FUSES

This engine has 3 blade type automotive fuses.
Replacement fuses must have same rating as blown
fuse. Use fuse chart below to determine correct fuse.
Wire Color
2 Purple Wires
1 Red Wire w/ Black Stripe
1 Red Wire w/ White Stripe
2 Red Wires

Fuse Replacement

1. Shut engine off and remove key.
2. Locate fuse holders.
3. Remove fuse cover and pull out fuse. Inspect
condition of fuse holder.
4. Inspect fuse for a solid fusible link or a broken
fusible link. Replace fuse if fusible link is broken. If
you are not sure if fusible link is broken, replace
fuse.
5. Insert fuse into fuse holder until it is seated properly.
Install fuse cover.
6. If replacement fuse fails, there is a problem within
circuit. Diagnostics are required. Identify which
circuit is aff ected (see EFI System for electrical
schematic) by identifying failed fuse/circuit. Perform
troubleshooting procedures appropriate for circuit
fuse that failed.
7. Install fuse holder into fuse cover.
Troubleshooting Guide
20/25 Amp Battery Charging System
NOTE: Always zero digital volt-ohm meter (DVOM) on
each scale before testing to ensure accurate
readings. Voltage test should be made with
engine running at specifi c test condition noted.
Battery should be checked for state of charge
(non-operating voltage 12.5 VDC or lower,
battery should be charged or replaced).
When problems occur in keeping a battery fully charged
or a battery charges at a high rate, battery or charging
system may be cause of fault. Before performing any
testing, battery must be fully charged.

To test charging system:

1. Visually inspect system components and wiring.
Look for damaged or loose wire connections,
including battery cables.
2. Set DVOM to DC volts, place one lead of tester on
rectifi er-regulator body and other lead to battery
negative (-) terminal. Run engine and observe volt
reading on meter. If voltage is 0.5 VDC or less
continue with testing. If voltage is higher than 0.5
VDC, inspect and repair wiring/connections as
needed (insuffi cient ground).
3. Perform these output tests for charging system using
DVOM set to DC volts.
a. With engine off and key switch in OFF position,
measure voltage at battery. If less than 12.4 VDC,
recharge battery and retest. If 12.5 VDC continue
with tests.
62 690 05 Rev. E
Fuse Rating
30-amp Fuse
10-amp Fuse
10-amp Fuse
KohlerEngines.com
b. Run engine at high speed no load (greater than
3000 RPM). After running 1 minute, measure
voltage at battery.
i. If voltage increases to between 13-15 VDC,
the system is working correctly.
ii. If voltage increases to 15.5 VDC or higher,
system is overcharging. Replace rectifi er-
regulator.
iii. If voltage stays at 12.5 VDC or decreases,
charging system is NOT operating, proceed to
step 4.
4. With engine off , unplug rectifi er-regulator connector
and inspect connector terminals within connector
body and rectifi er-regulator terminals for corrosion/
arching/damage. Repair/replace as needed. If OK,
proceed to next test.
5. Set DVOM to AC volts, place test leads to each
white stator wire. Run engine at 1200 RPM or
greater and monitor voltage.
Condition
Voltage is 13 volts AC or
more.
Voltage is less than 13
volts AC.
6. With engine off and stator unplugged from rectifi er-
regulator, check for resistance/continuity between
across stator leads (white wires).
Condition
Resistance is 0.1/0.2
ohms.
Resistance is 0 ohms.
Resistance is infi nity
ohms/no continuity.
7. With engine off and stator unplugged from rectifi er-
regulator, check for resistance/continuity from stator
leads (white wires) to ground.
Condition
Resistance is infi nity ohms
(no continuity).
Resistance (or continuity)
measured.
8. If stator tests good (steps 4-7), but system was
identifi ed in step 3 as not working, failure is likely
with rectifi er-regulator. Replace rectifi er-regulator,
retest system to confi rm repairs (step 3).
Electrical System
Conclusion
Stator is OK.
Stator is faulty. Continue
with steps 6 and 7).
Conclusion
Stator coil is OK.
Stator is shorted; replace.
Stator is open; replace.
Conclusion
Stator is OK (not shorted
to ground).
Stator leads are shorted to
ground; replace.
83
