Table 19. Summary of onboard ports (continued)
Onboard Port
TP (Technician Port) - USB type
mini-B
Each IBM Elastic Storage System 3200 system requires two Ethernet cables to connect it to an Ethernet
switch. One cable connects to the Ethernet port of the left server canister, and the other cable connects to
Ethernet port of the right server canister.
Each IBM Elastic Storage System 3200 server canister has two PCIe interface slots to support optional
host interface adapters. The host interface adapters can be supported in any of the interface slots. The
following table provides an overview of the host interface adapters.
Table 20. Summary of supported host interface adapters
Protocol
200 Gb IB-HDR/
Ethernet
100 Gb Ethernet
Note: Each server canister within the IBM Elastic Storage System 3200 system (building block) must be
configured with the same host interface adapters.

Planning for adapters

IBM Elastic Storage System 3200 contains two server canisters. Each server canister has two PCIe
interface slots to support extra adapters. InfiniBand and Ethernet adapters are supported in any of the
interface slots. In addition, each server canister contains one Onboard Ethernet port and one SSR access
port.
Important: Both server canisters in an IBM Elastic Storage System 3200 system (same building block)
must be configured with the same adapters. Both server canisters must have identical configuration.
Speed
N/A
Feature
AJZL 2 per adapter
AJZN 2 per adapter
Ports FRU part
number
01LL648
01LL634
Function
Fixed IP address from factory for
service and hardware configuration
Left canister:
Right canister:
User ID: essserv1
Password:
• Left canister - {Serial # of
enclosure} A
• Right canister - {Serial # of
enclosure} B
Example: Enclosure serial 78E00TF
• Left canister password:
78E00TFA
• Right canister password:
78E00TFB
Serial number of the enclosure
can be obtained from the front
tag located at the left side of the
enclosure.
Quantity supported
2-4
2-4
