8 Testing
8.1 Leak Test
DANGER!
Risk of Death, Injury or Damage
To prevent electrical shock
– ALWAYS disconnect concentrator from electrical outlet before servicing.
Product Tank with Regulator Manufactured Before 7/1/2012
Only the VAW model is shown. Leak test for the AW model is performed in the same manner.
Filer, capacitor, and PE valve not shown.
1154245-F-02
Product Tank with Regulator Manufactured After 7/1/2012
Testing
41
