Figure 87. 11S label
Note: The required software update is cumulus-3.7.12a.
2. Log in to the switch by using the following default credentials and press the Enter key.
• User ID: cumulus
• Password: CumulusLinux!
If the CumulusLinux1 default password does not work, to reset the password see the Password
Recovery section in the NVIDIA documentation.
3. Use the following command to display the 11S serial number.
cumulus@1Gsw:~$ decode-syseeprom | grep Serial | awk '{print $5}'| cut --complement -c -3
The system displays the 11S serial number similar to the following:
01FT690YA50YD7BGABX
4. Change the default password to the 11S password by using the following command:
cumulus@accton-1gb-mgmt:~$ passwd
current UNIX password: CumulusLinux!
Enter new UNIX password: <<<Copy and paste the output provided in the 11S serial number
display step.
Retype new UNIX password: <<<Copy and paste the output provided in the 11S serial number
display step.
passwd: password updated successfully.
5. Log in through SSH or console and log in with the new 11S password to validate the changes.
Note: The default password must be set to the 11S serial number 01FT690YA50YD7BGABX. If not,
the password must be CumulusLinux!.
Connect the PC to the switch console port
Figure 88. Switch port and switch markings
Connect the PC to the switch console port as follows:
• Connect to the switch by using RJ45 to serial cable.
Figure 89. RJ45 to serial cable and USB to serial cable
• Connect the serial end to the serial to USB cable.
• Connect the USB cable to the PC.
108 IBM Elastic Storage System 3200: Hardware Planning and Installation Guide
Mgmt0
Console Port
USB Port
