KA01114D/06/EN/03.14
71245370
Products
Brief Operating Instructions
Proline Promag W 400
Electromagnetic flowmeter
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
• On the CD-ROM supplied (is not included in the delivery for
all device versions).
• Available for all device versions via:
– Internet:
www.endress.com/deviceviewer
– Smart phone/tablet: Endress+Hauser Operations App
Description of the procedure (→  10)
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proline Promag W 400

Summary of Contents for Endress+Hauser Proline Promag W 400

  • Page 1 Operating Instructions and the other documentation: • On the CD-ROM supplied (is not included in the delivery for all device versions). • Available for all device versions via: – Internet: www.endress.com/deviceviewer – Smart phone/tablet: Endress+Hauser Operations App Description of the procedure (→  10)

  • Page 2: Table Of Contents

    Table of contents Proline Promag W 400 Table of contents Document information ............3 Symbols used .

  • Page 3: Document Information

    Proline Promag W 400 Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 4 Document information Proline Promag W 400 1.1.3 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.1.4 Symbols for certain types of information Symbol Meaning Permitted Indicates procedures, processes or actions that are permitted. Preferred Indicates procedures, processes or actions that are preferred.

  • Page 5: Basic Safety Instructions

    Proline Promag W 400 Basic safety instructions Symbol Meaning Flow direction Hazardous area Indicates a hazardous area. Safe area (non-hazardous area) Indicates the non-hazardous area. Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣...

  • Page 6: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 7: Product Safety

    It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions.

  • Page 8: Product Description

    Product description Proline Promag W 400 Product description Product design A0017218  1 Important components of the compact version Display module Smart sensor electronics module HistoROM DAT (plug-in memory) Endress+Hauser...

  • Page 9: Incoming Acceptance And Product Identification

    Proline Promag W 400 Incoming acceptance and product identification Main electronics module Terminals (screw terminals, some available as plug-in terminals) Transmitter housing, compact version Cable glands Sensor, compact version Incoming acceptance and product identification Incoming acceptance Are the order codes on the...

  • Page 10: Product Identification

    Incoming acceptance and product identification Proline Promag W 400 • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! In such cases, the technical documentation is available via the Internet or via the Endress +Hauser Operations App, see the "Device documentation"...

  • Page 11: Storage And Transport

    Enter the serial number (Ser. no.) of the device: see nameplate (→  2,  10).  All the associated documentation is displayed. Endress+Hauser Operations App The Endress+Hauser Operations App is available for Android (Google play) and iOS (App Store). Via the serial number: Launch the Endress+Hauser Operations App.

  • Page 12: Transporting The Product

    Storage and transport Proline Promag W 400 Transporting the product 5.2.1 For measuring devices ≤ DN 300 (12") WARNING Center of gravity of the measuring device is higher than the suspension points of the webbing slings. Risk of injury if the measuring device slips.

  • Page 13: Mounting

    Proline Promag W 400 Mounting A0016257 Mounting Installation conditions 6.1.1 Mounting position Mounting location A0023343 h ≥ 2 × DN Installation in down pipes Install a siphon with a vent valve downstream of the sensor in down pipes whose length h ≥...
  • Page 14 Mounting Proline Promag W 400 A0017064  3 Installation in a down pipe Vent valve Pipe siphon Length of down pipe Installation in partially filled pipes A partially filled pipe with a gradient necessitates a drain-type configuration. The empty pipe detection (EPD) function offers additional protection by detecting empty or partially filled pipes.
  • Page 15 Proline Promag W 400 Mounting Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction. An optimum orientation position helps avoid gas and air accumulations and deposits in the measuring tube.
  • Page 16 • Avoid direct sunlight, particularly in warm climatic regions. • Avoid direct exposure to weather conditions. • Protect the display against impact. • Protect the display from abrasion by sand in desert areas. A display protector can be ordered from Endress+Hauser: "Accessories" section System pressure A0015594 Endress+Hauser...
  • Page 17 Proline Promag W 400 Mounting Furthermore, install pulse dampers if reciprocating, diaphragm or peristaltic pumps are used. Vibrations It is recommended to mount the sensor and transmitter separately. A0016266  4 Measures to avoid device vibrations (L > 10 m (33 ft))
  • Page 18 Mounting Proline Promag W 400 6.1.3 Special mounting instructions Display protection ‣ To ensure that the optional display protection can be easily opened, maintain the following minimum head clearance: 350 mm (13.8 in) Permanent immersion in water A0017296  5 Engineering unit in m(ft) Replacement of cable gland on connection housing (→...

  • Page 19: Mounting The Measuring Device

    Proline Promag W 400 Mounting Mounting the measuring device 6.2.1 Required tools For transmitter • Torque wrench • For wall mounting: Open-ended wrench for hexagonal screw max. M5 • For pipe mounting: – Open-ended wrench AF 8 – Phillips head screwdriver PH 2 •...
  • Page 20 Mounting Proline Promag W 400  A0013964 Mounting the seals CAUTION An electrically conductive layer could form on the inside of the measuring tube! Risk of measuring signal short circuit. ‣ Do not use electrically conductive sealing compounds such as graphite.
  • Page 21 Proline Promag W 400 Mounting Wall mounting 17 (0.67) 14 (0.55) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0020523  6 Engineering unit mm (in) Post mounting WARNING Excessive tightening torque applied to the fixing screws on plastic housing! Risk of damaging the plastic transmitter.
  • Page 22 Mounting Proline Promag W 400 ø 20…70 TX 25 ø ( 0.79…2.75) SW 8 A0020705  7 Engineering unit mm (in) 6.2.5 Turning the transmitter housing TX 20 A0021602 Endress+Hauser...
  • Page 23 Proline Promag W 400 Mounting 3 mm A0021603 TX 20 A0021604 4 mm A0021605 Endress+Hauser...
  • Page 24 Mounting Proline Promag W 400 Reassembling the transmitter housing WARNING Excessive tightening torque applied to the fixing screws! Damage to the transmitter. ‣ When reassembling, tighten the fixing screws as per the tightening torque: Step Fixing screw Tightening torques for housing made of:...

  • Page 25: Post-Installation Check

    Proline Promag W 400 Electrical connection Reassembling the transmitter housing WARNING Excessive tightening torque applied to the fixing screws! Damage to the transmitter. ‣ When reassembling, tighten the fixing screws as per the tightening torque: Step Fixing screw Tightening torque for housing made of:...

  • Page 26: Connection Conditions

    Electrical connection Proline Promag W 400 Connection conditions 7.1.1 Required tools • Torque wrench • For cable entries: Use corresponding tools • For housing cover: Torx screwdriver or flat-blade screwdriver • Wire stripper • When using stranded cables: crimping tool for ferrule 7.1.2...
  • Page 27 Proline Promag W 400 Electrical connection Signal damping Max. 9 dB over the entire length of the cable cross-section Shielding Copper braided shielding or braided shielding with foil shield. When grounding the cable shield, observe the grounding concept of the plant.
  • Page 28 Electrical connection Proline Promag W 400 Operation in zones of severe electrical interference Grounding is by means of the ground terminal provided for the purpose inside the connection housing. The stripped and twisted lengths of cable shield to the ground terminal must be as short as possible.
  • Page 29 Proline Promag W 400 Electrical connection PROFIBUS DP signal transmission Order code for "Output" and "Input" Terminal numbers Output 1 26 (RxD/TxD-P) 27 (RxD/TxD-N) Option L Order code for "Output": Option L: PROFIBUS DP, for use in non-hazardous areas and Zone 2/div. 2 EtherNet/IP signal transmission Order code for "Output"...
  • Page 30 Electrical connection Proline Promag W 400 7.1.4 Pin assignment, device plug PROFIBUS DP For use in the non-hazardous area and Zone 2/Div. 2. Device plug for signal transmission (device side) Assignment Coding Plug/socket Socket PROFIBUS DP PROFIBUS DP Grounding/shielding A0016811...
  • Page 31 Proline Promag W 400 Electrical connection 7.1.6 Preparing the connecting cable for the remote version When terminating the connecting cable, pay attention to the following points: • In the case of electrode cables, make sure that the ferrules do not touch the core shields on the sensor side.

  • Page 32: Connecting The Measuring Device

    Electrical connection Proline Promag W 400 Sensor Electrode cable Coil current cable 20 (0.79)* 20 (0.79)* 160 (6.30)* 170 (6.69)* 80 (3.15) 70 (2.76) 50 (1.97) 50 (1.97) 18.5 (0.73) 10 (0.39) 6 (0.24) 8 (0.31) ³1 (0.04) A0016489 A0016488...
  • Page 33 Proline Promag W 400 Electrical connection WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. The threads on the cover are coated with a dry lubricant.
  • Page 34 Electrical connection Proline Promag W 400 Connecting the supply voltage and PROFIBUS DP PH 2 2627 10 (0.4) A0023164 ‣ Connect the cable in accordance with the terminal assignment (→  29). For supply voltage: open the shock protection cover.
  • Page 35 Proline Promag W 400 Electrical connection Connecting the supply voltage and EtherNet/IP PH 2 10 (0.4) A0021356 ‣ Connect the cable in accordance with the terminal assignment (→  29). For supply voltage: open the shock protection cover. 7.2.2 Connecting the remote version...
  • Page 36 Electrical connection Proline Promag W 400 TX 20 6 5 7 8 4 37 36 42 41 A0017445  11 Transmitter: main electronics module with terminals 42 41 A0021527  12 Sensor: connection module 7.2.3 Ensuring potential equalization CAUTION Electrode damage can result in the complete failure of the device! ‣...
  • Page 37 Proline Promag W 400 Electrical connection Connection examples for standard situations Metal, grounded pipe A0016315  13 Potential equalization via measuring tube Connection example in special situations Unlined and ungrounded metal pipe This connection method also applies in situations where: •...
  • Page 38 Electrical connection Proline Promag W 400 Ground cable Copper wire, at least6 mm (0.0093 in A0016318  15 Potential equalization via ground terminal and ground disks For remote device versions, the ground terminal in the example always refers to the sensor and not to the transmitter.

  • Page 39: Hardware Settings

    Proline Promag W 400 Electrical connection Hardware settings 7.3.1 Setting the device address EtherNet/IP The IP address of the measuring device can be configured for the network via DIP switches. Addressing data IP address and configuration options 1st octet 2nd octet...
  • Page 40 Electrical connection Proline Promag W 400 PROFIBUS DP The address must always be configured for a PROFIBUS DP/PA device. The valid address range is between 1 and 126. In a PROFIBUS DP/PA network, each address can only be assigned once. If an address is not configured correctly, the device is not recognized by the master.

  • Page 41: Ensuring The Degree Of Protection

    Proline Promag W 400 Electrical connection DIP 3 DIP 1 390 Ω 220 Ω 390 Ω DIP 2 A0023063  17 Termination using DIP switches on the I/O electronics module (for baud rates < 1.5 MBaud) Ensuring the degree of protection 7.4.1...

  • Page 42: Post-Connection Check

    Electrical connection Proline Promag W 400 The degree of protection of the transmitter is always only IP66/67, Type 4X enclosure and the transmitter must therefore be treated accordingly (→  41). To guarantee IP68 degree of protection, Type 6P enclosure for the "Cust-potted" options, carry out the following steps after the electrical connection: Firmly tighten the cable glands (torque: 2 to 3.5 Nm) until there is no gap between the...

  • Page 43: Operation Options

    Proline Promag W 400 Operation options Operation options Structure and function of the operating menu 8.1.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation Setup Diagnostics Operating menu for experts Expert A0014058-EN  18 Schematic structure of the operating menu 8.1.2...

  • Page 44: Access To The Operating Menu Via The Local Display

    Operation options Proline Promag W 400 Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language à 20.50 English Deutsch Español Français User ABC_ DEFG...
  • Page 45 Proline Promag W 400 Operation options 8.2.1 Operational display Status area Status signals Failure Function check Out of specification Maintenance required Diagnostic behavior Locking Communication Alarm Warning Device locked Remote operation enabled Display area Measured variables Symbol Meaning Volume flow...
  • Page 46 Operation options Proline Promag W 400 8.2.2 Navigation view Status area The following appears in the status area of the navigation view in the top right corner: • Of the submenu – The direct access code for the parameter you are navigating to (e.g. 0022-1) –...
  • Page 47 Proline Promag W 400 Operation options Correction symbols under Clears all entered characters. Moves the input position Moves the input position Deletes one character one position to the left. one position to the right. immediately to the left of the input position.
  • Page 48 Operation options Proline Promag W 400 Meaning Escape key combination (press keys simultaneously) In a menu, submenu • Pressing the key briefly: – Exits the current menu level and takes you to the next higher level. – If help text is open, closes the help text of the parameter.
  • Page 49 Proline Promag W 400 Operation options 8.2.6 User roles and related access authorization The two user roles "Operator" and "Maintenance" have different write access to the parameters if the customer defines a user-specific access code. This protects the device configuration via the local display from unauthorized access (→...

  • Page 50: Access To The Operating Menu Via The Web Browser

    Operation options Proline Promag W 400 Switching on the keypad lock The keypad lock is switched on automatically: • Each time the device is restarted. • If the device has not been operated for longer than one minute in the measured value display.
  • Page 51 Proline Promag W 400 Operation options ON OFF Default Ethernet network settings IP 192.168.1.212 Write protection A0023353 • Once the DIP switch has been activated, the device must be restarted before the device uses the standard IP address. • If the standard IP address (top DIP switch No. 2 = ON) is used, there is no connection to the EtherNet/IP network.
  • Page 52 Operation options Proline Promag W 400 Starting the Web browser Enter the IP address of the Web server in the address line of the Web browser: 192.168.1.212 If the IP address of the measuring device is known, enter the defined device address in the address line of the Web browser.
  • Page 53 Proline Promag W 400 Operation options 8.3.5 User interface A0017757-EN Picture of device Function row with 6 functions Device tag Header Working area Navigation area Header The following information appears in the header: • Device tag (→  56) • Device status with status signal •...

  • Page 54: Access To The Operating Menu Via The Operating Tool

    System integration Proline Promag W 400 Access to the operating menu via the operating tool For detailed information about access to the operating menu via operating tool, refer to the Operating Instructions for the device (→  10). System integration For information on system integration, see the Operating Instructions for the device (→...

  • Page 55: Setting The Operating Language

    Proline Promag W 400 Commissioning • If hardware addressing is active, software addressing is disabled. • If a switch is made to hardware addressing, the address configured via software addressing is retained for the first 9 places (the first three octets).

  • Page 56: Configuring The Measuring Device

    Commissioning Proline Promag W 400 10.5 Configuring the measuring device The Setup menu and its guided wizards enable fast commissioning of the measuring device. The wizards systematically guide the user through all the parameters required for configuration, such as parameters for measurement or outputs.
  • Page 57 Proline Promag W 400 Commissioning Navigation "Setup" menu → Advanced setup → Administration → Def. access code Structure of the submenu Define access code → Define access code Confirm access code Defining the access code via local display Navigate to the Enter access code parameter.
  • Page 58 Commissioning Proline Promag W 400 The parameter values are now read only and cannot be edited any more (exception "Contrast display" parameter): • Via local display • Via service interface (CDI-RJ45) • Via HART protocol For device version with HART communication type...

  • Page 59: Diagnostic Information

    Proline Promag W 400 Diagnostic information ON OFF Default Ethernet network settings IP 192.168.1.212 Write protection A0023059 Loosen the 4 fixing screws on the housing cover and open the housing cover. Setting the write protection switch (WP) on the main electronics module to the ON position enables the hardware write protection.
  • Page 60 Diagnostic information Proline Promag W 400 X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2 Diagnostics 3 Supply voltage (ID:203) S801 0d00h02m25s...
