Dual rate/exp.

The dual rate/exp. function only applies to channels 1,2,4.
Dual Rate: Dual Rate reduces or increases the difference between the highest and lowest possible value,
for example if applied to the rudder, (set to a throw of 10cm) before changing the settings, when you
move your stick to 1/2 you would get 5cm rudder movement, if you move the stick 1/4 of the way, the
rudder will move 2.5cm, so at 100% there is a direct, linear relationship of stick movement and surface
movement.
If a setting of 50% is entered then moving the stick all the way in one direction will only give 1/2 of the
surface movement and 1/2 stick movement will only produce 1/4 surface movement, this has the effect
of reducing how responsive the rudder is when the stick is moved, effectively reducing the range of
movement available to the servo. This function is usually assigned to a condition so that it can be turned
on and off during flight.
Exp. (Exponential) Exponential changes the relationship between stick movement and surface movement
by creating a curve, when in use the stick movement and surface movement are no longer linear so the
stick has a different response in different at different positions. For example this is useful when needing
less reaction during a take-off but more reaction when in the ai r.
Setup:
1. Press the "OK" to change between settings.
Use the "UP" and "DOWN" keys to change the channel/rate/ *Chi
2.
depending on the selected setting. RateExp
Hold the "CANCEL" key to save and return to the previous menu.
3.
To return a setting to default, press and hold the "OK" key for 3 seconds. Press and hold the
4.
"CANCEL" key to save.

5.8 Throttle curve

This function enables the user to adjust the ratio between stick and servo movement using a linear line
or non-linear curves.
This is useful when wanting to change how the throttle reacts at between different stick positions, for
example having a smaller throttle change when the stick is between 0-30%, then a larger throttle change
between 30% and 100%. If your models throttle is not linear, it is also possible to use this function to
create a more linear movement.
This function uses 5 points to change the throttle curve, L being the low and H being the high.
