User Guide
e. Slide the retention clip forward until it stops near the cable connector. Doing this will
ensure that the retention clip functions properly in the event the cable is pulled on for
some reason.
Step 8 : Make sure the CMA(s) is in operational position by folding the arm(s) in toward the enclosure and
attaching the elbow end(s) to the connector(s) attached to the rail. Verify that all of the cabling is
in functional order and does not bind or catch.
4.4 Rear Fan Replacement
Figure 49: Cable Retention Mechanism
Figure 50: Cinching Cable Retention Clip
4. Part Replacement
4.4 Rear Fan Replacement
67
