OptiView TM Series III
Getting Started Guide

The Analyzer and Accessories

The analyzer is designed for troubleshooting and monitoring Local Area Networks
(LANs). The analyzer tests all seven OSI layers. It tests from the cable to the
application layer and everything in between, so problems have nowhere to hide.
OptiView
(RJ-45 jack) along with a 1000BASE-X port (fiber optic interface) that supports
the following optional fiber dapters: 1000BASE-SX (850nm), 1000BASE-LX
(1300nm), 1000BASE-LX10 (1310nm), 1000BASE-BX (1490nm), and
1000BASE-ZX (1440nm). Check
supported fiber adapters.
OptiView Series III
External Battery Pack
Stylus
Figure 1. The Standard OptiView
4
Series III supports 10/100/1000 Ethernet through 10/100/1000 Port
TM
AC Adapter/
Charger
TM
Series III Integrated Network Analyzer and Supplied
Accessories
www.flukenetworks.com
Getting
Started
Softcase
Guide
Power Cord
for additional
Registration
CD
Card
Startup III
Card
aww01f.eps
