5. Complete the steps outlined in the "Completing the ESS 3200 installation at the customer site (SSR
task)" on page 64.
Install and connect management server 5105-22E
For information about installing the management server, see Install and Connect the ESS Management
Server 5105-22E on the IBM Worldwide Customized Installation Instructions (WCII) website.
Connect power cords to rack PDUs
For information, see Connect power cords to rack PDUs on the IBM Worldwide Customized Installation
Instructions (WCII) website.
ESS 5000 SCx/SLx network cabling
In case your configuration includes ESS 5000 with SCx or SLx network cabling, see the following links:
• For information about 5147-SCx networking cabling, see ESS SCx network cabling on the IBM
Worldwide Customized Installation Instructions (WCII) website.
• For information about 5147-SLx networking cabling, see ESS SLx network cabling on the IBM Worldwide
Customized Installation Instructions (WCII) website.
Connect AC (wall) power to the rack PDUs
For information, see Connect AC (wall) power to the rack PDUs on the IBM Worldwide Customized
Installation Instructions (WCII) website.
Power On switches, storage enclosures, and servers
For information, see Power on switches, storage enclosures, and servers on the IBM Worldwide
Customized Installation Instructions (WCII) website.
Check servers with essutils tool
For information, see Check servers with essutils tool on the IBM Worldwide Customized Installation
Instructions (WCII) website.
Best practices for network configuration (Customer reference task)
Use this section for best practices and guidance when you fill out the Installation worksheet.
Using these best practices, the customer is aided to select IP addresses for the management interfaces
and fill out the Installation worksheet. This information from the customer is required for the SSR to
pre-set the required IP addresses needed for successful storage deployment. Once the SSR is finished,
the hardware and management networking is ready for the next phase of the install (Quick deployment
guide), see the Quick Deployment guide in the IBM Elastic Storage System 3200 Documentation website.
The SSR takes the input from the worksheet and implements the requested IP addresses. The information
below is general guidance and is purely for example reasons. If the SSR does not receive desired IP
addresses at time of hardware installation, they would set default IP addresses on the nodes.
Management server best practices (EMS)
Ensure that each IP in the worksheet is on the same subnet. Recommended subnet is /24
(255.255.255.0).
Management Network IPs:
Subnet: 192.168.45.0/24
IP Address: 192.168.45.20
Chapter 4. Installing 61
