• Schedule Mode
• Queue Shaper Enable
• Queue Shaper Rate
• Queue Shaper Unit
• Queue Shaper Excess
• Queue Scheduler
Weight
• Queue Scheduler
Percent
• Port Shaper Enable
• Port Shaper Rate
•
Port Shaper Unit
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the previous page.
4.4.2.3 Port Shaping
This page provides an overview of QoS Egress Port Shapers for all switch ports. The Port shaping screen in
appears.
Controls whether the scheduler mode is "Strict Priority" or "Weighted" on this
switch port.
Controls whether the queue shaper is enabled for this queue on this switch port.
Controls the rate for the queue shaper.
This value is restricted to 100-1000000 when the "Unit" is "kbps", and it is
restricted to 1-13200 when the "Unit" is "Mbps".
The default value is 500.
Controls the unit of measure for the queue shaper rate as "kbps" or "Mbps".
The default value is "kbps".
Controls whether the queue is allowed to use excess bandwidth.
Controls the weight for this queue.
This value is restricted to 1-100. This parameter is only shown if "Scheduler
Mode" is set to "Weighted".
The default value is "17".
Shows the weight in percent for this queue. This parameter is only shown if
"Scheduler Mode" is set to "Weighted".
Controls whether the port shaper is enabled for this switch port.
Controls the rate for the port shaper.
This value is restricted to 100-1000000 when the "Unit" is "kbps", and it is
restricted to 1-13200 when the "Unit" is "Mbps".
The default value is 500.
Controls the unit of measure for the port shaper rate as "kbps" or "Mbps".
The default value is "kbps".
256
User's Manual of IGS PoE series
Figure 4-4-2-3
