AIDS

Description
Camshaft Lubricant (Valspar ZZ613)
Dielectric Grease (GE/Novaguard G661)
Dielectric Grease
Kohler Electric Starter Drive Lubricant (Inertia Drive)
Kohler Electric Starter Drive Lubricant (Solenoid Shift)
RTV Silicone Sealant
Loctite ® 5900 ® Heavy Body in 4 oz. aerosol dispenser.
Only oxime-based, oil resistant RTV sealants, such as those listed, are approved
for use. Permatex ® the Right Stuff
5910 are recommended for best sealing characteristics.
®
Spline Drive Lubricant

FLYWHEEL HOLDING TOOL

A fl ywheel holding tool can be made out of an old junk
fl ywheel ring gear and used in place of a strap wrench.
1. Using an abrasive cut-off wheel, cut out a six tooth
segment of ring gear as shown.
2. Grind off any burrs or sharp edges.
3. Invert segment and place it between ignition bosses
on crankcase so tool teeth engage fl ywheel ring
gear teeth. Bosses will lock tool and fl ywheel in
position for loosening, tightening, or removing with a
puller.
62 690 05 Rev. E
® 1 Minute Gasket™ or Loctite

ROCKER ARM/CRANKSHAFT TOOL

A spanner wrench to lift rocker arms or turn crankshaft
may be made out of an old junk connecting rod.
1. Find a used connecting rod from a 10 HP or larger
2. Remove studs of a Posi-Lock rod or grind off
3. Find a 1 in. long capscrew with correct thread size to
4. Use a fl at washer with correct I.D. to slip on
KohlerEngines.com
® Nos. 5900 ® or
Loctite
Permatex
engine. Remove and discard rod cap.
aligning steps of a Command rod, so joint surface is
fl at.
match threads in connecting rod.
capscrew and approximately 1 in. O.D. Assemble
capscrew and washer to joint surface of rod.
Tools and Aids
Source/Part No.
Kohler 25 357 14-S
Kohler 25 357 11-S
Loctite ® 51360
Kohler 52 357 01-S
Kohler 52 357 02-S
Kohler 25 597 07-S
Loctite 5910
® ®
Loctite ® Ultra Black 598™
Loctite Ultra Blue 587™
®
® Ultra Copper 5920™
the Right Stuff
® ®
Minute Gasket™
Kohler 25 357 12-S
