If the .KSF filename is "SKIPPEDSAMPL", it will be
treated as a sample skipped during loading.
Legacy files may include .KSF filenames of
"INTERNALnnnn," which designated internal samples on
previous Korg instruments. On the KRONOS, this feature is
not supported.
• Relative parameter chunk 2
Chunk ID ('RLP2')
Chunk size (4)
Transposing (–64...+63)
Resonance (–99...+99)
Attack (–99...+99)
Decay (–99...+99)
• Relative parameter chunk 3
Chunk ID ('RLP3')
Chunk size (fixed at 6)
Drive (–99...+99)
Boost (–99...+99)
LowEQLevel (–99...+99)
MidEQLevel (–99...+99)
HighEQLevel (–99...+99)
unused
• Multisample number chunk
Chunk ID('MNO1')
Chunk size (4)
Multisample number (0–)
KSF (Korg Sample File) files
There are four types of structure for these files. One consists
of a Sample Parameter chunk, Sample Data chunk, Sample
Number chunk and Sample name (SMP1 + SMD1 + SNO1 +
NAME). Another consists of a Sample Parameter chunk,
Sample Data chunk, Sample Filename chunk, Sample
Number chunk, and Sample name chunk (SMP1 + SMD1 +
SMF1 + SNO1 + NAME). The latter structure is in the case
where the sample data of the Sample chunk is empty, and
uses the sample data of the .KSF file specified by the Sample
Filename chunk (shared sample data).
• Sample parameter chunk
Chunk ID ('SMP1')
Chunk size (32)
Sample name
Start address
2nd start address
Loop start address
Loop end address
• Sample data chunk
Chunk ID ('SMD1')
Chunk size (12 + number of sample
databytes)
Sampling frequency
Disk mode and file format information Korg format sample files
Attributes
Loop tune (–99...+99 cents)
Number of channels (1)
Sample size (8/16)
Number of samples
Sample data
[4 bytes]
[4 bytes]
Sampling frequency is a 4-byte unsigned integer; all
frequencies between 0Hz and 4.294GHz are supported.
[1 byte]
When sampling frequency is greater than 48kHz, if the data
[1 byte]
includes audio frequencies above 24kHz, playback quality
[1 byte]
may be slightly degraded.
[1 byte]
• Attributes
MSB
[4 bytes]
[4 bytes]
[1 byte]
[1 byte]
[1 byte]
[1 byte]
• Sample number chunk
[1 byte]
Chunk ID ('SNO1')
[1 byte]
Chunk size (4)
Sample number (0–)
[4 bytes]
• Sample name chunk
[4 bytes]
Chunk ID ('NAME')
[4 bytes]
Chunk size (fixed at 24)
Sample name
• Sample filename chunk
Chunk ID ('SMF1')
Chunk size (12)
KSF filename
If the .KSF filename is "SKIPPEDSAMPL", it will be
treated as a sample skipped during loading.
If the .KSF filename is "INTERNALnnnn", internal
samples will be used.
• Divided sample parameter chunk
[4 bytes]
Chunk ID ('SPD1')
[4 bytes]
Chunk size (12)
[16 bytes]
The following up to the sample size is the same as in the
SMD1 chunk
[4 bytes]
Sampling frequency
[4 bytes]
Attributes
[4 bytes]
Loop tune
[4 bytes]
Number of channels
Sample size
[4 bytes]
Number of samples
[4 bytes]
Total number of samples in all divided files
[4 bytes]
[1 byte]
[1 byte]
[1 byte]
[1 byte]
[4 bytes]
variable length
Sample parameter attributes
LSB
1: +12 dB playback 0: 0 dB playback*
Compression ID
1: Compressed data 0: Un-compressed data
1: Not Use 2nd Start 0: Use It
1: Reverse 0: Forward
1: Loop Off 0: Loop On
* For uncompressed data, this bit is handled as a
switch that specifies the playback gain.
For compressed data, this bit is handled as a
compression ID.
[4 bytes]
[4 bytes]
[4 bytes]
[4 bytes]
[4 bytes]
[24 bytes]
[4 bytes]
[4 bytes]
[12 bytes]
[4 bytes]
[4 bytes]
[4 bytes]
[1 byte]
[1 byte]
[1 byte]
[1 byte]
[4 bytes]
