Engine Dimensions - Opposite Starter Side

M
A Lifting Point
E Lifting Point
I 652.3 mm (25.68 in.)
M Muffl er (optional)
62 690 05 Rev. E
L
I
B Cylinder #2 Shroud
Fuel Filter
F Fits 6.4 mm (0.25 in.)
Fuel Line
Oil Drain Plug
J
1/2 NPT Inch
KohlerEngines.com
A
B
K
J
C Access to Oil Cooler
70.5 mm (2.78 in.)
G
Exhaust Port #2
Engine Mounting
K
Surface
Specifi cations
C
G
H
156.2 mm (6.15 in.)
D Cylinder #2 Shroud
Removal
H Mounting Hole "A"
L 2.6 mm (0.10 in.)
D
E
F
