Table 1. DIP Switch Positions and Corresponding Serial Baud Rates (Continued)
DIP Switches 3–5
The switch settings determine the baud rate when the cFP-1808 is powered on. If
you change the switch settings while the cFP-1808 is on, you must turn it off, then
on again, to apply the new settings and change the baud rate.
The serial interface on the cFP-1808 always uses the following parameters: 1 start
bit, 8 data bits, 1 stop bit, and no parity.
© National Instruments Corporation
Serial Baud Rate
19,200
38,400
DIP Switches 3–5
11
Serial Baud Rate
57,600
115,200
