Page 1 User’s Guide ARMOR G5 AX6000 Multi-Gigabit Security WiFi Router Model: NBG7815 Default Login Details Version 1.00 Edition 3, 12/2021 LAN IP Address http://zyxelwifi.com Standard (Router) Mode http://zyxelwifi.net http://192.168.123.1 Bridge Mode http://DHCP-assigned IP http://192.168.123.2 Password None required for first login Copyright © 2021 Zyxel and/or its affiliates. All Rights Reserved.
Page 2 Related Documentation • Quick Start Guide The Quick Start Guide shows how to connect the NBG7815 and access the Web Configurator wizards. It contains information on setting up your network and configuring for Internet access. • More Information Go to support.zyxel.com...
Page 3: Document Conventions
Main WiFi means you first click Settings in the navigation panel, then the WiFi sub menu and finally the Main WiFi tab to get to that screen. Icons Used in Figures Figures in this user guide may use the following generic icons. The NBG7815 icon is not an exact representation of your device. NBG7815...
Page 4: Table Of Contents
Standard Mode Status ......................... 55 Bridge Mode Status ..........................58 Technical Reference ........................61 Applications ............................62 WAN ............................... 82 Wireless LAN ............................106 LAN ............................... 118 Security ..............................128 System ..............................135 Troubleshooting and Appendices ....................145 Troubleshooting ..........................146 NBG7815 User’s Guide...
Page 5: Table Of Contents
1.4 Initial Setup Wizard ......................... 17 1.5 OpenVPN Server/Client ......................... 17 1.6 Ways to Manage the NBG7815 ....................17 1.7 Good Habits for Managing the NBG7815 ................... 17 1.8 Resetting the NBG7815 ........................18 1.8.1 How to Use the Reset Button ....................18 1.9 WPS Button ............................
Page 6 4.6 Configure a Profile’s WiFi Schedule ....................39 4.7 Pause or Resume Internet Access on a Profile ................41 4.8 Turn on or off the NBG7815’s LED (Light) ..................42 4.9 Change Your NBG7815 Operating Mode ................... 43 4.10 Configure a Port Forwarding Rule ....................44 Chapter 5 Web Configurator..........................47...
Page 7 10.1.1 What You Can Do ......................106 10.1.2 What You Should Know ....................107 10.2 Main WiFi ............................110 10.3 Guest WiFi ............................ 113 10.4 MAC Filter ............................ 114 10.4.1 Add MAC Address ......................115 10.5 WPS ............................... 115 10.6 Scheduling ........................... 117 NBG7815 User’s Guide...
Page 8 14.1 Overview ............................. 146 14.2 Power, Hardware Connections, and LEDs ................146 14.3 NBG7815 Access and Login ...................... 147 14.4 Internet Access ........................... 148 14.5 Resetting the NBG7815 to Its Factory Defaults ................ 149 14.6 WiFi Connections ........................149 NBG7815 User’s Guide...
Page 9 Table of Contents 14.7 USB File Sharing Problems ......................151 Appendix A Customer Support ..................... 152 Appendix B Setting Up Your Computer’s IP Address..............157 Appendix C Legal Information ...................... 173 Index ..............................179 NBG7815 User’s Guide...
Page 10: User's Guide
User’s Guide...
Page 11: Introduction
The NBG7815 extends the range of your existing wired network without additional wiring, providing easy network access to mobile users. The NBG7815 is able to work on both 2.4G and 5G networks. This table summarizes some of the features that are available at the time of writing.
Page 12: Multi-Gigabit
IPv6 address size to 128 bits (from the 32-bit IPv4 address) allows up to 3.4 x 10 IP addresses. The NBG7815 can use IPv4/IPv6 dual stack to connect to IPv4 and IPv6 networks, and support IPv6 rapid deployment (6RD). See the LAN chapter in the User’s Guide for information on configuring IPv6 in NBG7815.
Page 13 IEEE 802.11a/b/g/n/ac/ax compliant clients can wirelessly connect to the NBG7815 to access network resources. The NBG7815 is a dual-band gateway that can use both 2.4G and 5G networks at the same time. You can use the 2.4 GHz band for regular Internet surfing and downloading while using the 5 GHz band for time sensitive traffic like high-definition video, music, and gaming.
Page 14 NBG7815, but not to other networks connected to it. USB File Sharing Share files on a USB memory stick or hard drive connected to your NBG7815 with users on your network. The NBG7815 also supports file sharing using FTP (file transfer protocol).
Page 15: Operating Modes For The Nbg7815
Figure 5 Standard Mode Example Use your NBG7815 as a bridge if you already have a router or gateway on your network. In this mode your NBG7815 bridges a wired network (LAN) and WiFi in the same subnet. In bridge mode, NBG7815 has one IP address and NBG7815 interfaces are bridged together in the same network.
Page 16: Auto-Ip Change
1.3.1 Auto-IP Change When the NBG7815 (A) gets a WAN IP address or a DNS server IP address which is in the same subnet as the LAN IP address 192.168.123.1, Auto-IP Change allows the NBG7815 to change its LAN IP address to 10.0.0.1 automatically.
Page 17: Initial Setup Wizard
• Web Configurator. This is recommended for everyday management of the NBG7815 using a (supported) web browser. • Zyxel ARMOR mobile app. This is the app you can use to manage the NBG7815 on your cellphone. To install the app, scan the QR code on the QSG.
Page 18: Resetting The Nbg7815
Make sure the power LED is on. Locate the Reset hole. Insert a thin object into the Reset hole for longer than 8 seconds to reset the NBG7815 back to its factory- default configuration (for example, default Standard (Router) operation mode and login IP address of 192.168.123.1, WiFi SSID and password).
Page 19 Chapter 1 Introduction You can use the WPS button in the Web Configurator of the NBG7815 to activate WPS in order to quickly set up a WiFi network with strong security. Make sure the power LED is on (not blinking).
Page 20: Hardware Installation And Connection
H A P T E R Hardware Installation and Connection This chapter describes the front panel LED and rear panel of the NBG7815 and shows you how to mount the NBG7815 on the desk or wall. 2.1 Rear Panel The following figure show the rear panel of the NBG7815. The rear panel contains: Figure 9 Rear Panel The following table describes the items on the rear panel.
Page 21 The NBG7815 is upgrading firmware. Blinking (Fast) The NBG7815 is resetting. Purple Blinking WPS is in process. Purple Blinking The NBG7815 is receiving power and ready for use. and Dark Blue The NBG7815 detects Internet connection problems. Figure 11 Rear Panel NBG7815 User’s Guide...
Page 22: Desk Mounting
Press the button for longer than 8 seconds to return the NBG7815 to the factory defaults. 2.3 Desk Mounting Place the side of the NBG7815 with the attached rubber feet carefully on the desk. These rubber feet help protect the NBG7815 from shock or vibration and ensure space between the desk and NBG7815.
Page 23 Make sure the screws are fastened well enough to hold the weight of the NBG7815 with the connection cables. Remove the rubber feet. Align the holes on the back of the NBG7815 with the screws on the wall. Hang the NBG7815 on the screws. Figure 13 Wall Mounting – Rubber Feet...
Page 24: Wizard
Note: The wizard appears automatically when the NBG7815 is accessed for the first time or when you reset the NBG7815 to its default factory settings. Your NBG7815 will check the status of your Internet connection the first time you log in. NBG7815 User’s Guide...
Page 25 The following screen shows if you are not connected to the Internet. Note: You may need to turn off your network firewall if access to the Internet from the NBG7815 is blocked. You need to connect to the Internet to access your NBG7815. See Section 14.4 on page 148 if you cannot connect to the Internet.
Page 26 Password. Select the check box Keep 2.4G & 5G name the same if you want to use the same name for your 2.4G and 5G WiFi. Wait a moment for your WiFi settings to be applied to your NBG7815. NBG7815 User’s Guide...
Page 27 Chapter 3 Wizard The following screen shows if you have set up your WiFi name and password successfully. Click NEXT to go to the next step in the wizard. NBG7815 User’s Guide...
Page 28 Chapter 3 Wizard Wait a moment for the NBG7815 to check if your device is updated with the latest firmware. If not, your NBG7815 will automatically update the firmware. NBG7815 User’s Guide...
Page 29 You need to create a myZyxelCloud account to log into the NBG7815. The Zyxel cloud service gives you an online management site to configure and view the status of your NBG7815. Click NEXT to go to the next step in the wizard.
Page 30 Enter your Email and Password if you already have a myZyxelCloud account. If not, you can create one by clicking Sign Up. You can also click the Facebook or Google icon to create an account with your Facebook or Google account. NBG7815 User’s Guide...
Page 31 Chapter 3 Wizard 10 The legal page shows after you log in. Select the check box I understand and agree the Zyxel Cloud Terms of Use and then click Confirm. NBG7815 User’s Guide...
Page 32 11 The following page asks for your authorization to use your account. Click Authorize to finish registering your myZyxelcloud account. You will be directed back to the NBG7815 Web Configurator. 12 Wait a moment for your NBG7815 to link to your myZyxelcloud account.
Page 33 Chapter 3 Wizard 13 You can create a local password to access the NBG7815 directly. You can choose to log in with your myZyxelcloud account or your local password the next time you log in. Note: You can change your local password in System > General Settings. See Section 13.4 on...
Page 34: Tutorials
), and click Diagnose to open the Advanced Speed Test screen. Use this screen to view all the available connections in your NBG7815 system. Click TEST to perform a speed test. This shows data rates for both upstream and downstream traffic. Click TEST AGAIN to update the information.
Page 35: Configure The Nbg7815'S Wifi Networks
Click the Speed Test History tab to view a summary of the tests made. Click Clear to delete all records. 4.3 Configure the NBG7815’s WiFi Networks In the NBG7815 you can configure independent WiFi networks with different privileges. Clients can associate only with the network for which they have security settings (SSID and password). The following table describes the different NBG7815’s profile networks and their privileges.
Page 36 Select Keep 2.4G & 5G name the same, so they both use the same WiFi name. Select the WiFi security mode, bandwidth, and channel for the 2.4 GHz and 5 GHz networks. Click APPLY to save your changes. NBG7815 User’s Guide...
Page 37 Chapter 4 Tutorials NBG7815 User’s Guide...
Page 38: Enable Or Disable A Guest Wifi Network
Chapter 4 Tutorials 4.4 Enable or Disable a Guest WiFi Network After the NBG7815 is set up, you can use separate WiFi networks for your clients. The WiFi settings will be applied to all clients in the same network. Note: This is not available if you are using bridge mode.
Page 39: Add Clients To A Profile
BACK. 4.6 Configure a Profile’s WiFi Schedule When you create or edit a profile, you can schedule the NBG7815 to automatically disable or enable WiFi access during a certain period of time for clients in that profile. Note: This is not available if you are using bridge mode.
Page 40 Click the switch to activate the profile’s Internet schedule. Click the Edit icon ( ) to modify a profile’s Internet schedule. Click the start time cell and drag down to the end time to set up your schedule. NBG7815 User’s Guide...
Page 41: Pause Or Resume Internet Access On A Profile
Note: This is not available if you are using bridge mode. Click the Navigation Panel icon on the top-left corner ( ). Select Parental Control, and click the Profile tab. Use the Profile screen to display the profiles created in the NBG7815. NBG7815 User’s Guide...
Page 42: Turn On Or Off The Nbg7815'S Led (Light)
Click a profile’s RESUME button to resume network access at once, or click the QUICK BLOCK button to pause Internet access for that specific profile. 4.8 Turn on or off the NBG7815’s LED (Light) In the Overview screen, find the LED field and drag the button of the slider to increase the brightness or turn off the NBG7815’s LED.
Page 43: Change Your Nbg7815 Operating Mode
Chapter 4 Tutorials 4.9 Change Your NBG7815 Operating Mode The operating mode refers to how the NBG7815 is being used in the network. The NBG7815 has the following operating modes: • Standard: This is the NBG7815’s default mode. In this mode, the NBG7815 routes traffic between a local network and another network such as the Internet.
Page 44: Configure A Port Forwarding Rule
Note: This is not available if you are using bridge mode. Click the Navigation Panel icon on the top-left corner ( ). From the Settings drop-down list, select Internet, and click the NAT & Port Forwarding tab. NBG7815 User’s Guide...
Page 45 Click Add Rule to create a port forwarding rule. Add a service name, a port number or a range of ports to define the service to be forwarded, specify the transport layer protocol used for the service, and the IP address of a computer on your LAN that will receive the packets from the ports. NBG7815 User’s Guide...
Page 46 Chapter 4 Tutorials NBG7815 User’s Guide...
Page 47: Web Configurator
H A P T E R Web Configurator 5.1 Overview This chapter describes how to access the NBG7815 Web Configurator and provides an overview of its screens. The Web Configurator is an HTML-based management interface that allows easy system setup and management through Internet browser.
Page 48 Chapter 5 Web Configurator The NBG7815 Overview screen displays allowing you to monitor your NBG7815. It shows if the NBG7815 is online, and how many WiFi clients are currently connected to your NBG7815, as well as their upstream/ downstream data rates.
Page 49 Chapter 5 Web Configurator Figure 14 Overview (Standard Mode) NBG7815 User’s Guide...
Page 50: Navigation Panel
Chapter 5 Web Configurator Figure 15 Overview (Bridge Mode) 5.3 Navigation Panel Use the sub-menus on the navigation panel to configure NBG7815 features. Your navigation panel varies depending on the operating mode of your NBG7815. See Section 1.3 on page 15 for more information on standard (router) mode and bridge mode.
Page 51: Standard Mode Navigation Panel
• Change the brightness of your NBG7815’s LED Diagnose Advanced Use this screen to check the speed of the connection between your NBG7815 Speed Test and the broadband modem/router. Speed Test Use this screen to view a summary of previous speed tests.
Page 52 Set up file-sharing through the NBG7815 using File Explorer or the workgroup name • Configure the workgroup name and create file-sharing user accounts Use this screen to set up file sharing through the NBG7815 using FTP and create user accounts. USB Media Use this screen to configure settings for media sharing.
Page 53: Bridge Mode Navigation Panel
Set up file-sharing through the NBG7815 using File Explorer or the workgroup name • Configure the workgroup name and create file-sharing user accounts Use this screen to set up file sharing through the NBG7815 using FTP and create user accounts. USB Media Use this screen to configure settings for media sharing.
Page 54 Use this screen to upload firmware, reboot the NBG7815 without turning the power off or reset the NBG7815 to factory default. Operating Use this screen to select whether your NBG7815 acts as a router, or a bridge. Mode Logs Use this screen to view the list of activities recorded by your NBG7815.
Page 55: Standard Mode Status
H A P T E R Standard Mode Status 6.1 Overview Use the Status screen to view read-only information about your NBG7815 in standard (router) mode. 6.2 Standard Mode Status Click Settings > System > Status to open the status screen.
Page 56 This is the model name of your NBG7815. Firmware Version This is the firmware version. System Operation Mode This is the device mode to which the NBG7815 is set, see Section 13.7 on page 142 more information. Enable IPv4 Firewall This shows if the IPv4 firewall is enabled on the NBG7815.
Page 57 IP Subnet Mask This shows the LAN port’s subnet mask. DHCP Server This shows the LAN port’s DHCP role – Enable or Disable. IPv6 Address This shows the current IPv6 address of the NBG7815 in the LAN. NBG7815 User’s Guide...
Page 58: Bridge Mode Status
Log into the Web Configurator if you have not already. See the Quick start Guide for instructions on how to do this. To use your NBG7815 as a bridge, go to Settings > System > Operating Mode and select Bridge Mode. Figure 19 Changing to Bridge Mode Note: You have to log in to the Web Configurator again when you change modes.
Page 59: Accessing The Web Configurator In Bridge Mode
Connect your computer to one of the LAN port of the NBG7815. Connect a modem/router to the other LAN port of the NBG7815 using an Ethernet cable. If the NBG7815 is not connected to a router or DHCP server, the NBG7815 cannot assign your computer an IP address.
Page 60 This is the model name of your NBG7815. Firmware Version This is the firmware version. System Operation Mode This is the device mode to which the NBG7815 is set, see Section 13.7 on page 142 for more information. Enable IPv4 Firewall This shows if the IPv4 firewall is enabled on the NBG7815.
Page 61: Technical Reference
Technical Reference...
Page 62: Applications
(Section 8.3.3 on page 70). • Use the USB Application screen to allow file sharing or to set up your NBG7815 to act as a media server (Section 8.4 on page 72). 8.1.2 What You Need To Know The following terms and concepts may help as you read through this chapter.
Page 63: Before You Begin
Connect the USB device to the NBG7815’s USB port. The NBG7815 detects the USB device and makes its contents available for browsing. If you are connecting a USB hard drive that comes with an external power supply, make sure it is connected to an appropriate power source that is on.
Page 64: Device Setup
) to configure a rule for the client device. 8.2.1.1 Edit Device Detail Use this screen to configure basic settings for the client device. Click the Action icon , and then the Edit icon ( ) to show the following screen. NBG7815 User’s Guide...
Page 65 Enter a name for the client device to which this rule applies. Device Type Choose the type of client device to which this rule applies. APPLY Click APPLY to save your settings back to the NBG7815. CANCEL Click CANCEL to exit the screen without saving. 8.2.1.2 Add New Profile Use this screen to configure a restricted access schedule.
Page 66 WiFi on or off. DESELECT ALL Click DESELECT ALL to remove all WiFi scheduling. 8.2.1.3 Profile Screen Use this screen to edit or delete an existing rule. Click Parental Control > Profile to show the following screen. NBG7815 User’s Guide...
Page 67: Openvpn Server/Client
( ). Select OpenVPN Server, and click the OpenVPN Server tab. Figure 26 Example of NBG7815 Acting As VPN Server The NBG7815 (A) transmits data through a secure VPN channel (B) to the client device (C). NBG7815 User’s Guide...
Page 68 The fields define the network from which OpenVPN clients can connect to the NBG7815 OpenVPN server. Enter an IPv4 address and subnet mask. Advertise DNS to Clients Select Enable if you want the NBG7815 to broadcast its OpenVPN server to OpenVPN clients in its VPN network defined previously. NBG7815 User’s Guide...
Page 69: Openvpn Account
Click CANCEL to begin configuring this screen afresh. 8.3.2 OpenVPN Account Use the OpenVPN Account List screen to view the basic information of the NBG7815 OpenVPN server. Use the OpenVPN Account Status screen to view the basic information of clients that are connected to the NBG7815 OpenVPN server.
Page 70: Openvpn Client
Click CANCEL to exit this screen without saving. 8.3.3 OpenVPN Client Use the OpenVPN Server List in this screen to view the basic information of the OpenVPN Server accounts that you are connected to when the NBG7815 functions as an OpenVPN client. NBG7815 User’s Guide...
Page 71 Chapter 8 Applications Figure 30 Example of NBG7815 Acting As VPN Client The VPN server (A) transmits data through a secure VPN channel (B) to the NBG7815 (C) client device. Note: You can only connect to one server at a time.
Page 72: Usb Application
8.4 USB Application Configure file sharing through File Explorer / FTP with users on your network using a USB memory stick or hard drive connected to your NBG7815. You can also configure your NBG7815 to function as a DLNA- compliant media server.
Page 73: Samba Server
Chapter 8 Applications 8.4.1 SAMBA Server Use this screen to set up file-sharing through the NBG7815 using File Explorer or the workgroup name. You can also configure the workgroup name and create file-sharing user accounts. Click USB Application > SAMBA to show the following screen.
Page 74 Click to edit an existing port forwarding rule. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to begin configuring this screen afresh. 8.4.1.1 Add SAMBA Account Use this screen to configure settings for a SAMBA account.
Page 75: Ftp Server
Click CANCEL to exit the screen without saving. 8.4.2 FTP Server Use this screen to set up file sharing through the NBG7815 using FTP and create user accounts. Click USB Application > FTP to show the following screen. Figure 35 USB Application > FTP The following table describes the labels in this screen.
Page 76 Click to edit an existing port forwarding rule. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to begin configuring this screen afresh. 8.4.2.1 Add FTP Account Use this screen to configure settings for a FTP account.
Page 77: Usb Media Sharing
Enter the maximum bandwidth (in Kbps) allowed for incoming FTP traffic. Downstream Bandwidth Enter the maximum bandwidth (in Kbps) allowed for outgoing FTP traffic. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to exit the screen without saving. 8.4.3 USB Media Sharing Use this screen to configure settings for media sharing.
Page 78: Access Your Shared Files From A Computer
Rescan Media Control RESCAN Click this button to have the NBG7815 scan the media files on the connected USB device and do indexing of the file list again so that DLNA clients can find the new files if any. APPLY Click APPLY to save your changes back to the NBG7815.
Page 79: Using An Ftp Program
Once you access usb1 through your NBG7815, you do not have to re-login unless you restart your computer. 8.5.2 Using an FTP Program Here is how to use an FTP program to access a file storage device connected to the NBG7815’s USB port. Note: This example uses the FileZilla FTP program to browse your shared files.
Page 80 You can click the Edit or Delete icon to edit or delete the rules. Figure 39 FTP Setup Open FileZilla, enter the Host IP address of the NBG7815 (the default IP address is 192.168.123.1), the Username and Password, and the port number 21, and then click Quickconnect. A screen asking for password authentication appears.
Page 81 Chapter 8 Applications Figure 40 IFile Sharing through FTP Once you log in the USB device displays in the usb1 folder. NBG7815 User’s Guide...
Page 82: Wan
• Use the Internet Connection screen to enter your ISP information and set how the computer acquires its IP, DNS and WAN MAC addresses (Section 9.4 on page 85). • Use the NAT & Port Forwarding screen to enable NAT, set a default server and change your NBG7815’s port forwarding settings (Section 9.5 on page 94).
Page 83: What You Need To Know
The WAN IP address is an IP address for the NBG7815, which makes it accessible from an outside network. It is used by the NBG7815 to communicate with other devices in other networks. It can be static (fixed) or dynamically assigned by the ISP each time the NBG7815 tries to access the Internet.
Page 84 Use IPv6 Rapid Deployment (6rd) when the local network uses IPv6 and the ISP has an IPv4 network. When the NBG7815 has an IPv4 WAN address and you set IPv6/IPv4 Mode to IPv4 Only, you can enable 6rd to encapsulate IPv6 packets in IPv4 packets to cross the ISP’s IPv4 network.
Page 85: Internet Connection
Chapter 9 WAN Figure 42 IPv6 Rapid Deployment 9.4 Internet Connection Use this screen to change your NBG7815’s Internet access settings. The screen varies depending on the encapsulation method you select. Click Settings > Internet > Internet Connection. 9.4.1 IPoE Encapsulation This screen displays when you select IPoE encapsulation.
Page 86 Provider Type IPv4 / IPv6 Select IPv4 Only if you want the NBG7815 to run IPv4 only. Select Dual Stack to allow the NBG7815 to run IPv4 and IPv6 at the same time. IPv4 Address Automatic IP (DHCP) Select this option If your ISP did not assign you a fixed IP address. This is the default selection.
Page 87 Section 9.3.1 on page 83 for more information. The NAT, DHCP server and firewall functions on the NBG7815 are still available in this mode. IPv6 Address This section is NOT available when you select IPv4 Only in the IPv4/IPv6 field.
Page 88: Pppoe Encapsulation
By implementing PPPoE directly on the NBG7815 (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the NBG7815 does that part of the task. Furthermore, with NAT, all of the LANs’ computers will have access.
Page 89 The following table describes the labels in this screen. Table 27 Network > WAN > Internet Connection: PPPoE Encapsulation LABEL DESCRIPTION Internet Connection Internet Service Select PPPoE if you connect to your Internet through dial-up. Provider Type NBG7815 User’s Guide...
Page 90 Select this option and enter your WAN IP address if the ISP assigned a fixed IP address. WAN MAC Address The MAC address section allows users to configure the WAN port's MAC address by using the NBG7815’s MAC address, copying the MAC address from a computer on your LAN or manually entering a MAC address.
Page 91: Pptp Encapsulation
LAN & WAN Subnet Conflict Automatically Select this option to have the NBG7815 change its LAN IP address to 10.0.0.1 or 192.168.123.1 change the LAN IP accordingly when the NBG7815 gets a dynamic WAN IP address in the same subnet as the LAN IP address.
Page 92 Select PPTP if you want to connect the Internet through point to point tunneling protocol. Provider Type PPTP Username Enter the user name given to you by your ISP. Password Enter the password associated with the user name above. NBG7815 User’s Guide...
Page 93 LAN IP address. See Section 9.3.1 on page 83 for more information. The NAT, DHCP server and firewall functions on the NBG7815 are still available in this mode. APPLY Click APPLY to save your changes back to the NBG7815.
Page 94: Nat And Port Forwarding
(B in the example) and assign a default server IP address of 192.168.123.35 to a third (C in the example). You assign the LAN IP addresses and the ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet. Figure 46 Multiple Servers Behind NAT Example NBG7815 User’s Guide...
Page 95 Chapter 9 WAN Use this screen to enable NAT, set a default server and view the summary table of your NBG7815’s port forwarding settings. Click Settings > Internet > NAT & Port Forwarding to show the following screen. Figure 47 Settings > Internet > NAT & Port Forwarding The following table describes the labels in this screen.
Page 96: Add Port Forwarding Rule
Click CANCEL to begin configuring this screen afresh. 9.5.1 Add Port Forwarding Rule Use this screen to configure your NBG7815’s port forwarding settings to forward incoming service requests to the servers on your local network. Click Settings > Internet > NAT & Port Forwarding > Add Rule to show the following screen.
Page 97: Passthrough
CANCEL Click CANCEL to exit this screen without saving. 9.6 Passthrough Use this screen to change your NBG7815’s ALGs and VPN pass-through settings. Click Settings > Internet > Passthrough to show the following screen. ALG Overview Application Layer Gateway (ALG) allows the following applications to operate properly through the NBG7815’s NAT.
Page 98 PPTP VPN account. If PPTP is disabled, then when a client sends a request to a VPN server, the server will reply to the NBG7815 and the NBG7815 will drop the request. When PPTP is enabled, the NBG7815 will forward the reply from the VPN server to the client that initiated the request, and the connection will establish successfully.
Page 99: Port Trigger
Port trigger addresses this problem. Port trigger allows computers on the LAN to dynamically take turns using the service. The NBG7815 records the IP address of a LAN computer that sends traffic to the WAN to request a service with a specific port number and protocol (a "trigger" port). When the NBG7815's WAN port receives a response with a specific port number and protocol ("open"...
Page 100: Add Port Trigger Rule
The NBG7815 forwards the traffic to Jane’s computer IP address. Only Jane can connect to the Real Audio server until the connection is closed or times out. The NBG7815 times out in 3 minutes with UDP (User Datagram Protocol) or 2 hours with TCP/IP (Transfer Control Protocol/Internet Protocol).
Page 101: Dynamic Dns
Enter a port number or the ending port number in a range of port numbers. Trigger Port The trigger port is a port (or a range of ports) that causes (or triggers) the NBG7815 to record the IP address of the LAN computer that sent the traffic to a server on the WAN.
Page 102: Upnp
Enter your user name. Password Enter the password assigned to you. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to begin configuring this screen afresh. 9.9 UPnP Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer-to-peer network connectivity between devices.
Page 103: Turning On Upnp In Windows 10 Example
Chapter 9 WAN Use this screen to enable UPnP on your NBG7815. Click Settings > Internet > UPnP to display the following screen. Figure 54 Settings > Internet > UPnP The following table describes the labels in this screen. Table 35 Settings > Internet > UPnP...
Page 104 Chapter 9 WAN Click Network and Sharing Center. Click Change advanced sharing settings. NBG7815 User’s Guide...
Page 105 Under Domain, select Turn on network discovery and click Save Changes. Network discovery allows your computer to find other computers and devices on the network and other computers on the network to find your computer. This makes it easier to share files and printers. NBG7815 User’s Guide...
Page 106: Wireless Lan
• Use the Guest WiFi screen to set up multiple WiFi networks on your NBG7815 (Section 10.3 on page 113). • Use the MAC Filter screen to allow or deny WiFi stations from connecting to the NBG7815 based on their MAC address (Section 10.4 on page 114).
Page 107: What You Should Know
Some WiFi devices, such as scanners, can detect WiFi networks but cannot use WiFi networks. These kinds of WiFi devices might not have MAC addresses. Hexadecimal characters are 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, and F. NBG7815 User’s Guide...
Page 108 Guest WiFi Guest WiFi allows you to set up a WiFi network where users can access to Internet through the NBG7815 (Z), but not other networks connected to it. In the following figure, a guest user can access the Internet from the guest WiFi network A through Z but not the home or company network N.
Page 109 PIN (Personal Identification Number) in the client devices. They then connect and set up a secure network by themselves. See how to set up a secure WiFi network using WPS in Section 4.2 on page NBG7815 User’s Guide...
Page 110: Main Wifi
Use this screen to configure the SSID and WiFi security of the NBG7815’s default WiFi. Note: If you are configuring the NBG7815 from a computer connected to the WiFi and you change the NBG7815’s SSID, channel or security settings, you will lose your WiFi connection when you press Apply to confirm.
Page 111 Chapter 10 Wireless LAN Figure 58 Settings > WiFi > Main WiFi NBG7815 User’s Guide...
Page 112 Password The password has two uses: • Manual: Manually enter the same password on the NBG7815 and the client. Enter 8 – 63 ASCII characters or exactly 64 hexadecimal (‘0 – 9’, ‘a – f’) characters. • WPS: When using WPS, the NBG7815 sends this password to the client.
Page 113: Guest Wifi
WiFi Name (SSID) An SSID profile is the set of parameters relating to one of the NBG7815’s BSSs. The SSID (Service Set IDentifier) identifies the Service Set with which a WiFi device is associated. This field displays the name of the WiFi profile on the network. When a WiFi client scans for an AP to associate with, this is the name that is broadcast and seen in the WiFi client utility.
Page 114: Mac Filter
00:A0:C5:00:00:02. You need to know the MAC address of the devices to configure this screen. Use this screen to change your NBG7815’s MAC filter settings. Click Settings > WiFi > MAC Filter to show following screen. Figure 60 Settings > WiFi > MAC Filter The following table describes the labels in this screen.
Page 115: Add Mac Address
MAC address. Click to add a rule in the MAC Address List. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to reload the previous configuration for this screen. 10.4.1 Add MAC Address Use this screen to configure the MAC address you want to add to the MAC address list.
Page 116 This is the 802.11 mode used. Only compliant WiFi devices can associate with the NBG7815. SSID This is the name of the WiFi network (the NBG7815’s first SSID) that WPS clients connect to. Security This is the type of WiFi security employed by the network.
Page 117: Scheduling
Click SELECT ALL or click gray blocks to specify days and times to turn the WiFi on or off. If you click SELECT ALL you can not select any specific days and times. DESELECT ALL Click DESELECT ALL to remove all the WiFi scheduling. NBG7815 User’s Guide...
Page 118: Lan
The LAN screens can help you configure a manage IP addresses and partition your physical network into logical networks. 11.2 What You Can Do • Use the LAN IP screen to configure the IPv4 addresses for your NBG7815 on the LAN (Section 11.4 on page 119).
Page 119: Lan Ip
These parameters should work for the majority of installations. 11.4 LAN IP Use this screen to change the IPv4 address for your NBG7815 in standard (router) mode. Click Settings > LAN > LAN IP to show the following screen. NBG7815 User’s Guide...
Page 120 Chapter 11 LAN Figure 66 Settings > LAN > LAN IP (Standard Mode) NBG7815 User’s Guide...
Page 121 Enter the IPv4 address of your NBG7815 in dotted decimal notation. IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your NBG7815 will automatically calculate the subnet mask based on the IP address that you assign. Unless you are implementing subnetting, use the subnet mask computed by the NBG7815.
Page 122: Static Dhcp Table-Add/Edit Rule
First DNS Server Select Obtained From ISP if your ISP dynamically assigns DNS server information (and the NBG7815's WAN IP address). The field to the right displays the (read-only) DNS server IP Second DNS Server address that the ISP assigns.
Page 123 This field displays the IP address of a computer on your LAN. If you select User- Defined in the Device List field, enter the IP addresses manually. APPLY Click APPLY to save your changes back to the NBG7815. CANCEL Click CANCEL to exit this screen without saving.
Page 124: Configure Lan Screen In Bridge Mode
Click Settings > LAN > LAN IP to show the following screen. Note: If you change the IP address of the NBG7815 in the screen below, you will need to log into the NBG7815 again using the new IP address.
Page 125: Ipv6 Lan
Click CANCEL to reload the previous configuration for this screen. 11.5 IPv6 LAN Use this screen to configure the IPv6 address for your NBG7815 on the LAN. Click Settings > LAN > IPv6 LAN to show the following screen. Note: This is not available if you are using bridge mode.
Page 126 DESCRIPTION LAN IPv6 Address Assignment Enable DHCPv6-PD Select this option to use DHCPv6 prefix delegation. The NBG7815 will obtain an IPv6 prefix from the ISP or a connected uplink router for the LAN. Autoconfiguration Select SLAAC + RDNSS to enable IPv6 stateless auto-configuration on this interface. The...
Page 127 Enter the valid lifetime for the prefix. Link Local Only Select this option to only use the link local address on the NBG7815 interfaces in the LAN. Select this option to identify a unique local address of the NBG7815 in the LAN.
Page 128: Security
Security 12.1 Overview Use these screens to enable and configure the firewall that protects your NBG7815 and your LAN from unwanted or malicious traffic. Enable the firewall to protect your LAN computers from attacks by hackers on the Internet and control access between the LAN and WAN.
Page 129: Ipv4 Firewall
Protect against IP spoofing by making sure the firewall is active. Keep the firewall in a secured (locked) room. 12.2 IPv4 Firewall Use this screen to enable or disable the NBG7815’s IPv4 firewall. Click Settings > Firewall > IPv4 Firewall to show the following screen. NBG7815 User’s Guide...
Page 130 Respond to Ping The NBG7815 will not respond to any incoming Ping requests when None is selected. Select LAN to reply to incoming LAN Ping requests. Select WAN to reply to incoming WAN Ping requests. Otherwise select LAN&WAN to reply to all incoming LAN and WAN Ping requests.
Page 131: Ipv4 Firewall - Add Rule
Use this screen to configure IPv4 firewall rule. Click Settings > Firewall > IPv4 Firewall > Add Rule to open the following screen. Note: For a comprehensive list of port numbers and services, visit the IANA (Internet Assigned Number Authority) website. Figure 74 Settings > Firewall > IPv4 Firewall > Add Rule NBG7815 User’s Guide...
Page 132: Ipv6 Firewall
Enter the IP address of the computer to which traffic for the application or service is entering. The NBG7815 applies the firewall rule to traffic initiating from this computer. Source IP Address Enter the IP address of the computer that initializes traffic for the application or service.
Page 133: Ipv6 Firewall - Add Rule
LABEL DESCRIPTION Configuration Simple Security Select Enable to enabled simple security on your NBG7815. Rule Status Select Enable to enabled rule status on your NBG7815. Action Select DROP to silently discard the packets which meet the firewall rules. The others are accepted.
Page 134 Enter the IP address of the computer to which traffic for the application or service is entering. The NBG7815 applies the firewall rule to traffic initiating from this computer. Source IP Address Enter the IP address of the computer that initializes traffic for the application or service.
Page 135: System
NBG7815 to factory defaults (Section 13.6 on page 141). • Use the Operating Mode screen select whether you want the NBG7815 to act as a router or a bridge (Section 13.7 on page 142). • Use the Logs screen to see the system logs recorded by the NBG7815 (Section 13.8 on page...
Page 136 Chapter 13 System Figure 77 Settings > System > Status (Standard Mode) NBG7815 User’s Guide...
Page 137 This is the model name of your NBG7815. Firmware Version This is the firmware version. System Operation Mode This is the device mode in which the NBG7815 is currently running. See Section 13.7 on page 142 for more information. Enable IPv4 Firewall This shows if the IPv4 firewall is enabled on the NBG7815.
Page 138: General Setting
Table 50 Settings > System > Status (continued) LABEL DESCRIPTION DHCP Server This shows whether the NBG7815 acts as a DHCP Server and provides LAN IP addresses to its clients or not. IPv6 Address This shows the current LAN IPv6 address of the NBG7815.
Page 139 LABEL DESCRIPTION System Settings System Name System Name is a unique name to identify the NBG7815 in an Ethernet network. Domain Name Enter the domain name you want to give to the NBG7815. (This is not available if you are using...
Page 140: Remote Access
Chapter 13 System 13.5 Remote Access Use this screen to change your NBG7815’s remote management settings. You can use HTTPS or Wake on LAN to access and manage the NBG7815. Wake On LAN (WoL) allows you to remotely turn on a device on the network, such as a computer, storage device or media server.
Page 141: Maintenance Setup
Click the RESET TO FACTORY DEFAULT button in this section to clear all user-entered configuration information and returns the NBG7815 to its factory defaults. You can also press the Reset button on the rear panel to reset the factory defaults of your NBG7815. Click Settings > System > Maintenance to show the following screen.
Page 142: Operating Mode
Use this screen to select how you want to use your NBG7815. The Operating Mode function lets you configure your NBG7815 as a router or bridge. You can choose between Standard Mode, and Bridge Mode depending on your network topology and the features you require from your NBG7815.
Page 143: Logs
The DHCP server on your device is disabled. • Router functions (such as NAT, bandwidth management, remote management, firewall and so on) are not available when the NBG7815 is in Bridge Mode. • The IP address of the device on the local network is set to 192.168.123.2.
Page 144 Chapter 13 System Figure 84 Settings > System > Logs NBG7815 User’s Guide...
Page 145: Troubleshooting And Appendices
Troubleshooting and Appendices...
Page 146: Troubleshooting
• Make sure you are using the power adapter or cord included with the NBG7815. • Make sure the power adapter or cord is connected to the NBG7815 and plugged in to an appropriate power source. Make sure the power source is turned on.
Page 147: Nbg7815 Access And Login
The default IP address of the NBG7815 in Bridge Mode is 192.168.123.2. • If you changed the IP address and have forgotten it, you might get the IP address of the NBG7815 in Standard Mode by looking up the IP address of the default gateway for your computer. To do this in most Windows computers, click Start >...
Page 148: Internet Access
Internet access. Your computer and the NBG7815 should be in the same subnet. If the NBG7815 is in Bridge Mode, make sure the WAN port is connected to a broadband modem or router with Internet access and your computer is set to obtain an dynamic IP address.
Page 149: Resetting The Nbg7815 To Its Factory Defaults
The Internet connection is slow or intermittent. • There might be a lot of traffic on the network. Look at the LEDs. If the NBG7815 is sending or receiving a lot of information, try closing some programs that use the Internet, especially peer-to-peer applications.
Page 150 • Make sure your computer (with a WiFi adapter installed) is within the transmission range of the NBG7815. • Check that both the NBG7815 and the WiFi adapter on your computer are using the same WiFi and WiFi security settings.
Page 151: Usb File Sharing Problems
• If the USB device requires a special driver, install the driver from the installation disc that came with the device. After driver installation, reconnect the USB device to the NBG7815 and try to connect to it again with your computer.
Page 152: Appendix A Customer Support
• Brief description of the problem and the steps you took to solve it. Corporate Headquarters (Worldwide) Taiwan • Zyxel Communications Corporation • https://www.zyxel.com Asia China • Zyxel Communications (Shanghai) Corp. Zyxel Communications (Beijing) Corp. Zyxel Communications (Tianjin) Corp. • https://www.zyxel.com/cn/zh/ India • Zyxel Technology India Pvt Ltd. • https://www.zyxel.com/in/en/ Kazakhstan •...
Page 153 • Zyxel Singapore Pte Ltd. • http://www.zyxel.com.sg Taiwan • Zyxel Communications Corporation • https://www.zyxel.com/tw/zh/ Thailand • Zyxel Thailand Co., Ltd. • https://www.zyxel.com/th/th/ Vietnam • Zyxel Communications Corporation-Vietnam Office • https://www.zyxel.com/vn/vi Europe Belarus • Zyxel BY • https://www.zyxel.by Bulgaria • Zyxel България • https://www.zyxel.com/bg/bg/...
Page 154 Appendix A Customer Support Czech Republic • Zyxel Communications Czech s.r.o • https://www.zyxel.com/cz/cs/ Denmark • Zyxel Communications A/S • https://www.zyxel.com/dk/da/ Finland • Zyxel Communications • https://www.zyxel.com/fi/fi/ France • Zyxel France • https://www.zyxel.fr Germany • Zyxel Deutschland GmbH • https://www.zyxel.com/de/de/ Hungary •...
Page 155 Appendix A Customer Support • https://www.zyxel.com/ro/ro Russia • Zyxel Russia • https://www.zyxel.com/ru/ru/ Slovakia • Zyxel Communications Czech s.r.o. organizacna zlozka • https://www.zyxel.com/sk/sk/ Spain • Zyxel Communications ES Ltd. • https://www.zyxel.com/es/es/ Sweden • Zyxel Communications • https://www.zyxel.com/se/sv/ Switzerland • Studerus AG •...
Page 156 • https://www.zyxel.com/co/es/ Ecuador • Zyxel Communications Corporation • https://www.zyxel.com/co/es/ South America • Zyxel Communications Corporation • https://www.zyxel.com/co/es/ Middle East Israel • Zyxel Communications Corporation • http://il.zyxel.com/ North America • Zyxel Communications, Inc. – North America Headquarters • https://www.zyxel.com/us/en/ NBG7815 User’s Guide...
Page 157: Appendix B Setting Up Your Computer's Ip Address
P P E N D I X Setting Up Your Computer’s IP Address Note: The NBG7815 may not support all of the operating systems described in this appendix. See the product specifications for more information about which operating systems are supported.
Page 158 Appendix B Setting Up Your Computer’s IP Address In the Network & Internet panel, click Ethernet. Click Change adapter options. The Network Connections panel opens. NBG7815 User’s Guide...
Page 159 Appendix B Setting Up Your Computer’s IP Address Right-click the Ethernet network you are connected to, then select Properties. Double-click Internet Protocol Version 4 (TCP/IPv4). NBG7815 User’s Guide...
Page 160 ISP. You may also have to enter a Preferred DNS server and an Alternate DNS server, if that information was provided. Click Advanced if you want to configure advanced settings for IP, DNS and WINS. Click OK to close the Internet Protocol Version 4 (TCP/IPv4) Properties window. Click OK to close the Ethernet Properties window. NBG7815 User’s Guide...
Page 161 In the Command Prompt window, enter "ipconfig" and then press [ENTER]. The IP settings are displayed as follows. macOS: Big Sur 11 The screens in this section are from macOS Big Sur (v11). Click Apple > System Preferences. In the System Preferences window, click the Network icon. NBG7815 User’s Guide...
Page 162 Select the TCP/IP tab to configure IP settings. For dynamically assigned settings, select Using DHCP from the Configure IPv4 list. For statically assigned settings, do the following: • From the Configure IPv4 list, select Manually. • In the IP Address field, enter your IP address. NBG7815 User’s Guide...
Page 163 Appendix B Setting Up Your Computer’s IP Address • In the Subnet Mask field, enter your subnet mask. • In the Router field, enter the IP address of your NBG7815. Click OK. Click Apply on the Network panel to apply the settings.
Page 164 Ubuntu 8 installation. Note: Make sure you are logged in as the root administrator. Follow the steps below to configure your computer’s IP address in GNOME: Click Activities (upper left) to open the search panel. NBG7815 User’s Guide...
Page 165 Appendix B Setting Up Your Computer’s IP Address Enter “network” and the system will display the search results related to “network”. Click Network to open the Network panel. Click the settings icon of the connection you want to configure. NBG7815 User’s Guide...
Page 166 Gateway address fields. Enter the DNS settings if you know your DNS server IP addresses. • Alternatively, select Automatic (DHCP) if you are assigned a dynamic IP address. Click Apply to save the configuration. Note: The configuration will be applied after rebooting or connection interface restart. NBG7815 User’s Guide...
Page 167 Appendix B Setting Up Your Computer’s IP Address To apply the configuration, click the switch to turn off and on to restart the connection interface. Verify the Settings Check your TCP/IP properties by opening the connection settings panel and selecting the Details tab. NBG7815 User’s Guide...
Page 168 Click K Menu > Computer > Administrator Settings (YaST). When the Run as Root – KDE su dialog opens, enter the Administrator Password and click OK. When the YaST Control Center window opens, select Network Devices and then click the Network Card icon. NBG7815 User’s Guide...
Page 169 Appendix B Setting Up Your Computer’s IP Address When the Network Settings window opens, click the Overview tab. Select the appropriate connection Name from the list, and then click the Configure button. When the Network Card Setup window opens, click the Address tab. NBG7815 User’s Guide...
Page 170 Click Next to save the changes and close the Network Card Setup window. If you know your DNS server IP addresses, click the Hostname/DNS tab in Network Settings and then enter the DNS server information in the fields provided. NBG7815 User’s Guide...
Page 171 Click the KNetwork Manager icon on the Task bar to check your TCP/IP properties. From the Options sub- menu, select Show Connection Information. When the Connection Status – KNetwork Manager window opens, click the Statistics tab to check if your connection is working properly. NBG7815 User’s Guide...
Page 172 Appendix B Setting Up Your Computer’s IP Address NBG7815 User’s Guide...
Page 173: Appendix C Legal Information
Regulatory Notice and Statement UNITED STATES of AMERICA The following information applies if you use the product within USA area. US Importer: Zyxel Communications, Inc, 1130 North Miller Street Anaheim, CA92806-2001, https://www.zyxel.com/us/en/ FCC EMC Statement • The device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 174 • 2.4 GHz frekvenèu joslas izmantoðanai ârpus telpâm nepiecieðama atïauja no Elektronisko sakaru direkcijas. Vairâk informâcijas: http://www.esd.lv. Lietuvių kalba Šiuo Zyxel deklaruoja, kad šis įranga atitinka esminius reikalavimus ir kitas 2014/53/ES Direktyvos nuostatas. (Lithuanian) NBG7815 User’s Guide...
Page 175 Do not install, use, or service this device during a thunderstorm. There is a remote risk of electric shock from lightning. • Connect ONLY suitable accessories to the device. • Do not open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. NBG7815 User’s Guide...
Page 176 återvinningsstation. Vid tiden för kasseringen bidrar du till en bättre miljö och mänsklig hälsa genom att göra dig av med den på ett återvinningsställe. 台灣以下訊息僅適用於產品具有無線功能且銷售至台灣地區 • 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 • 無線資訊傳輸設備的製造廠商應確保頻率穩定性，如依製造廠商使用手冊上所述正常操作，發射的信號應維持於操作頻帶中。 • 使用無線產品時，應避免影響附近雷達系統之操作。 • 高增益指向性天線只得應用於固定式點對點系統。 NBG7815 User’s Guide...
Page 177 Any replacement will consist of a new or re-manufactured functionally equivalent product of equal or higher value, and will be solely at the discretion of Zyxel. This warranty shall not apply if the product has been modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. NBG7815 User’s Guide...
Page 178 Register your product online at www.zyxel.com to receive email notices of firmware upgrades and related information. Open Source Licenses This product contains in part some free software distributed under GPL license terms and/or GPL like licenses. To request the source code covered under these licenses, please go to: https://www.zyxel.com/form/gpl_oss_software_notice.shtml NBG7815 User’s Guide...
Page 179: Index
AP Mode Common Internet File System, see CIFS menu configuration AP+Bridge back up Application Layer Gateway, see ALG connection speed applications check NBG7815 contact information ARMOR mobile app cooling the NBG7815 Auto-IP Change desk-mount conditions copyright customer support NBG7815 User’s Guide...
Page 180 FileZilla dual-band WiFi filter action Dynamic DNS firewall enable first guidelines Dynamic DNS screen ICMP packet DynDNS 132, 134 stateful inspection DynDNS see also DDNS 132, 134 turn off firewall action default firewall rule activate firmware NBG7815 User’s Guide...
Page 181 IPv6 stateless auto-configuration http enable //(DHCP-assigned IP) HTTP (Hypertext Transfer Protocol) ISP (Internet Service Provider) IANA (Internet Assigned Number Authority) IEEE 802.11a/b/g/n/ac/ax compliant Java enabled IEEE 802.3bz Java permission Internet access JavaScript 47, 147 pause/resume on profile problem NBG7815 User’s Guide...
Page 182 Bluetooth pairing media sharing description firmware upgrade reset the NBG7815 Microsoft Point-to-Point Encryption (MPPE) turn on/off mode WPS in process MTU (Maximum Transmission Unit) 87, 93 local (user) database Multi-Gigabit (IEEE 802.3bz)
Page 183 PIN (Personal Identification Number) Reset hole ping RESET TO FACTORY DEFAULT button Point-to-Point Protocol over Ethernet resource unit (RU) pop-up window restart web browser system port router mode Ethernet WAN 20, 22 status screen 20, 22 RTSP 20, 22 NBG7815 User’s Guide...
Page 184 112, 113 WiFi security policy and ALG TCP port 7547 security setting Telnet WiFi network access the NBG7815 Server Message Block, see SMB transmission range server port number WiFi service provider transmission speed Dynamic DNS cable type Service Set...
Page 185 107, 116, 149 overview type WiFi security setting WiFi tutorial Wake On LAN (WoL) WiFi5 (802.11ac) wall mounting WiFi6 (802.11ax) information Windows Media Player NBG7815 wireless LAN WAN (Wide Area Network) wizard WAN information accessing WAN IP address NBG7815 User’s Guide...
Page 186 Index overview setup workgroup name Windows WPA-PSK (WiFi Protected Access-Pre-Shared Key) activate WPS (WiFi Protected Setup) WPS button in Web Configurator WPS in process WPS screen WPS-aware WiFi station NBG7815 User’s Guide...
