FP-DI-330 and cFP-DI-330
Eight-Channel Universal Digital Input Module
These operating instructions describe how to install and use the
National Instruments FP-DI-330 and cFP-DI-330 digital input
modules (referred to inclusively as the [c]FP-DI-330). For
information about configuring and accessing the [c]FP-DI-330
over a network, refer to the user manual for the FieldPoint network
module you are using.
Features
The [c]FP-DI-330 is a FieldPoint digital input module with the
following features:
•
Eight digital input channels
•
Universal inputs that work with any voltage from 5 V TTL
level up to 250 VDC/VAC
•
Compatibility with sourcing, sinking, or power-sensing
applications
•
On/Off LED indicators
•
250 V
CAT II continuous channel-to-ground isolation,
rms
verified by 2,300 V
•
–40 to 70 °C operation
•
Hot swappable
Installing the FP-DI-330
The FP-DI-330 mounts on a FieldPoint terminal base (FP-TB-x),
which provides operating power to the module. Installing the
FP-DI-330 onto a powered terminal base does not disrupt the
operation of the bank.
Operating Instructions
, 1 minute dielectric withstand test
rms
Advertisement
Table of Contents
Related Manuals for National Instruments FieldPoint FP-DI-330
Summary of Contents for National Instruments FieldPoint FP-DI-330
- Page 1 FP-DI-330 and cFP-DI-330 Eight-Channel Universal Digital Input Module These operating instructions describe how to install and use the National Instruments FP-DI-330 and cFP-DI-330 digital input modules (referred to inclusively as the [c]FP-DI-330). For information about configuring and accessing the [c]FP-DI-330 over a network, refer to the user manual for the FieldPoint network module you are using.
- Page 2 To install the FP-DI-330, refer to Figure 1 and complete the following steps: 1. Slide the terminal base key to position X. 2. Align the FP-DI-330 alignment slots with the guide rails on the terminal base. 3. Press firmly to seat the FP-DI-330 on the terminal base. When the module is firmly seated, the terminal base latch locks it into place.
- Page 3 ; and a common terminal, COM. All eight COM terminals are internally connected to each other and to the C terminals. All eight V terminals are internally connected to each other and to the V terminals. © National Instruments Corp. FP-DI-330 and cFP-DI-330...
- Page 4 You can use a 5–250 VDC external power supply to power field devices. Connect the positive lead of the external power supply to both V terminals and the negative lead to both C terminals. Ensure that the current through both V terminals can never exceed 2 A. Install 2 A maximum, fast-acting fuses between the external power supply and the V terminals.
- Page 5 Circuitry Device (NPN) (Ch 4) Sourcing- Input Output (Ch 4) Circuitry Device (PNP) (Ch n ) Input Switch (Ch n ) Circuitry To Next Channel [c]FP-DI-330 Figure 3. Connecting Devices to the [c]FP-DI-330 © National Instruments Corp. FP-DI-330 and cFP-DI-330...
- Page 6 Connecting a Switch to the [c]FP-DI-330 You can connect limit or control switches to the [c]FP-DI-330. Connect a power supply to the V and C terminals of the [c]FP-DI-330. Connect the IN and the V terminals to the switch. 5–250 V External –...
- Page 7 , IN , IN , and COM terminals to the sinking-output device. 5–250 V External – Power Supply Sinking- Input Output Circuitry Device (NPN) [c]FP-DI-330 Figure 7. Wiring the [c]FP-DI-330 to a Sinking-Output Device © National Instruments Corp. FP-DI-330 and cFP-DI-330...
- Page 8 If the sinking-output device is connected to a power supply, connect the power supply to the IN terminal of the [c]FP-DI-330. Sinking- Input Output Circuitry Device – (NPN) [c]FP-DI-330 Figure 8. Wiring the [c]FP-DI-330 to an Externally Powered Sinking-Output Device Connecting a Load to the [c]FP-DI-330 If you want to use the [c]FP-DI-330 to sense the power that is applied to a load, connect the IN...
-
Page 9: Sensing Dc Voltages
When an external device applies a voltage between 1 V and the minimum ON-state voltage across the input terminals, the channel may or may not register an ON condition. © National Instruments Corp. FP-DI-330 and cFP-DI-330... -
Page 10: Status Indicators
The AC smoothing filter shown in Figure 10 ensures that the channel remains ON if the signal frequency is higher than 50 Hz and the signal voltage is higher than the minimum ON state. Refer to the Specifications section for more information about minimum ON-state voltages and digital logic levels. - Page 11 250 V Working voltage is defined as the signal voltage plus the common-mode voltage. Common-mode voltage is the voltage of the module with respect to ground. © National Instruments Corp. FP-DI-330 and cFP-DI-330...
-
Page 12: Specifications
• Operate the [c]FP-DI-330 only at or below Pollution Degree 2. Pollution Degree 2 means that only nonconductive pollution occurs in most cases. Occasionally, however, a temporary conductivity caused by condensation must be expected. • Do not operate FieldPoint products in an explosive atmosphere or where there may be flammable gases or fumes. - Page 13 Operating temperature ...... –40 to 70 °C Storage temperature ......–55 to 85 °C Humidity ........... 10 to 90% RH, noncondensing Maximum altitude......2,000 m; at higher altitudes the isolation voltage ratings must be lowered Pollution Degree ....... 2 © National Instruments Corp. FP-DI-330 and cFP-DI-330...
- Page 14 Shock and Vibration These specifications apply only to the cFP-DI-330. NI recommends Compact FieldPoint if your application is subject to shock and vibration. Operating vibration, random (IEC 60068-2-64)......10–500 Hz, 5 g Operating vibration, sinusoidal (IEC 60068-2-6)........ 10–500 Hz, 5 g Operating shock (IEC 60068-2-27)......
- Page 15 Compact FieldPoint controller user manual for the dimensions and cabling clearance requirements of the Compact FieldPoint system. 107.19 mm (4.22 in.) 109.5 mm (4.31 in.) 91.44 mm (3.60 in.) Figure 12. FP-DI-330 Mechanical Dimensions © National Instruments Corp. FP-DI-330 and cFP-DI-330...
-
Page 16: Where To Go For Support
FieldPoint™, National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents .
