module(s)
• Connector blocks and/or cables
1. Mount the cFP-1808
You can mount the cFP-1808 on a panel or in a standard 19 in. rack. Before using
either of these mounting methods, record the serial number from the back of the
cFP-1808.
Each set of mounting instructions in this document includes an instruction to
connect the protective earth (PE) ground terminal on the cFP-1808 to the system
safety ground. The PE ground terminal has the following symbol stamped beside
it: . Connect the PE ground terminal to the system safety ground using 14 AWG
™
• Ethernet or serial cable
• 11–30 VDC power supply
• Accessories: Ethernet cable,
number 2 Phillips screwdriver
• PC running Windows
• FieldPoint software 4.1.2 or later
