Installation
Unit Inspection
As soon as the unit arrives at the job site
•
Verify that the nameplate data matches the data on the
sales order and bill of lading (including electrical data).
•
Verify that the power supply complies with the unit
nameplate specifications.
•
Verify that the power supply complies with the electric
heater specifications on the unit nameplate.
•
Visually inspect the exterior of the unit, including the
roof, for signs of shipping damage.
•
Check for material shortages. Refer to the Component
Layout and Ship with Location illustration,
p.
15).
Note: If the job site inspection of the unit reveals damage
or material shortages, file a claim with the carrier
immediately. Specify the type and extent of the
damage on the "bill of lading" before signing.
•
Visually inspect the internal components for shipping
damage as soon as possible after delivery and before
it is stored. Do Not walk on the sheet metal base pans.
WARNING
No Step Surface!
Do not walk on the sheet metal drain pan. Walking on
the drain pan could cause the supporting metal to
collapse, resulting in the operator/technician to fall.
Failure to follow this recommendation could result in
death or serious injury.
•
If concealed damage is discovered, notify the carrier's
terminal of damage immediately by phone and by
mail. Concealed damage must be reported within 15
days.
Request an immediate joint inspection of the damage by
the carrier and the consignee. Do not remove damaged
material from the receiving location. Take photos of the
damage, if possible. The owner must provide reasonable
evidence that the damage did not occur after delivery.
Storage
Take precautions to prevent condensate from forming
inside the unit's electrical compartments and motors if:
a. The unit is stored before it is installed; or,
b. The unit is set on the roof curb, and temporary heat
is provided in the building. Isolate all side panel
service entrances and base pan openings (e.g.,
conduit holes, S/A and R/A openings, and flue
openings) from the ambient air until the unit is
ready for start-up.
16
Note: Do not use the unit's heater for temporary heat
without first completing the start-up procedure
detailed under "Starting the Unit".
Trane will not assume any responsibility for equipment
damage resulting from condensate accumulation on the
unit's electrical and/or mechanical components.
Unit Clearances
Figure 3, p. 18
service clearances for either a single or multiple unit
installation. These clearances are the minimum distances
necessary to assure adequate serviceability, cataloged
unit capacity, and peak operating efficiency.
(Figure 1,
Providing less than the recommended clearances may
result in "short-circuiting" of exhaust and economizer
airflows.
Unit Dimensions & Weight Information
Overall unit dimensional data for the W_HE unit is
illustrated in
illustration and the dimensional data is shown in
p.
25.
Table 6, p. 30
weights. Weights shown represent approximate operating
weights. Actual weights are stamped on the unit
nameplate.
illustrates the minimum operating and
Figure 4, p.
19. A Center-of-Gravity
lists the typical unit and curb operating
Table 4,
RT-SVX35H-EN
