Specifi cations

Engine Dimensions - Starter Side

M
L K
A 680.8 mm (26.80 in.)
E 80.2 mm (3.16 in.)
I Mounting Hole "A"
M Grass Screen
8
N
J
I
H
93.5 mm (3.68 in.)
B
Exhaust Port #1
6.4 mm (0.25 in.)
F
Square Keyway
156.2 mm (6.15 in.)
J Cylinder #1 Shroud
Removal
N Cylinder #1 Shroud
KohlerEngines.com
O
C
E
D
F
G
C Oil Pressure Switch
7/16-20 UNF-2B Inch
G 38.1 mm (1.50 in.)
Deep
K 389.8 mm (15.35 in.)
50.0 mm (1.97 in.)
O
Oil Filter Removal
A
B
Engine Mounting
D
Surface
H Ø 28.6 mm (1.13 in.)
L 423.2 mm (16.66 in.)
62 690 05 Rev. E
