Engine Dimensions - PTO Side (Later Design)

M
L
A 428.1 mm (16.86 in.)
60 mm (2.36 in.)
E
Exhaust Port #2
I Rotation Direction
M 275.2 mm (10.84 in.)
62 690 05 Rev. E
O
C
B
N
K
J
B 45°
M8 X 1.25 mm
F
4 Studs
J 89.8 mm (3.54 in.)
60.0 mm (2.36 in.)
N
Exhaust Port #1
KohlerEngines.com
A
C
B
B
I
C 35°
Ø 254.0 mm (10.0
G
K Mounting Hole "A"
O 124.2 mm (4.89 in.)
Specifi cations
B
E
F
G
H
2X Ø 35 mm (1.38 in.)
D
Muffl er Gasket
3/8-16 UNF-2B Inch
H 30 mm (1.18 in.)
in.)
Deep 4 Holes
L 89.8 mm (3.54 in.)
D
7
