7.17 BROADCAST STORM CONTROL CONFIGURATION SCREEN

NOTE: Broadcast frames, per second, received above the threshold setting in this
screen are dropped.
Screen Navigation Path
Password > Main Menu > Device Control Menu > Broadcast Storm Control Configuration
When to Use
To set the limit on the received broadcast frames that are switched out to other ports.
How to Access
Use the arrow keys to highlight the Broadcast Storm Control Configuration menu item on the
Device Control Menu screen and press ENTER. The Broadcast Storm Control Configuration
screen, Figure 7-22, displays.
Screen Example
Figure 7-22 Broadcast Storm Control Configuration Screen
Broadcast Storm Control Configuration Screen
Device Control Menu Screens 7-47
