Icom ID-RP2 Instruction Manual page 5

D D AH-106 : 10 GHz parabolic antenna 800 (d)
D D AH-107 : 10 GHz parabolic antenna 450 (d)
➥Both AH-106 and AH-107 are offset parabolic an-
tenna and connect to ID-RP2L.
Up to 20 km
(approx.; 12.4 miles)
* of communication range is provided when
5 miles)
AH-106 or AH-107 is used at the both microwave
link repeaters, respectively.
And up to 12 km
(approx.; 7.5 miles)
tion range is provided between AH-107 and AH-
106's repeaters.
*Communication range may differ/change according to en-
vironment, such as weather, installed conditions, etc.
D D AH-108 : 1.2 GHz Collinear antenna
➥2 Collinear antennas are built-in and better isolation
is provided than separated 2 antennas.
* or 8 km
(approx.;
* of communica-
Antenna
ID-RP2C
POWE R
10 BESE-T
SERVICE 1 SERVICE
2
ASSIS
T 1
ASSIS T 2
Repea ter Contro ID-RP 2C
ller
POWER POWER
SERVICE
T SERVICE
R SERVICE
Rep ID-
eate r Con RP2 V Rep ID-
trolle r eate r Con RP2
troll D er
ID-RP2V ID-RP2D
Internet Internet
2
SYSTEM OUTLINE
ID-RP2L
1
Area
Zone
Signal
Internet
