Media Gateway 3500
Installation, Operation, and Maintenance
Version 3.0
Document #: LTRT-90704 Rev 003
Document # LTRT-90704
October 2005

Advertisement

Table of Contents
loading

Related Manuals for Nortel Media Gateway 3500

Summary of Contents for Nortel Media Gateway 3500

  • Page 1 Media Gateway 3500 Installation, Operation, and Maintenance Version 3.0 Document #: LTRT-90704 Rev 003 Document # LTRT-90704 October 2005...

  • Page 3: Table Of Contents

    2.1 Media Gateway 3500 Hardware Configuration ........17 2.1.1 Media Gateway 3500 + TP-1610 Board Configuration......17 2.1.2 Media Gateway 3500 Accessories Kit ..........18 2.2 Front and Back Views of the Media Gateway 3500 ........18 2.3 The Chassis....................19 2.3.1 Earthing Requirements................ 20 2.3.2 Power Requirements ................
  • Page 4 DiffServ Priorities................. 54 4.2.4 IEEE 802.1p QoS/CoS Layer 2 Traffic Prioritization ......54 4.2.5 Security Profiles................... 55 4.2.6 Defining IP Parameters - Media Gateway 3500 + TP-1610 Configuration ..................55 4.3 Environmental Requirements ..............56 4.3.1 NEBs Environmental Requirements ............ 56 4.3.2 Temperature ..................
  • Page 5 10 SC Software Backup/Restore Procedures ............97 10.1 Creating the SC Software Backup............97 10.2 Restoring SC Software from Backup ..........98 11 Cabling the Media Gateway 3500 ..............101 11.1 Connecting the ES/4411 IP Network Cabling ........101 11.2 TP-1610 Configuration - Cabling the Trunk Connectors ....103 11.3 External Alarm Indicator Connections..........103...
  • Page 6 12.9.1.3 Media (RTP/RTCP) Security ..............133 12.9.1.4 SSH ....................... 134 12.9.1.5 SSL/TLS ....................134 12.9.2 Media Gateway 3500 Security Configuration ........134 12.9.2.1 Enable Secure Mode................134 12.9.2.2 Software Re-Installation ................ 135 12.9.2.3 Enable Secure Mode Examples............135 12.9.2.4 Disable Secure Mode ................137 12.9.2.5 Software Re-Installation ................
  • Page 7 Installation, Operation, Maintenance Manual Contents 15.4 Performing the Online Software Upgrade ........168 15.4.1 Configure Telnet/FTP password of the Media Gateway....169 15.4.2 Starting the Online Software Upgrade Wizard........169 15.4.2.1 Welcome Questionnaire ................ 172 15.4.2.2 Upgrading the Secondary SC Board............. 173 15.4.2.3 OS Upgrade Phase for Version 2.1 to Version 3.0 Upgrade ....
  • Page 8 17.9 Simple Diagnostic Tool’s File............198 17.10 Useful Solaris™ Configuration Files ..........198 17.11 Information Needed when Contacting Technical Support ....198 18 Media Gateway 3500 Selected Functional Specifications ......201 19 Regulatory Information...................207 20 Appendix - Installing ES Board Software............211 20.1 Media Gateway 3500 Media Gateway Version 2.1......211 20.2 Troubleshooting .................212...
  • Page 9 Figure 1-1: Media Gateway Block Diagram....................16 Figure 2-1: Media Gateway 3500 + 1610 Configuration - Front View............18 Figure 2-2: Media Gateway 3500 + 1610 Configuration, DC Power - Back View........19 Figure 2-3: Media Gateway 3500 + 1610 Configuration, AC Power - Back View........19 Figure 2-4: Fan Tray Unit Panel and Alarm Indicators................23...
  • Page 10 Media Gateway 3500 Figure 24-1: Downloadable Conversion Utility Opening Screen ............224 Figure 24-2: Call Progress Tones Screen ................... 225 Figure 24-3: Voice Prompts Screen ....................226 Figure 24-4: Select Files Window......................227 Figure 24-5: File Data Window......................228 Figure 24-6: Trunk Traces Screen ...................... 230 Figure 24-7: UDP2File Utility Dialog Box ....................
  • Page 11 Table 4-6: DiffServ Priority Parameters....................54 Table 4-7: IEEE 802.1p Service Proirity Classes ...................54 Table 4-8: Security Profiles ........................55 Table 4-9: MAC Address and IP Address Registration for Media Gateway 3500 + TP-1610 Configuration.........................55 Table 4-10: NEBS Requirements ......................56 Table 4-11: Temperature Range ......................57 Table 4-12: Humidity Range........................57...
  • Page 12 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 13: Introductory Matter

    Related Documentation The documentation package contains the following publications: Media Gateway 3500 Product Description - contains the description of the product features, components, standard control protocols and management protocols (Document # LTRT-925xx). Media Gateway 3500 Installation, Operation & Maintenance Manual (this manual) - Version 3.0...
  • Page 14 Through the EMS, the system operator can also configure the Media Gateway 3500 to send all alarms set as they are to be handled according to manual or automatic rules. The manual is intended for System level operators who are to use the EMS.

  • Page 15: Introduction To The Media Gateway 3500

    Service Providers rapid time-to-market and reliable cost-effective deployment of next-generation networks. The Media Gateway 3500 is a robust, scalable and modular solution, designed for the carrier environment, matching the density requirements for medium deployments, while meeting Network Service Providers' demands for high availability, reliable new voice infrastructure networks.

  • Page 16: Figure 1-1: Media Gateway Block Diagram

    Media Gateway 3500 The block diagram of the Media Gateway options are illustrated in the figures below and depicts its functional internal engineering mechanisms. Figure 1-1: Media Gateway Block Diagram IP Network Gigabit Ethernet Gigabit Ethernet Uplink Uplink Power Power Entry...

  • Page 17: Hardware Overview

    2.1.1 Media Gateway 3500 + TP-1610 Board Configuration The table below details the components of the Media Gateway 3500 + TP-1610 board configuration. Table 2-1: Components of the Media Gateway 3500 + TP-1610 Board Configuration...

  • Page 18: Media Gateway 3500 Accessories Kit

    Media Gateway 3500 2.1.2 Media Gateway 3500 Accessories Kit Each Media Gateway 3500 is accompanied by an accessories kit, which includes: RS-232 Straight Cable for Console Terminal (not crossed-over) RS-232 Straight Cable for Ethernet Switch Console Terminal (not crossed-over) AC Power Cable (for AC configurations)

  • Page 19: The Chassis

    Installation, Operation, Maintenance Manual 2. Hardware Overview Figure 2-2: Media Gateway 3500 + 1610 Configuration, DC Power - Back View Figure 2-3: Media Gateway 3500 + 1610 Configuration, AC Power - Back View The Chassis The Media Gateway 3500 chassis complies with NEBS Level 3 requirements, and conforms to CompactPCI PICMG 2.0 standards.

  • Page 20: Earthing Requirements

    Do not depend on locknut-bushings and double-locknuts for bonding purposes. Use the earthing hardware provided with the chassis. 2.3.2 Power Requirements The Media Gateway 3500 chassis can be powered from either AC or DC sources. Table 2-3: Power Requirements Type Power Requirements...

  • Page 21: Power Consumption

    Installation, Operation, Maintenance Manual 2. Hardware Overview 2.3.2.1 Power Consumption 2.3.2.1.1 DC Input Power The average power consumption for a full complement of boards is approximately 460 watts (4 A at 115 VAC, 2 A at 230 VAC and 9.5 A at 48 VDC). Two Power Entry Modules (PEM), each containing two input terminals, are provided for DC connections on the rear of the chassis.

  • Page 22: Electro Magnetic Compatibility (Emc) Features

    2.4.1 Cooling System The Media Gateway 3500 components are cooled by a Fan Tray unit, located at the left of the card cage. The Fan Tray Unit draws air in through a perforated grill at the right side of the chassis.

  • Page 23: Advanced Power Module (Apm)

    The alarm indicators are connected to the fault detection and alarm system provided with the Media Gateway 3500. As needed, LEDs indicate critical, major or minor system faults as well as system and shelf alarms. Figure 2-4: Fan Tray Unit Panel and Alarm Indicators Version 3.0...

  • Page 24: Alarm Indicators

    Media Gateway 3500 2.4.4.1 Alarm Indicators The table below describes the chassis’ front panel alarm indicators. Table 2-4: Chassis Front Panel Alarm Indicators and Buttons Color Component Label Description Code Remarks LED 1 SYSTEM Indicates that the Green OK Default = Red...

  • Page 25: Media Gateway 3500 Boards

    Installation, Operation, Maintenance Manual 2. Hardware Overview Media Gateway 3500 Boards 2.5.1 The TP-1610 Board The TP-1610 board is a high-density, hot-swappable, compactPCI resource board with a capacity of 480 DS0 channels, supporting all necessary functions for voice, data and fax streaming over IP networks.

  • Page 26: Figure 2-5: 1610 Board, Panel View

    Media Gateway 3500 Figure 2-5: 1610 Board, Panel View Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 27: Figure 2-6: 1610 Rtm Panel With 2 Telco Connectors

    Installation, Operation, Maintenance Manual 2. Hardware Overview Figure 2-6: 1610 RTM Panel with 2 Telco Connectors Version 3.0 October 2005...
  • Page 28 Media Gateway 3500 Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 29: 50-Pin Telco Connector E1/T1/J1 Connections

    Installation, Operation, Maintenance Manual 2. Hardware Overview 2.5.1.1 50-pin Telco Connector E1/T1/J1 Connections The user’s 50-pin male connector on Trunks 1 to 8 is connected to the 50-pin female connector labeled E1/T1/J1 1 to 8. The user’s 50-pin male connector on Trunks 9 to 16 is connected to the 50-pin female connector labeled E1/T1/J1 9 to 16.

  • Page 30: Tp-1610 Board Panel Led Indicators

    Media Gateway 3500 2.5.1.2 TP-1610 Board Panel LED Indicators Refer to the tables below for LED indicator definitions. Table 2-6: Board Status LED Indicators Label Color Function FAIL Board failure (fatal error) Green Board initialization sequence terminated OK Bi-color Indicates the Active board...

  • Page 31: Sc (System Controller) Board

    Installation, Operation, Maintenance Manual 2. Hardware Overview Table 2-9: Ethernet Indicators Label Color Function LINK Green Ethernet link is active Yellow Packets running on Ethernet link (Receive or Transmit) 2.5.2 SC (System Controller) Board The System Controller (SC) is a Sun™ CompactPCI™ Single Board Computer (SBC), running on the Solaris™...

  • Page 32: Front Panel Ps2 Com Serial Port

    Media Gateway 3500 Figure 2-8: SC Panel 2.5.2.1 Front Panel PS2 COM Serial Port Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 33: Figure 2-9: Sc Front Panel Serial Port Connector

    Installation, Operation, Maintenance Manual 2. Hardware Overview The figure below displays the pin assignments for the front panel PS2 COM serial port. Figure 2-9: SC Front Panel Serial Port Connector 7 DCD 6 RTS 8 Shield GND 4 GND 5 RXD 3 TXD 2 CTS 1 DTR...

  • Page 34: System Controller Panel Indicators & Controls

    Doing so can cause file corruption and loss of system serviceability. Use the correct shutdown procedure described in Shutdown Procedures. These pushbuttons are for use by Nortel Technical Support personnel only. ABORT - Pressing the ABORT pushbutton halts the normal operation of the SC software back to the “OK Prompt”...

  • Page 35: Table 2-12: Rs-232 Console Pin Signal Interface

    Detecting the state of front chassis push-buttons Monitoring PEM status The SA RTMs are located in the rear cage of the Media Gateway 3500, in the respective slots 1 and 2, behind the SC boards in the front cage. These RTMs contain an RS-232 console port 9-pin female D-type connector (P2).

  • Page 36: Table 2-13: Sa Rtm Led Indicators

    Media Gateway 3500 Table 2-13: SA RTM LED Indicators Label Color Function FAIL Board failure (fatal error) Board initialization sequence terminated OK Green bi-color Indicates the Active board indicator Board initialization sequence terminated OK Yellow Yellow on indicates Standby board...

  • Page 37: Figure 2-10: Sa Rtm Panel

    Installation, Operation, Maintenance Manual 2. Hardware Overview Figure 2-10: SA RTM Panel Version 3.0 October 2005...

  • Page 38: Ethernet Switch Boards

    Media Gateway 3500 Ethernet Switch Boards WARNING To prevent broadcast storms, avoid external interconnection between the links of the two Ethernet Switches. Note: The Ethernet Switch boards are placed in slots 3 and 4 only. The ES/4411 Ethernet Switch board, based on CPC4411, complies with cPCI Extended Fabric Board standards utilizing a PICMG 2.16-compliant packet switching matrix onto a...

  • Page 39: Table 2-14: Rj-11 Console Port Pinout

    Installation, Operation, Maintenance Manual 2. Hardware Overview Table 2-14: RJ-11 Console Port Pinout RJ-11 PIN# Signal Name PC DB-9 Connector Version 3.0 October 2005...

  • Page 40: 4411 Panel Indicators

    Media Gateway 3500 Figure 2-11: ES/4411 Panel 2.6.1.1 ES/4411 Panel Indicators The status of the twenty-four switched Ethernet ports and the out-of-band management port is indicated by LEDs visible from the front panel. A green LED is used to indicate link and activity (transmit or receive), and a yellow LED is used to indicate the current port speed.

  • Page 41: Table 2-15: Port/Link Activity Indicators

    Installation, Operation, Maintenance Manual 2. Hardware Overview Table 2-15: Port/Link Activity Indicators Indicator Status Function Green Link exists No Link exists Flashing Green Activity (transmit or receive) Note 1: The 10/100 Base-TX ports flash the Activity indicator when there is transmit or receive activity.

  • Page 42: 4411 Physical Slots To Ethernet Port Correlation - Media Gateway 3500 + Tp-1610 Configuration

    Media Gateway 3500 Table 2-19: Ethernet Switch Hot-Swap Indicator Indicator Status State Indication Blue Board can be removed or inserted 2.6.1.2 ES/4411 Physical Slots to Ethernet Port Correlation - Media Gateway 3500 + TP-1610 Configuration Table 2-20: ES/4411 Physical Slots to Ethernet Port Correlation...

  • Page 43: 4411 Rtm

    The ES/4411 RTM is supplied with the ES/4411 board and allows connection from the Media Gateway 3500 to 10/100 Base-T external Ethernet equipment instead of or in addition to using fiber GbE equipment. The Ethernet Switch RTM allows access to five additional 10/100 MB ports of the Ethernet Switch board not utilized for Media Gateway 3500 board connections.

  • Page 44: Figure 2-12: Es/4411 Rtm Panel

    Media Gateway 3500 Figure 2-12: ES/4411 RTM Panel Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 45: Figure 2-13: Es/4411 Rtm F-Link Location

    Installation, Operation, Maintenance Manual 2. Hardware Overview 2.6.1.3.2 ES/4411 RTM F-Link Switch Settings The ES/4411 boards’ hardware configuration is changed in version 3.0 and requires the F-Link (Frabric to Frabric) switch located on the ES/4411 RTM (refer to the figure below) to be set correctly.

  • Page 47: Installation Process Flow

    Customers should prepare the site according to the requirements described in the Site Preparation section prior to the installation of the Media Gateway 3500 equipment. The Hardware Installation phase comprises unpacking the equipment, mounting the chassis on the rack, connecting network, console, power and earthing cables, as well as powering up the system and verifying that it is in working order.

  • Page 48: Figure 3-1: Installation Process Flow (Tp-1610 Configuration)

    Media Gateway 3500 Figure 3-1: Installation Process Flow (TP-1610 Configuration) START Install Install Configure Configure Prepare Configure Hardware Hardware Software Site (Cont.) (Cont.) Updating Initial Connecting Preparing Full Unpacking / Configuration PSTN Interface Getting Started Checking Files Provisioning Hardware &...

  • Page 49: Site Preparation

    The PC is used to install and configure the SC board software Telco Rack 19-inch rack can support up to 6 Media Gateway 3500s Screws and Washers Appropriate for installing Media Gateway 3500 chassis on rack Wrist Strap and banana plug For electrostatic discharge (ESD) connection or alligator clip...

  • Page 50: Electrical

    Provide sufficient capacity for the average power consumption for a full consumption complement of boards: Power consumption: Media Gateway 3500 chassis with maximum TP-1610 boards: 460 watts (4 A @ 115 VAC, 2 A at 230 VAC and 9.5 A at 48 VDC) For AC power...

  • Page 51: Cables

    RS-232 Cables For SA and ES Console Terminals (provided with the product) Fiber Optic and copper Cables The customer provides: For Media Gateway 3500 + PSTN: TP-1610 Configuration For NEBS GR-1088-CORE compliance use Shielded cables to connect to DS-1 and Ethernet ports For other installations then NEBS UTP cables may be used for DS-1 ports.

  • Page 52: Defining Ip Parameters

    However, the MAC Address field in the table below is provided for your convenience. Note: The PC should be in the same subnet as that of the Media Gateway 3500 components, that communicate with the PC. 4.2.1...

  • Page 53: Network Server Ip Addresses

    Installation, Operation, Maintenance Manual 4. Site Preparation 4.2.2 Network Server IP Addresses For the relevant Network Servers, prepare the following information: Table 4-5: Network Server IP Addresses Network Server IP Addresses Comment Up to 3 Syslog Version 3.0 October 2005...

  • Page 54: Diffserv Priorities

    Media Gateway 3500 4.2.3 DiffServ Priorities Use the following parameters for DiffServ Priorities. They should be taken from the Network configuration. Table 4-6: DiffServ Priority Parameters Diff Serv Class Protocol Group Diff Serv Priority Name Network Communications between network devices within one...

  • Page 55: Security Profiles

    Server IKE Pre-Shared Key IKE Encryption 4.2.6 Defining IP Parameters - Media Gateway 3500 + TP-1610 Configuration Table 4-9: MAC Address and IP Address Registration for Media Gateway 3500 + TP-1610 Configuration Slot Board Type MAC Address MAC Address IP Address...

  • Page 56: Environmental Requirements

    Media Gateway 3500 Environmental Requirements 4.3.1 NEBs Environmental Requirements The Media Gateway 3500 chassis mechanical envelope complies with the requirements of NEBS GR-63-CORE, Issue 2. The table below provides a list of the mechanical requirements which were imposed on the chassis design.

  • Page 57: Temperature

    Installation, Operation, Maintenance Manual 4. Site Preparation Presently, the system operation is guaranteed under the following conditions: 4.3.2 Temperature Table 4-11: Temperature Range Temperature Range for Operation C to +55 Recommended Ambient Temperature C to +30 4.3.3 Humidity Table 4-12: Humidity Range 5 to 90% Relative Humidity Range for Operation 70% (wet bulb)

  • Page 58: Rack Requirements

    Media Gateway 3500 4.3.7 Rack Requirements Table 4-15: Rack Requirements 19-inch Telco Rack As per GR-63-CORE Space Maintenance access 762 mm (2’ 6”) Wiring access 610 mm (2’) Interfacing with the IP Networks To ensure full high availability capabilities, one of methods detailed below must be incorporated into the network infrastructure.

  • Page 59: Method Two: One L-2 Switch With Two Vlans

    Installation, Operation, Maintenance Manual 4. Site Preparation This configuration is more economical when more than one Media Gateway 3500 is deployed at a single site. The local communication between multiple Media Gateway 3500s passes through the two interconnected L-2 switches while all external communication passes through ports to the external router.

  • Page 60: Clock Synchronization

    Media Gateway 3500 Clock Synchronization The Media Gateway 3500 Media Gateway can operate in either Non-Synchronized or Synchronized mode. 4.5.1 Clock Synchronization for PSTN Interfaces When connecting the gateway to PSTN network, the clock synchronization methods that should be applied for the PSTN trunks must be reviewed. Typically, the gateway can receive the synchronization clock from several sources as BITS (Building Integrated Timing Source), SETS (SDH Equipment Timing Source) or from regular E1/T1 trunks.

  • Page 61: Connections For The Synchronized Mode

    4.5.2 Connections for the Synchronized Mode In synchronized mode, the Media Gateway 3500 operates in synchronization with the PSTN equipment attached to the PSTN interfaces. It derives the synchronization timing from one of the E1 / T1 / J1 trunks and distributes the timing to all other synchronous interfaces in the system according to Bellcore GR-1244-CORE line-timing scheme.

  • Page 62: Figure 4-4: Synchronized Mode Connections Diagram

    Media Gateway 3500 Figure 4-4: Synchronized Mode Connections Diagram Primary synchronization bus Secondary synchronization bus Primary Secondary Master Slave Slave Master 1610 Board 1610 Board 1610 Board 1610 Board PSTN Trunks PSTN Trunks PSTN Trunks PSTN Trunks 1. Use qualified clock trunks as the clock reference to synchronize the gateway.
  • Page 63 Installation, Operation, Maintenance Manual 4. Site Preparation Reader’s Notes Version 3.0 October 2005...

  • Page 65: Unpacking/Checking Contents

    Open the protective plastic covering. Grasp the Media Gateway 3500 chassis with both hands and lift it from the carton. Place the Media Gateway 3500 chassis upright on a stable surface. Save the packaging material in case the equipment needs to be transported at a future time.
  • Page 66 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 67: Mounting The Chassis On A Rack

    The Media Gateway 3500 complies with Network Equipment Building System (NEBS) requirements for racks. The Media Gateway 3500 is provided with mounting flanges on either side of the front of the chassis, appropriate for standard 19-inch racks(provided by Customers). 23 inch racks are not supported by the Media Gateway 3500.

  • Page 68: Figure 6-1: Attaching The Chassis To The Rack

    Media Gateway 3500 To mount the chassis on a rack, take these 2 steps: Grasp the handles on either side of the chassis as well as on the base of the chassis. Lift it and fit it onto the rack.

  • Page 69: Figure 6-2: Chassis On The Rack - Front View

    Installation, Operation, Maintenance Manual 6. Mounting the Chassis on a Rack Figure 6-2: Chassis on the Rack - Front View Note: If you are using pre-installed support studs on the rack, lift the chassis and mount in place, over the installed studs. Place washers over the studs and secure the caps.
  • Page 70 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 71: Earthing

    The earth connection’s resistance must not be greater than 0.1 ohm. Verify that the rack’s earthing is properly done. Earthing provisions for the Media Gateway 3500 are located on the Power Entry Module (PEM) panel, as shown in the figure below. There are two earth connectors situated immediately to the right of each DC power connector or to the left of the AC power connector.

  • Page 72: Figure 7-2: Earthing Connections Chassis Rear Pem (Ac Version)

    Media Gateway 3500 Figure 7-2: Earthing Connections Chassis Rear PEM (AC Version) Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 73: Powering Up

    Check that the console is connected to the SA RTM that is to be the initial active SC board. Check that the SA RTM alarm cabling is secured to the Media Gateway 3500 chassis as well as to the external equipment.

  • Page 74: Connecting System Power

    Be sure to make the earth connection before connecting the power. Refer to' Earthing' on page 71. Figure 8-1: PS-2 Power Supply The Media Gateway 3500 chassis can be powered from either AC or DC sources. Caution Use EITHER the AC or the DC power supplies. NEVER MIX connectIing both types of power supplies in the same system, since chassis malfunction or permanent damage can result.

  • Page 75: Connecting Ac Power

    Installation, Operation, Maintenance Manual 8. Powering Up 8.2.1 Connecting AC Power A standard, properly earthed, socket and associated circuit breaker is provided on the rear of the chassis. A power cable is provided according to the customer’s local standard. Table 8-2: AC Power Cable Types Item Description A0539897...

  • Page 76: Connecting Dc Power

    Media Gateway 3500 To connect the AC power to the terminals, take the next 9 steps: If a UPS is included, verify that an AC power source with UPS is to be used (required for redundant system configurations). Verify that the circuit breaker in the electrical cabinet is sufficient to handle the power requirements.

  • Page 77: Figure 8-2: Dc Power Connections Redundant Pairs

    Installation, Operation, Maintenance Manual 8. Powering Up The rear of the chassis (refer to the figure below) is provided with redundant pairs of power inputs for DC. These pairs are marked J1 and J2. Each pair (the two input terminals marked J1 and the two input terminals marked J2) must be connected to a separate power source for the redundancy configuration to function correctly.

  • Page 78: Figure 8-3: Making The Dc Power Connections

    Media Gateway 3500 Repeat these steps for the connections on the second PEM. Figure 8-3: Making the DC Power Connections Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 79: Post-Power Connection Test Procedures Checklist

    Installation, Operation, Maintenance Manual 8. Powering Up Post-Power Connection Test Procedures Checklist To complete the installation up to this point, verify the next 5 items are correct: Verify that air is flowing out the air vents of the chassis by feeling the air flow at the vents.
  • Page 80 Media Gateway 3500 Table 8-3: Functional Checks on Component Indicators Functional Unit Indicator Indicator Status Description Fan Tray Unit All LEDs on; Not applicable in Version 1.2 APM Fan Tray FAULT Normally OFF Power Supply LED is Red if voltage to the fans is...
  • Page 81 Installation, Operation, Maintenance Manual 8. Powering Up Reader’s N otes Version 3.0 October 2005...

  • Page 83: Configuring Sc Software For The First Time

    Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time Configuring SC Software for the First Time The System Controller (SC) software is pre-installed on the SC board. You are required to configure the preinstalled Sun™ Solaris ™ 2.8/2.9 configuration files and SC software. Note 1: Solaris™...

  • Page 84: Defining Ip Parameters

    IP address of NTP server (if exists). NTP server is server providing time of day Note: The PC should be in the same subnet as that of the Media Gateway 3500 components. Configuring the NTP Server When using an NTP server to synchronize the date and time of the SC-2 boards, configure the Solaris™...

  • Page 85: Configuring The Sc Boards

    Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time Using the RS-232 terminal from the console connected to the SC board, access the HyperTerminal tool through: [Start]◊[Programs]◊[Accessories]◊[Communications]◊ [HyperTerminal] Open the console connection using the following parameters: Bits per second: 9600 Data bits: Parity:...

  • Page 86: Updating The Basic Sc Network Configuration

    Media Gateway 3500 9.5.1 Updating the Basic SC Network Configuration To update the basic SC Network configuration, take these 10 steps: At the RS-232 console terminal, If you are prompted, at the log-on prompt, clientxxx console, log on using the default username: root and password: root.

  • Page 87: Performing The Basic Sc Configuration

    Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time [clientxx]: SC1 SC name (node name) Enter the correct IP address for the SC board and press Enter. [10.6.8.33]: 10.2.229.253 IP address Enter the correct IP address for the Default router and press Enter. [10.6.0.1]: 10.2.0.1 Default router Enter the correct IP address for the Subnet and press Enter.

  • Page 88: Basic Sc Configuration On The First Sc Board

    Media Gateway 3500 During the basic configuration of the first SC board, the IP addresses you have defined are entered at the appropriate prompts. 9.5.2.1 Basic SC Configuration on the First SC Board To perform the basic SC configuration on the first SC board, take these 11 steps: Follow the configuration scripts shown in the example below.
  • Page 89 NTP server IP [10.2.229.57]: At the Enable Security prompt, to enable security, enter 1. To disable Security, enter 0. For more information refer to 'Media Gateway 3500 Security Technology' on page Enable Security (0-no, 1-yes) [0]: You are prompted to enter the SC Root Password and the passwords for SNMP Read and Write Community.
  • Page 90 Media Gateway 3500 SC Root Password [leave unchanged]: ****** SNMP Read Community [leave unchanged]: ****** SNMP Write Community [leave unchanged]: ****** A summary of the settings is displayed. ---------------------------------------------- Summary: Global IP Address: 10.1.2.3 Master SC IP Address: 10.1.1.1 (sc1) Redundant SC IP Address: 10.6.8.29 (sc2)
  • Page 91 Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time >>> Make backup of deleted file /etc/rc3.d/S76snmpdx ... >>> Make backup of deleted file /etc/init.d/init.snmpdx ... >>> Remove /usr/lib/smpdx ... >>> Make backup of deleted file /usr/lib/snmp/snmpdx ... >>>...
  • Page 92 Media Gateway 3500 When installing software on the first SC board, type n and press Enter. Note: For Redundant systems with tow SC boards, DO NOT reboot the SC boards until after both are configured. For Simplex configurations with only one SC board: If your hardware configuration contains only one SC board, reboot now and confirming the reboot command when prompted.

  • Page 93: Basic Sc Configuration On The Second Sc Board

    Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time 9.5.2.2 Basic SC Configuration on the Second SC Board To perform the basic SC configuration on the second SC board, take these 10 steps: Follow the configuration scripts shown in the example below. Example of Part 1 of the basic configuration process: Entered text is shown in bold and the IP addresses are assumed for the purposes of this example.
  • Page 94 Media Gateway 3500 Product Type 2 (mediant5000) Call Control Proxy Type 0 (noProxy) Trunk Protocol 0 (e1) VOP Board Type 1 (TP1610) ------------------------------------------------ [y]: y Start configuring (y/n) The following is displayed: >>> Update /etc/inet/inetd.conf file ... >>> Restore file /etc/inet/inetd.conf from the backup ...

  • Page 95: Software Testing

    Installation, Operation, Maintenance Manual 9. Configuring SC Software for the First Time >>> Configure crontab ... >>> Make backup of modified file /var/spool/cron/crontabs/root >>> get current crontab configuration ... >>> add cleanlogs job and statistics job to crontab ... >>> reload crontab configuration ... >>>...
  • Page 96 Media Gateway 3500 Note: If the Ping has not received the proper response, check the physical connections to the network. Using Telnet, access each SC board and run the command: tools d The Analytical tool runs various test. Verify that the test results are all OK.

  • Page 97: Sc Software Backup/Restore Procedures

    Installation, Operation, Maintenance Manual 10. SC Software Backup/Restore Procedures SC Software Backup/Restore Procedures 10.1 Creating the SC Software Backup An offline backup of the System Controller (SC) software should be made at the following times: After completing the initial installation and configuration After making any change in the SC configuration Before performing a software upgrade download (this is to be sure that an up-to-date backup is indeed available should any complication occur as the result of the software...

  • Page 98: Restoring Sc Software From Backup

    Media Gateway 3500 The Full Backup procedure is activated. You are prompted to confirm the action. Type y and press Enter. ---------------- Full Backup ----------- This tool will create a copy of complete software installation including configuration database. You must run this tool only on ACTIVE SC !!!!! Make a backup (y/[n]) ? y You are prompted to accept the default backup file name (Project.backup.tar) or type...
  • Page 99 Installation, Operation, Maintenance Manual 10. SC Software Backup/Restore Procedures page 83.) Use ftp to copy the tar file from its safekeeping location outside of the SC board to the SC board. At the prompt, type tools tg rs and press Enter. The Restore procedure is activated. You are prompted to choose from the two types of backups.
  • Page 100 Media Gateway 3500 Repeat steps 1 to 10 for the second SC board. Startup the system either using the EMS (refer to EMS documentation) or by typing the command at the Telnet prompt, tools tg up. You are prompted to confirm this command.

  • Page 101: Cabling The Media Gateway 3500

    To assure full high-availability capabilities, the configuration of the interface to the IP backbone must include certain redundant features from which two separate fiber optic cables are incoming to the Media Gateway 3500 Media Gateway. For more information on, refer to the section below.

  • Page 102: Table 11-1: Ip Separation And Es/4411S Port Allotment

    Media Gateway 3500 step: Connect to the ports on the ES/4411 RTM according to your OAM, Control and Management IP Separation configuration. (Refer to the table below.) When connecting the fiber optic cables to port 25, be sure to make a crossover connection between the TX and RX.

  • Page 103: Tp-1610 Configuration - Cabling The Trunk Connectors

    To connect the trunk span cabling, take this step: On each of the TP-1610 RTMs, behind the TP-1610 boards, connect the E1/T1/J1 cables to the Media Gateway 3500 E1/T1/J1 interfaces. The user’s 50-pin male connector of Trunks 1 to 8 is connected to the 50-pin female connector labeled E1/T1/J1 1 to 8.

  • Page 104: Figure 11-1: Normal Logic Alarm Connection Diagram

    Media Gateway 3500 Figure 11-1: Normal Logic Alarm Connection Diagram Normal Logic Connection SA-1 slot 1 TELCO Alarm Equipment SA-1 slot 2 Figure 11-2: Inverse Logic Alarm Connection Diagram Inverse Logic Connection SA-1 slot 1 TELCO Alarm Equipment SA-1 slot 2 Plug-in the terminal block into the PCB connector.

  • Page 105: Operating The Media Gateway Using The Ems

    (OAM&P) of MG 3500 media gateways. For users who chose to operate the Media Gateway 3500 without the EMS, information on getting started with MIBs is available in 'Appendix - Getting Started with MIBs' on page 211.

  • Page 106: Figure 12-1: Ems Regions Screen

    The figure below shows The EMS Regions screen with the path, Globe>Frankfurt selected in the Status pane. Figure 12-1: EMS Regions screen The figure below shows the EMS with a graphic representation of the Media Gateway 3500 (path, Globe>Pars>10.7.9.71) displayed in the Status pane. Installation, Operation, Maintenance Manual...

  • Page 107: Figure 12-2: Ems - Main Screen, Media Gateway Displayed

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Figure 12-2: EMS - Main Screen, Media Gateway Displayed Version 3.0 October 2005...

  • Page 108: Ems Architecture Overview

    Media Gateway 3500 The figure below shows EMS trunk parameters provisioning screen for board # 1. Figure 12-3: Trunk Parameters Provisioning Screen 12.1 EMS Architecture Overview Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 109: Basic Media Gateway Configuration In The Ems

    EMS integrated in a network system. Figure 12-4: Media Gateway Management System Architecture Note: The figure above depicts the Media Gateway 3500 Media Gateways. The diagram is representative as it applies to all Media Gateway products. 12.2...

  • Page 110: Performance Monitoring

    Media Gateway 3500 For instructions on configuring the Media Gateway, refer to the EMS User's manual section, Configuring the Media Gateway 3500 Media Gateway. Follow the steps for adding/removing, locking/unlocking and provisioning a Media Gateway. Refer to EMS User's manual section, Monitoring Status Panes.

  • Page 111: Real-Time Performance Monitoring

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS 12.3.1 Real-Time Performance Monitoring Real-time performance monitoring provides EMS users with the ability to perform high frequency polling of various system parameters. To select an entity to poll, take these 2 steps: Navigate to the entity according to regular EMS navigation concepts and from the Performance Monitoring menu in the Info pane, select the Display Real Time PMs option (refer to the figure below).

  • Page 112: Viewing Historical Data

    Media Gateway 3500 Users can open up to five separate real-time graphs in the same client application. In each graph, you can simultaneously view up to 5 parameters of the same Media Gateway or compare the same parameters over different Media Gateways.

  • Page 113: Media Gateway Board Redundancy

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS green when the operational state is normal blue/orange/yellow/red when operations is affected by a fault according to its alarm severity. 12.4.1 Media Gateway Board Redundancy To set a Media Gateway board as the redundant board, right-click on the desired board and from the popup menu, select the Make Board Redundant option.

  • Page 114: Sc Redundancy

    Media Gateway 3500 IN the EMS, in addition to the status display of the Ethernet Switch boards, the user is notified by the “operational info” alarm trap issued from the Active SC announcing the message, “Network port 0 failed, start using network port 1”. In addition, the Ethernet Switch board is displayed as yellow indicating the appropriate “suspect”...

  • Page 115: Configuring Clock Control

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Clock synchronization is the mechanism of setting trunks clocks to be the same. Two slots (each populated by a TP board) are used as reference clock source. Clock synchronization operates as follows: Each of the 16 trunks in each TP board can be configured with provisioning parameter tgTrunkClockPriority (refer to the Element Management System User’s Manual,...
  • Page 116 Media Gateway 3500 When at least one Clock Slot Ref is set to any slot other than 0, the media gateway is set to SYNC working mode. Note: The Clock Slot Ref must refer to a slot containing a Media Gateway Board.

  • Page 117: Clock Synchronization Configuration Limitations For Tp-1610 Configurations

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS 12.5.3 Clock Synchronization Configuration Limitations for TP-1610 Configurations When working with a redundant system scheme, there are a few limitation that require note. Generally, the following clock synchronization configurations are supported: •...

  • Page 118: Configuring The Ip Addresses

    Media Gateway 3500 To achieve clock synchronization, a minimum of 2 TP-1610 boards only are required: • NONE sync mode must be defined in chassis • All connected trunks are set as clock masters on the connected equipment • Each trunk group is always synchronized by an external source...

  • Page 119: Figure 12-9: Static Route Table Screen

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS To configure the IP address for each of the Media Gateway boards, take these 3 steps: In the EMS, lock the Media Gateway. In the Subnet Separation screen, do one of the following: If you require a single subnet, mark the Single Subnet for all media gateway checkbox and enter the IP addresses for the following: Global IP Address...

  • Page 120: Auxiliary Files

    User Defined and Call Progress Tones together is 64. The MG 3500 sample configuration files supplied by Nortel can be used to construct your own file. The Call Progress Tones and User-Defined Tones file used by the MG 3500 is a binary file with the extension “.dat”.

  • Page 121: Format Of The Call Progress Tones Section In The Auxiliary Source File

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS tone.ini file (supplied with the tone.dat file as part of the software package on the CD accompanying the MG 3500) in any text editor, modify it, and convert the modified tone.ini back into a binary tones.dat file using the DConversion Utility supplied with the MG 3500 software package.
  • Page 122 Media Gateway 3500 parameter is relevant only in case the tone is not Amplitude Modulated. • High Freq Level [-dBm] - Generation level. 0 to -31 dBm. The value should be zero (0) for a single tone. This parameter is relevant only in case the tone is not Amplitude Modulated.

  • Page 123: Format Of The User Defined Tones Section

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Note 1: When defining the same frequencies for both a continuous tone and a cadence tone, the Signal On Time parameter of the continuous tone should have a value that is greater than the Signal On Time parameter of the cadence tone.

  • Page 124: Default Template For Call Progress Tones

    Media Gateway 3500 (0) for a single tone. Default Duration [msec] - The default duration (in 1 msec units) of the generated tone. 12.7.1.3 Default Template for Call Progress Tones The MG 3500 is initialized with the default Call Progress Tones configuration. To change one of the tones, edit the default call progress txt file.
  • Page 125 Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Table 12-1: Default Call Progress Tones [NUMBER OF CALL PROGRESS TONES] Number of Call Progress Tones=9 #Ringback Tone Type=2 [CALL PROGRESS TONE #3] Tone Form = 2 (Cadence) Low Freq [Hz]=440 High Freq [Hz]=0 Low Freq Level [-dBm]=16 (-16dBm)

  • Page 126: Modifying The Call Progress Tones File

    Media Gateway 3500 Table 12-1: Default Call Progress Tones [NUMBER OF CALL PROGRESS TONES] Number of Call Progress Tones=9 #Confirmation tone Tone Type=8 [CALL PROGRESS TONE #7] Tone Form = 2 (Cadence) Low Freq [Hz]=350 High Freq [Hz]=440 Low Freq Level [-dBm]=20 (-20dBm)
  • Page 127 Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Tone Form = 1 Low Freq [Hz]=440 High Freq [Hz]=0 Low Freq Level [-dBm]=10 (-10dBm) High Freq Level [-dBm]=0 First Signal On Time [10msec]=300; the dial tone is detected after 3 sec Users can specify several tones of the same type using Tone Type definition.

  • Page 128: Converting A Modified Cpt Ini File To A Dat File With The Download Conversion Utility

    Media Gateway 3500 12.7.1.5 Converting a Modified CPT ini File to a dat File with the Download Conversion Utility After modifying the original CPT ini file (supplied with the MG 3500's software package), you can use the Download Conversion Utility to convert the modified file into a dat binary file.
  • Page 129 Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Note 1: The maximum PRT buffer size is 1 MB. Note 2: If the same tone type was defined as PRT and as Call Progress Tone or User-Defined Tone, the MG 3500 plays it using the PRT module. Version 3.0 October 2005...

  • Page 130: Setting Diffserv Priorities

    12.8 Setting DiffServ Priorities The Media Gateway 3500 supports up to 5 DiffServ Priority Classes. All of the supported protocols are mapped within these 5 classes according to packet-loss impact, acceptable delay and jitter. You can set the priority per DiffServ class in the EMS DiffServ Priorities screen.

  • Page 131: Table 12-2: Diffserv Class Name And Protocol Group Assignments

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Table 12-2: DiffServ Class Name and Protocol Group Assignments Tolerance to: Protocol Group Target Applications and Services Loss Delay Jitter Premium Telephony service like RTP media, T.38 Fax over IP, Very Low Very Low Very Low...

  • Page 133: Media Gateway 3500 Security Technology

    The IKE protocol (Internet Key Exchange) is responsible for obtaining the IPSec encryption keys and encryption profile (known as IPSec Security Association). IPSec is used by the Media Gateway 3500 to assure confidentiality, authentication and integrity for the following media types: •...

  • Page 134: Ssh

    SSL (the Secure Socket Layer), also known as TLS (Transport Layer Security), is the method used to secure the Media Gateway 3500 's Media Gateway Boards Web server and telnet. The SSL protocol provides confidentiality, integrity and authenticity of the Web server.

  • Page 135: Software Re-Installation

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS Run installation script "perl /sc_install.pl" Choose option "3 – Change installed configuration" Select "Enable Security – yes" Provide IKE pre-shared key for the EMS server Change root password to your own selection Modify SNMP read/write community strings On the Secondary SC board Run installation script "perl /sc_install.pl"...
  • Page 136 Media Gateway 3500 ------------------------------------------------ Configuration Summary: ------------------------------------------------ Global SC IP Address 10.7.9.242 Master SC IP Address 10.7.13.45 Redundant SC IP Address (or 1.1.1.1 if none) 10.7.13.94 EMS Server IP Address 10.7.6.8 NTP Server IP Address 0.0.0.0 Enable Security 1 (yes)

  • Page 137: Disable Secure Mode

    Installation, Operation, Maintenance Manual 12. Operating the Media Gateway Using the EMS 12.9.2.4 Disable Secure Mode • To disable Secure Mode, take these 5 steps: Connect to both SC boards via Secure Shell (SSH) Stop software on both SC boards – "tools tg dn" On the Primary SC board: •...
  • Page 138 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 139: Testing The Installed System

    Installation, Operation, Maintenance Manual 13. Testing the Installed System Testing the Installed System After the hardware installation process is complete, software is configured, and the EMS has been configured, perform a test to verify that each board is operating. • To ping the SC boards from the PC, take these 3 steps: From the Start menu, select RUN and at the command prompt, enter cmd.
  • Page 140 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 141: Hardware Replacement Procedures

    2 steps: Locate the ESD (electrostatic discharge) connections on the Media Gateway 3500 chassis. Refer to the diagrams in 'Front and Back Views of the Media Gateway 3500' on page 18. Attach a wrist strap for electrostatic discharge (ESD) and connect it to an ESD connection on the chassis using a banana plug or an alligator clip.

  • Page 142: Sc Board Replacement Procedure

    It is imperative to cover all unoccupied slots in the front cage of the Media Gateway 3500 chassis and all unoccupied slots in the rear cage of the Media Gateway 3500 chassis with blank panels to maintain a high, internal airflow. See the current release notes for more information before changing any configuration.

  • Page 143: Figure 14-3: Red Ejector Buttons On A Board

    Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures Note 1: In a Redundant configuration, should a primary SC board fail before a faulty secondary SC board has been replaced, replace and configure the SC board to be initially active first and then do the second SC board.to install the SC software.

  • Page 144: Installing The Solaris™ 9 Os

    Nortel recommends using the EMS server as the Install Server. Note: The Install Server must reside on the same LAN with Media Gateway 3500 (i.e., it must be connected to the same Ethernet Switch. The installation is to be performed on the SC board while it resides in the Media Gateway 3500 chassis.

  • Page 145: Preparing The 'Install Image

    Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures 14.2.1.2 Preparing the 'Install Image' To prepare the 'Install Image', take these 5 steps: In the Install Server's CD-ROM drive (the server used by the EMS is recommended), insert the Solaris™ 9 OS 'Install Image' CD. Open a terminal (via Telnet or X).

  • Page 146: Installing The Sc Software

    Media Gateway 3500 EMS-Server8:/ [root] => cd /jumpstart/Solaris_9_904_v1.0 EMS-Server8:/ /jumpstart/Solaris_9_904_v1.0 [root] => ./add_client.sh sc_name sc_ip sc_mac Via the RS232 console connection on the SC board, copy the new firmware from the 'Install Image' to the local hard disk. client224:~# ~ => mount –F nfs ems_ip:jumpstart /mnt client224:~# ~ =>...

  • Page 147: Sc Installation Package

    SC Installation Package The SC installation package is provided on Media Gateway 3500 System Software Installation CD included in the accessory kit accompanying the Media Gateway 3500 . The following are the software components on the CD: Table 14-1: SC Installation Package Files...

  • Page 148: Redundant Configuration - Installing The Sc Software

    ~> dir sc_software.tar.gz.gz Use the ftp command to access the sun system on the SC board. Enter the default host name and IP address of the SC board provided by Nortel. ~> ftp <sc default IP address> Connected to sc.
  • Page 149 Unpack package version information... >>> unpacking version information (this takes around 10 sec)... >>> done Found the following installation package: ---------------------------------------- Media Gateway 3500 Version : 3.0.25 ---------------------------------------- When you are asked if you want to install, enter y. [n]: y Do you want to install (y/n) Unpack version-specific installation script...
  • Page 150 Media Gateway 3500 You are prompted to install either the Master or Secondary SC. Type 1 to select the Secondary SC. If you install Master SC you should configure it now. If you install Secondary SC you should copy configuration from Master SC.
  • Page 151 Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures NTP Server IP Address 1.1.1.1 Enable Security 0 (no) SC Root Password ****** SNMP Read Community ****** SNMP Write Community ****** Product Type Call Control Proxy Type 0 (noProxy) Trunk Protocol 0 (e1) VOP Board Type 1 (TP-1610) ------------------------------------------------...
  • Page 152 Media Gateway 3500 >>> Make record of new file /etc/init.d/pwd ... >>> Make record of new file /etc/rc3.d/S91pwd ... >>> Configure NTP server ... >>> Make backup of modified file /var/spool/cron/crontabs/root >>> get current crontab configuration ... >>> No NTP server defined ...

  • Page 153: Media Gateway Board Replacement Procedure

    Are you sure (n/y) 14.3 Media Gateway Board Replacement Procedure In the event of a Media Gateway board failure, the Media Gateway 3500 automatically notifies users with an alarm. Replace the failed board as soon as possible to restore the system.
  • Page 154 Media Gateway 3500 With the black ejector/injector latches in the open (pulled out) position, insert the board in the slot, aligning the board on the grooves on each end. Ease the board all the way into the slot until the ejector/injector latches touch the chassis.
  • Page 155 Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures To cable the TP-1610 RTM, take these 2 steps: On the TP-1610 RTM, attach the Telco cables. Tightly fasten the screws at both ends of the Telco cables. Version 3.0 October 2005...

  • Page 156: Ascertaining The Mac Addresses For The Tp-1610

    Media Gateway 3500 14.3.2 Ascertaining the MAC Addresses for the TP-1610 Each TP-1610 board contains two MAC addresses, known as first (located in the lower section of the installed board) and second (located in the upper section of the installed board) illustrated in the figure below.

  • Page 157: Sa Rtm Replacement Procedure

    Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures 14.4 SA RTM Replacement Procedure To remove an SA RTM board from the chassis, take these 5 steps: Remove the connected cables. Unfasten the screws on the plate of the board. Press the two red ejector buttons. Pull on the two ejector/injector latches and ease out the board from the slot.
  • Page 158 Media Gateway 3500 steps: Hold the board Horizontal with the top of the board pointed upward. With the black ejector/injector latches in the open (pulled out) position, insert the board in the slot, aligning the board on the grooves on each side.

  • Page 159: Power Supply Module Replacement

    Installation, Operation, Maintenance Manual 14. Hardware Replacement Procedures In the EMS, unlock the Ethernet Switch board of which the RTM has been replaced. For more information refer to the Element Management System User’s Manual, Document #: LTRT-910xx. In the EMS, verify that the Ethernet Switch board is enabled. In the EMS Main screen, Status pane, double click on the Ethernet Switch board of the RTM that has been replaced.

  • Page 160: Replacing The Fan Tray Unit

    Verify that the fan is functioning correctly by putting your left hand over the grill on the left side of the Media Gateway 3500 chassis (when facing the front cage), and your right hand over the grill on the right side. Your left hand should feel a reasonably strong suction of the air drawn in by the fan.

  • Page 161: Replacing Air Filters

    Verify that the fan tray unit is functioning correctly by putting your left hand over the grill on the left side of the Media Gateway 3500 chassis (when facing the front cage), and your right hand over the grill on the right side. Your left hand should feel a reasonably strong suction of the air drawn in by the fan.
  • Page 162 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 163: Software Upgrade

    Installation, Operation, Maintenance Manual 15. Software Upgrade Software Upgrade Online Software Upgrade may be performed on both Redundant systems (with 2 SC boards available) and Simplex systems (with 1 SC board available). Online Software Upgrade on a Redundant system is described below. For Online Software Upgrade on Simplex systems, refer to page 185.

  • Page 164: Site Preparation

    CD-ROM drive (optional) We recommend using EMS server as the “Installation Server”. However, if connection between the EMS server and the Media Gateway 3500 chassis is not fast enough, a separate machine should be used as “Installation Server”. If it is possible, we recommend placing the “Installation Server” in the same subnet with the Media Gateway 3500 chassis.

  • Page 165: Tm Os Image

    In order to load the installation image on Installation Server, take these 4 steps: Insert the Nortel CD with the corrent Installation Image into the CD-ROM drive. Connect to the Installation Server via Telnet or RS-232 terminal as the root user.

  • Page 166: Changing Network Configuration Of Installation Server

    Media Gateway 3500 15.3.1.3 Changing Network Configuration of Installation Server If you change network configuration of the Installation Server (it's IP address, netmask or default gateway) you must re-configure installed Solaris OS images. To re-configure installed Solaris OS image, take these steps:...

  • Page 167: Preparing The Ethernet Switch Boards

    Installation, Operation, Maintenance Manual 15. Software Upgrade 15.3.2 Preparing the Ethernet Switch Boards Ethernet Switch boards should have F-Link jumper in 'enabled' position. Although you may alter F-Link configuration during Online Software Upgrade, we recommend to prepare/verify F-Link configuration prior to starting Online Software Upgrade. Note that only version 2.1 with "Mode 4"...

  • Page 168: Performing The Online Software Upgrade

    EMS-Server8:/ [root] => ./rm_install_client [SC1_hostname] EMS-Server8:/ [root] => ./rm_install_client [SC2_hostname] Note that path to the ./rm_install_client script may differ, depending on the Solaris OS image version. If you are not sure how to unconfigure Jumpstart server, contact Nortel support. 15.4...

  • Page 169: Configure Telnet/Ftp Password Of The Media Gateway

    Installation, Operation, Maintenance Manual 15. Software Upgrade 15.4.1 Configure Telnet/FTP password of the Media Gateway In the MG Tree to the left, select the Media Gateway on which maintenance action is required. Right click selected Media Gateway and choose Details option in the popup menu. Change "Telnet Password"...

  • Page 170: Figure 15-1: Maintenance Actions Icon And Popup Menu

    Media Gateway 3500 Figure 15-1: Maintenance Actions Icon and Popup Menu Select the Sw Upgrade option. The Files Management screen appears. Figure 15-2: Files Management Screen In the Files Manager screen, select the version file to be upgraded to and loaded to the device and click OK.
  • Page 171 Installation, Operation, Maintenance Manual 15. Software Upgrade The Online Software Upgrade Wizard GUI includes Wizard Stages screen section and a 'Summary Table' screen section. The Summary Table includes a summary of the Request / Response messages exchanged between the EMS server and each of the SC boards during the upgrade process.

  • Page 172: Welcome Questionnaire

    Media Gateway 3500 15.4.2.1 Welcome Questionnaire The Welcome Questionnaire includes basic questions regarding the software upgrade process. In this screen, configure the following parameters: Graceful Shutdown Period (sec) - the amount of time allowed for calls to end before performing the upgrade on an individual Media Gateway board . During this period, the Media Gateway board accepts no new calls, and at the close of this period, any remaining calls are dropped.

  • Page 173: Upgrading The Secondary Sc Board

    Installation, Operation, Maintenance Manual 15. Software Upgrade 15.4.2.2 Upgrading the Secondary SC Board In the first stage, the secondary (Standby) SC board's software is upgraded. When upgrade on this board is completed, a switchover action occurs which exchanges Active/Standby status between the SC boards. The secondary SC board becomes the Active board and the primary SC board becomes the Standby SC board.

  • Page 174: Figure 15-5: Software Upgrade In Process, Includes Solaris

    Media Gateway 3500 Figure 15-5: Software Upgrade in Process, Includes Solaris OS Upgrade Requirement Notification Note: Be sure that you have gone through all needed site preparation steps as described (refer to page 164) if you did not do that prior to commencing the Software upgrade.

  • Page 175: Figure 15-6: Software Upgrade In Process, Provisioning Parameter Values Screen

    Installation, Operation, Maintenance Manual 15. Software Upgrade Figure 15-6: Software Upgrade in Process, Provisioning Parameter Values Screen Following this screen, the process performs a backup of the current configuration and saves it on the Installation Server. You are prompted to choose how the OS upgrade should be performed.

  • Page 176: Manual Os Upgrade

    Media Gateway 3500 Figure 15-7: Software Upgrade in Process, OS Upgrade Options Screen The Automatic OS Upgrade usually takes from 20 to 60 minutes, depending on the speed of the connection between the SC board and the Installation Server. While Automatic OS Upgrade is performed, there is no "progress"...

  • Page 177: Upgrading The Media Gateway Boards

    Installation, Operation, Maintenance Manual 15. Software Upgrade Installation Server that resides in the same subnet with SC boards Detailed instructions for the installing Solaris 9 are provided on page 144. Note: Before starting a manual OS installation, make sure that the other SC board is not configured as a Jumpstart Server.

  • Page 178: Upgrading The Primary Sc Board

    Media Gateway 3500 After upgrading the first ES board, click the Next button. At this point, the Active SC board, all of the Media Gateway boards and the Active Ethernet Switch board are upgraded to the new software version, making all of the essential parts of the new software distributed across all types of the boards in the chassis.

  • Page 179: Sc Board Cleanup

    Installation, Operation, Maintenance Manual 15. Software Upgrade 15.4.6 SC Board Cleanup After completing the Online Software Upgrade process, some unneeded settings may remain on the Secondary SC board. To perform cleanup on Secondary SC board, take these 4 steps: Connect to the Secondary SC board via Telnet or RS232 console At the prompt, type rm -rf /jumpstart and press Enter.

  • Page 180: Os Downgrade

    Media Gateway 3500 Figure 15-9: Software Upgrade in Process, Abort Screen A rollback may or may not affect media gateway service. It depends on the original software version that was installed prior to starting Online Software Upgrade (and that is being rolled back to) and how far the upgrade has progressed by the time the rollback is performed.

  • Page 181: Ethernet Switch Board Downgrade In Version 2.1

    Installation, Operation, Maintenance Manual 15. Software Upgrade Automatic OS Downgrade Automatic OS downgrade is performed fully automatically without any user intervention. If connection between the SC boards and the Installation Server provides sufficient speed, OS downgrade takes approximately 20 minutes. Manual OS Downgrade Manual OS downgrade is similar to the manual OS upgrade as described on page 176.

  • Page 182: Software Upgrade/Rollback Troubleshooting

    Media Gateway 3500 ES board and keeps it from starting up. This causes the first ES board to get the 'global IP' address. Using Telnet, connect to the first ES board (via global IP) and download the scripts to it. (Refer to ‘Appendix - Installing ES Board Software’ on page 211.) DO NOT RESET THE ES BOARD.
  • Page 183 Installation, Operation, Maintenance Manual 15. Software Upgrade client208::~# tools tg dn If there is no Telnet connection an SC board, take these 2 steps: Connect to the RS232 console of the SC board and verify that the OS is actually not running on it.
  • Page 184 (dependent upon only one SC board). For details on replacing a failed SC board, refer to ‘SC Board Replacement Procedure’ on page or contact Nortel for assistance in repairing the failed SC software. Rollback the Media Gateway boards. •...

  • Page 185: Alternative To Rollback After "Secondary Sc Upgrade" Phase During Version 2.1 To Version 3.0 Upgrade

    ES boards when it restarts and upgrades them with the new software. Replace the failed SC board (refer to ‘SC Board Replacement Procedure’ on page 142) or contact Nortel for assistance in repairing the failed SC software. 15.7...

  • Page 186: Upgrade From Version 2.1 To Version 3.0 - Known Limitations

    Media Gateway 3500 Table 15-1: Disabled Features for Upgrade from Version 2.1 to Version 3.0 Value after Default value upgrade from Feature Name in version 3.0 version 2.1 Provisioning guide Geographical Address Change Boards Provisioning Mode BoardProvisioningMode attribute in Gateway MO...

  • Page 187: Shutdown Procedures

    Installation, Operation, Maintenance Manual 16. Shutdown Procedures Shutdown Procedures In the event that you need to shut down the Media Gateway 3500, the correct shutdown procedure should be followed. To shut down a Media Gateway 3500, take these 5 steps: Verify that no activity in the system is being generated from the EMS or MIB browser due to operator activity.
  • Page 188 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 189: Diagnostics & Troubleshooting

    Diagnostics & Troubleshooting This section describes the recommended method for maintaining Nortel’ Media Gateway 3500 Media Gateways. Nortel provides a wide range of diagnostic tools to enable users to easily identify an error condition and to provide a solution or work around.

  • Page 190: Troubleshooting

    Media Gateway 3500 17.2 Troubleshooting The table below presents possible courses of action to remedy faults arising in the Media Gateway 3500 Media Gateway + TP-1610 configuration Table 17-1: Troubleshooting Faults in the Media Gateway Problem Possible Cause(s) What to do...
  • Page 191 Installation, Operation, Maintenance Manual 17. Diagnostics & Troubleshooting Table 17-1: Troubleshooting Faults in the Media Gateway Problem Possible Cause(s) What to do Refer to No Console Console settings Check the communication port settings communication to to verify: 9600, 8, N,1 the SC board Bit per second=9600 Data bits=8...
  • Page 192 Media Gateway 3500 Table 17-1: Troubleshooting Faults in the Media Gateway Problem Possible Cause(s) What to do Refer to Media Gateway IP Connect the Console to the SC board. settings Run the configuration utility to set the IP settings. No communication Software does not Try to "ping"...
  • Page 193 Installation, Operation, Maintenance Manual 17. Diagnostics & Troubleshooting Table 17-1: Troubleshooting Faults in the Media Gateway Problem Possible Cause(s) What to do Refer to The configured Check the MAC address on the board MAC addresses for and make sure that they are the same the board are as listed in the configuration.
  • Page 194 Media Gateway 3500 Table 17-1: Troubleshooting Faults in the Media Gateway Problem Possible Cause(s) What to do Refer to Synchronization Verify that the clock hierarchy is set problems - too properly. Check which clock sync mode many alarms on the is being used and is set in the trunks.

  • Page 195: Syslog Support

    Examples below. The Nortel application performs as a Syslog client. Messages (currently Error Reports events) generated by the Nortel application are sent via UDP and IP to a Syslog server application. Currently there are 5 error levels reported by the Syslog client Examples: Emergency level message: <128>sctp socket setsockopt error 0xf0 [File:sctp.cpp Line:453]...

  • Page 196: List Of Alarms

    Media Gateway 3500 17.4.1 List of Alarms The Media Gateway supports the following alarms list, where each of the alarms is assigned with its unique MIB Object Identifier (OID): TPBoardFailureTrap (future) MOAdminStateChange MOOperativeStateChange V5.2Alarm (For Broadband/Cable/IPAT applications only) TrunkAlarm STM1LinkAlarm...

  • Page 197: Application, Solaris™ Log Files' Directories

    Installation, Operation, Maintenance Manual 17. Diagnostics & Troubleshooting For a detailed summary of the alarms supported in the Media Gateway 3500 Media Gateway, refer to the Alarms and Alarm Field Descriptions Table in the Programmer’s User’s Manual, Document # LTRT-962xx, Element Management System User’s Manual, Document #: LTRT-910xx, and EMS Alarm Guide, Document #: LTRT 946xx.

  • Page 198: Simple Diagnostic Tool's File

    17.11 Information Needed when Contacting Technical Support When contacting Nortel Technical Support (refer to the title page or last page of this manual for detailed contact information), send the following information: A detailed description of the problem. Any information obtained from the troubleshooting process, suspected component, etc.
  • Page 199 Installation, Operation, Maintenance Manual 17. Diagnostics & Troubleshooting Output of tools d. Version 3.0 October 2005...

  • Page 201: Media Gateway 3500 Selected Functional Specifications

    Installation, Operation, Maintenance Manual 18. Media Gateway 3500 Selected Functional Specifications Media Gateway 3500 Selected Functional Specifications Table 18-1: Media Gateway 3500 Functional Specifications Function Specification Capacity Network Ports/DSP Up to 80 E1/T1 Links; Redundant*, 5+1 Media Gateway Boards Calls...
  • Page 202 Media Gateway 3500 Table 18-1: Media Gateway 3500 Functional Specifications Function Specification Cables: G.711, G.728 and G.729E Echo Cancellation G.165 and G.168 2000 compliant Gain Control Configurable Input/Output Gain Control: -31 dB to +31 dB in steps of 1 Silence Suppression G.723.1 Annex A...
  • Page 203 Installation, Operation, Maintenance Manual 18. Media Gateway 3500 Selected Functional Specifications Table 18-1: Media Gateway 3500 Functional Specifications Function Specification Generator, Tone Detection, DTMF Generator, DTMF Detection, Call Progress Tones Generator, Call Progress Tones Detection, Basic Continuity, Network, RTP, TDM Circuit, Generic Announcement,...
  • Page 204 Media Gateway 3500 Table 18-1: Media Gateway 3500 Functional Specifications Function Specification Note: Currently supported on Media Gateway blade TP-1610 only CCS - ISDN PRI: ETSI EURO ISDN, ANSI NI2, DMS, 5ESS, Japan INS1500, QSIG Basic Call, Australian Telecom, New Zealand Telecom,...
  • Page 205 Installation, Operation, Maintenance Manual 18. Media Gateway 3500 Selected Functional Specifications Table 18-1: Media Gateway 3500 Functional Specifications Function Specification Dimensions 222 x 483 x 311 mm (8.7 in. x 19 in. x 12.3 in.) (h x w x d)

  • Page 207: Regulatory Information

    Information contained in this document is believed to be accurate and reliable at the time of printing. However, due to ongoing product improvements and revisions, Nortel cannot guarantee the accuracy of printed material after the Date Published nor can it accept responsibility for errors or omissions.
  • Page 208 Should you experience trouble with this telephone equipment, contact Nortel. Do not attempt to repair this equipment! Facility Interface Code: 04DU9.BN, 04DU9.DN, 04DU9.1KN, 4DU9.ISN Service Order Code: 6.0N...
  • Page 209 Installation, Operation, Maintenance Manual 19. Regulatory Information FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 210 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 211: Appendix - Installing Es Board Software

    Appendix - Installing ES Board Software 20.1 Media Gateway 3500 Media Gateway Version 2.1 Media Gateway 3500 Media Gateway version 2.1 does not support automatic management of the Ethernet Switch board's software. Therefore, the user must perform the installation manually as described below.

  • Page 212: Troubleshooting

    Media Gateway 3500 Switch Board, but it wasn't activated yet. Please provision IP address of the Switch Board via EMS and lock/unlock it in order to activate new software. When the new software is uploaded, provision the IP address of the Switch Board via the EMS and LOCK/UNLOCK it.

  • Page 213: Appendix - Solaris

    Solaris OS. Because customized configured versions of the Solaris are utilized in the Media Gateway 3500 (to ensure full hardware compatibility and optimal software performance), it is important to utilize Nortel provided versions of the Solaris for installations on SC boards as needed.

  • Page 214: Installing The Sc Board

    Media Gateway 3500 At the prompt, change the directory to the CD-ROM's root. EMS-Server8:/ [root] => cd /cdrom/cdrom0 If there is no directory,"cdrom0" exists, type the command, eject and try again. EMS-Server8:/ [root] => eject At the prompt, run the 'install' script by typing ./install and pressing Enter.
  • Page 215 Installation, Operation, Maintenance Manual 21. Appendix - SolarisTM 8 OS Installation Via the RS232 console connection on the SC board, copy the new firmware from the 'Install Image' to the local hard disk. client224:~# ~ => mount –F nfs ems_ip:jumpstart /mnt client224:~# ~ =>...
  • Page 216 Media Gateway 3500 Reader’s Notes Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 217: Appendix - Updating The Media Gateway Boards Feature Key

    Installation, Operation, Maintenance Manual 22. Appendix – Updating the Media Gateway Boards Feature Appendix – Updating the Media Gateway Boards Feature Key The Feature key for the Media Gateway boards defines the maximum software version that may be loaded on the Media Gateway board and specific applications that may be configured on it.
  • Page 218 If such a report is produced, send it to Nortel Technical Support who will provide a file containing the correct keys for your Media Gateway boards.

  • Page 219: Appendix - Getting Started With Mibs

    Installation, Operation, Maintenance Manual 23. Appendix - Getting Started with MIBs Appendix - Getting Started with MIBs Using the EMS to manage their Media Gateway is strongly recommended due to the efficient, comprehensive and user-friendly environment offered in the EMS. However, a customer may opt for the alternative management method using the Media Gateway’s MIB and utilizing a MIB Compiler and Browser such as those provided by, for example, MGSOFT Corporation, accessible at URL 'http://www.mg-soft.com/'.

  • Page 220: Configuring A Newly Inserted Media Gateway Board

    Media Gateway 3500 When beginning to work with the Media Gateway for the first time, all the Media Gateway’s elements are locked, allowing the SNMP Agent to start provisioning those elements. It is important to unlock the elements when provisioning/configuration is complete, otherwise the Media Gateway will remain out of service.

  • Page 221: Modifying A Media Gateway Board Configuration

    Installation, Operation, Maintenance Manual 23. Appendix - Getting Started with MIBs When these actions are complete, the specific slot is configured with a specified board type. All other board parameters are configured with the default values. Refer to the Programmer’s User Manual, Document#: LTRT-914xx, for the list and description of the board parameters and the default values.

  • Page 222: Removing A Media Gateway Board

    Media Gateway 3500 Lock the configured MIB section by setting the tgTrunkActionType = lock. As a result: When working with a MIB browser, a trunk Table of all gateway trunks is displayed. Select the appropriate specific trunk number. Modify one of trunk’s parameters, which have read-write access.
  • Page 223 Installation, Operation, Maintenance Manual 23. Appendix - Getting Started with MIBs (Refer to 'List of Alarms' on page 195, or the Programmer’s User Manual, Document#: LTRT-914xx, for the Alarm values.) Version 3.0 October 2005...

  • Page 224: Appendix - Utilities

    Media Gateway 3500 Appendix - Utilities This section describes the functionality and operation of a list of utilities supplied with the software package. 24.1 Downloadable Conversion Utility LOCATION: .\Tools\DConvert.exe Figure 24-1: Downloadable Conversion Utility Opening Screen This utility is used to generate the following:...

  • Page 225: Process Call Progress Tones File(S)

    To convert a CPT ini file to a binary dat file, take these 8 steps: Create a CPT ini file using the direction in ''Modifying the Call Progress Tones File'' on page 120 or by editing a CPT ini file provided by Nortel. Execute DConvert.exe and click the Process Call Progress Tones file(s) button.

  • Page 226: Process Voice Prompts File(S)

    Media Gateway 3500 Note: The default value of the dBm units for tone levels checkbox is left unchecked for backward compatibility with versions prior to version 3.0. Click the Make File button. The dat file is generated and placed in the same directory as shown in the Output File field.

  • Page 227: Figure 24-4: Select Files Window

    Installation, Operation, Maintenance Manual 24. Appendix - Utilities Select it and click the Add>> button. To close the Add Files window, click the Exit button. (Press the Esc key to cancel changes.) Figure 24-4: Select Files Window Version 3.0 October 2005...

  • Page 228: Figure 24-5: File Data Window

    Media Gateway 3500 From any location on the PC, select the appropriate files and drag-drop them into the Voice Prompts window. Arrange the files as desired by dragging and dropping them from one location in the list to another location.

  • Page 229: Packet Tracing

    Installation, Operation, Maintenance Manual 24. Appendix - Utilities Note: For wav files, a coder is automatically selected from the wav file header. Close the File Data dialog by clicking on the Exit button. (Press the Esc key to cancel changes.). You are returned to the Voice Prompts window. The default Output file name is voiceprompts.dat.You can modify it.

  • Page 230: Dsp Traces

    Media Gateway 3500 Determine the UDP port (the same as in step 3). Click the SUBMIT button. The board starts to send the trace messages to the UDP2FILE application. In the UDP2File utility (Refer to Figure 24-7 below) you should see the number in the packets field increasing.
  • Page 231 Installation, Operation, Maintenance Manual 24. Appendix - Utilities DSP traces are useful for capturing voice/data directly from a DS0 channel. To setup a DSP trace take the following steps: On a PC run the UDP2File utility. Select a suitable trace file name. Determine the UDP port.

  • Page 232: Figure 24-8 Packet Recording Screen

    Media Gateway 3500 Figure 24-8 Packet Recording Screen Installation, Operation, Maintenance Manual Document # LTRT-90704...

  • Page 233: Index

    Creating the SC Software Backup ....97 50-pin Telco Connector E1/T1/J1 Connections ............29, 105 Defining IP Parameters... 52, 84, 120, 132 Defining IP Parameters - Media Gateway 3500 + TP-1610/SB-1610 Configuration.... 55 Diagnostics & Troubleshooting ... 157, 195 Advanced Power Module (APM) ....23 Alarm Indicators........23, 24...
  • Page 234 Performing the Basic SC Configuration .. 88, 92 Interfacing with the IP Networks....49, 58 Physical Requirements ......... 49 Introduction to IPSec and IKE .....135 Playing Prerecorded Tones (PRT)....130 Introduction to the Media Gateway 3500..15 Post-Power Connection Test Procedures Introductory Matter ........13 Checklist............ 79 IPSec ............135 Power Consumption........
  • Page 235 Installation, Operation, Maintenance Manual Index System Controller Panel Indicators & Controls ..............34 Technical Overview ........116 Testing the Installed System .......141 The Chassis...........19 The TP-1610/SB-1610 Board ......25 TP-1610/SB-1610 Board Panel LED Indicators ..............30 TP-1610/SB-1610 Configuration - Cabling the Trunk Connectors ......103, 105 Troubleshooting........186, 196 Troubleshooting Strategy ......195 Unpacking/Checking Contents ......65...
  • Page 236 Installation, Operation, Maintenance...

Table of Contents
