Unicast Address Table

Table 8-3 RMON Statistics Screen Field Descriptions (Continued)
Use this field...
Refresh Statistics command
Reset Counters command
PORT
8.3.1

Displaying RMON Statistics

To display the statistics for any index, proceed as follows:
1. Use the arrow keys to highlight the PORT field at the bottom of the screen.
2. Type the Port number into the PORT field.
3. Press ENTER (neither the RMON Statistics Port field nor the statistics will change until ENTER
is pressed).
8.4 UNICAST ADDRESS TABLE
Screen Navigation Path
Password > Main Menu > Network Monitor Menu > Unicast Address Table
When to Use
To search for a specific address, clear the entire address table or information associated with a
specific address, or set the aging time for deleting inactive entries. This screen contains the MAC
addresses and VLAN identifier associated with each port (that is, the source port associated with
the address and VLAN), sorted by MAC address or VLAN ID.
How to Access
Use the arrow keys to highlight the Unicast Address Table menu item on the Network Monitor
Menu screen and press ENTER. The Unicast Address Table screen,
8-10 Network Monitoring Menu Screens
To...
Refreshes the screen to see the most current statistics.
Temporarily reset all counters of a screen to zero to allow
you to observe counter activity over a period of time.
Enter the number of the port to view its statistics.
Figure 8-4, displays.
