FieldPoint
FP-DO-400 and cFP-DO-400
Eight-Channel, 5–30 V Digital Output Module
These operating instructions describe how to install and use the
National Instruments FP-DO-400 and cFP-DO-400 digital output
modules (referred to inclusively as the [c]FP-DO-400). For
information about configuring and accessing the [c]FP-DO-400
over a network, refer to the user manual for the FieldPoint network
module you are using.
Features
The [c]FP-DO-400 is a FieldPoint digital output module with the
following features:
•
Eight digital output channels
•
Sourcing outputs supply up to 1.5 A per channel, 8 A
module
•
Compatible with voltages from 5 to 30 VDC
•
On/Off LED indicators
•
2,300 V
rms
•
–40 to 70 °C operation
•
Hot swappable
•
User-configurable startup states
Installing the FP-DO-400
The FP-DO-400 mounts on a FieldPoint terminal base (FP-TB-x),
which provides operating power to the module. Installing the
FP-DO-400 onto a powered terminal base does not disrupt the
operation of the FieldPoint bank.
Operating Instructions
transient overvoltage protection
2
per
Advertisement
Table of Contents
Related Manuals for National Instruments FieldPoint FP-DO-400
Summary of Contents for National Instruments FieldPoint FP-DO-400
- Page 1 FP-DO-400 and cFP-DO-400 Eight-Channel, 5–30 V Digital Output Module These operating instructions describe how to install and use the National Instruments FP-DO-400 and cFP-DO-400 digital output modules (referred to inclusively as the [c]FP-DO-400). For information about configuring and accessing the [c]FP-DO-400 over a network, refer to the user manual for the FieldPoint network module you are using.
- Page 2 To install the FP-DO-400, refer to Figure 1 and complete the following steps: 1. Slide the terminal base key to either position X, used for any module, or position 4, used for the FP-DO-400 module. 2. Align the FP-DO-400 alignment slots with the guide rails on the terminal base.
- Page 3 ), one supply terminal (V ), and two common terminals (COM). All eight channels are referenced to the COM terminals. The V and V terminals are all internally connected, as are the C and COM terminals. © National Instruments Corp. FP-DO-400 and cFP-DO-400...
- Page 4 Use a 5–30 VDC external power supply for the output channels. The power supply must provide enough current to power all of the loads on the output channels, up to 1.5 A per channel. Connect the external power supply to multiple V and V terminals and to multiple C and COM terminals as needed to ensure that the maximum current through any terminal is 2 A or less.
-
Page 5: Digital Output Circuit
In the following example, three channels supply 1.5 A each and one channel supplies 1 A: ≤ 8 A (1.5 A) + (1.5 A) + (1.5 A) + (1 A) © National Instruments Corp. FP-DO-400 and cFP-DO-400... - Page 6 The outputs must not be short-circuited to the Caution potential of the C or COM terminals (the negative voltage of the external supply). Short circuits damage the [c]FP-DO-400 output channels. Check all wiring carefully before applying power. In the ON state, the effective resistance between the output (V ) is 0.3 Ω.
- Page 7 Inductive Load Figure 4. Digital Output Circuit (External Power Supply Not Shown) The [c]FP-DO-400 contains flyback diodes to prevent excessively high voltage from damaging the module. National Instruments still recommends using an external protection circuit across any inductive load.
-
Page 8: Status Indicators
Status Indicators Figure 5 shows the status indicator LEDs on the [c]FP-DO-400. Figure 5. Status Indicators The [c]FP-DO-400 has two green status LEDs, POWER and READY. After you install the FP-DO-400 onto a terminal base or the cFP-DO-400 onto a backplane and apply power to the connected network module, the green POWER indicator lights and the [c]FP-DO-400 informs the network module of its presence. - Page 9 If the FieldPoint product is not certified for operation in hazardous locations, do not operate it in an explosive atmosphere or where there may be flammable gases or fumes. © National Instruments Corp. FP-DO-400 and cFP-DO-400...
-
Page 10: Specifications
Specifications These specifications are typical for the range –40 to 70 °C unless otherwise noted. Output Characteristics Number of channels......8 Output type ........Sourcing Voltage range ........5–30 VDC Output impedance at 10–30 V ..0.3 Ω (0.3 V drop at 1 A) Maximum output current at 10–30 V Per channel Temperature Ranges... - Page 11 Operating vibration, sinusoidal (IEC 60068-2-6)........ 10–500 Hz, 5 g Operating shock (IEC 60068-2-27)......50 g, 3 ms half sine, 18 shocks at 6 orientations; 30 g, 11 ms half sine, 18 shocks at 6 orientations © National Instruments Corp. FP-DO-400 and cFP-DO-400...
- Page 12 Safety This product is designed to meet the requirements of the following standards of safety for electrical equipment for measurement, control, and laboratory use: • IEC 61010-1, EN 61010-1 • UL 3121-1, UL 61010C-1 • CAN/CSA C22.2 No. 1010.1 For UL, hazardous location, and other safety certifications, refer to the product label or to ni.com Electromagnetic Compatibility...
-
Page 13: Mechanical Dimensions
Compact FieldPoint controller user manual for the dimensions and cabling clearance requirements of the Compact FieldPoint system. 107.19 mm (4.22 in.) 109.5 mm (4.31 in.) 91.44 mm (3.60 in.) Figure 6. FP-DO-400 Mechanical Dimensions © National Instruments Corp. FP-DO-400 and cFP-DO-400... -
Page 14: Where To Go For Support
Where to Go for Support For more information about setting up the FieldPoint system, refer to these National Instruments documents: • FieldPoint network module user manual • Other FieldPoint I/O module operating instructions • FieldPoint terminal base and connector block operating... - Page 15 FieldPoint™, National Instruments™, NI™, and ni.com™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents .
