Regency G800EC Owners & Installation Manual

Hide thumbs Also See for G800EC:
Table of Contents

Advertisement

Quick Links

See also: Manual
Grandview
Warning
Fire or Explosion Hazard
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-125a
®
Gas Fireplace
ANSI Z21.88-2017
CSA 2.33-2017
G800EC
Installer: Please complete the details on the back cover and leave
this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: G800EC
Medium DV Gas Fireplace
www.regency-fire.com
10.07.19

Advertisement

Table of Contents
loading

Related Manuals for Regency G800EC

Summary of Contents for Regency G800EC

  • Page 1 Owners & Grandview G800EC ® Installation Manual Gas Fireplace MODEL: G800EC Medium DV Gas Fireplace www.regency-fire.com Warning Fire or Explosion Hazard Failure to follow safety warnings exactly could result in serious injury, death, or property damage. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: On Demand Pilot Light (Seven Day Safety Timer)

    ® you with all the warmth and charm of a wood fireplace at the flick of a switch. The Grandview™ G800EC has been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.
  • Page 3 (U.S.A. only) or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. A conversion kit is supplied with the appliance. Grandview® G800EC Gas Fireplace...
  • Page 4 fireplace damper and any other gas-fired burning appliance to the previous conditions of use. Other considerations: Non-metallic venting systems shall not interchange components with another listed or unlisted metallic venting system. Grandview® G800EC Gas Fireplace...

  • Page 5: Table Of Contents

    Light bulb replacement—Bottom Lights + Top Light ....79 Unit Assembly Prior to Installation .........38 Valve replacement ..............80 Nailing Flange Installation:.............38 IFC replacement ..............81 Wall Board/Drywall Installation G800EC .......40 Main Assembly ..............82 Conversion to top vent ............41 Main Assembly—Parts List ............83 Vent Restrictor Installation .............43 Accessory Parts List ..............84...

  • Page 6: Copy Of Safety Decal

    This is a copy of the label that accompanies each Grandview™ G800EC Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.

  • Page 7: For The State Of Massachusetts Only

    (e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Grandview® G800EC Gas Fireplace...

  • Page 8: Unit Dimensions

    " " 953mm 959mm 34 5 34 3 " " 880mm 883mm Finishing Trim Faceplate ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Grandview® G800EC Gas Fireplace...

  • Page 9: Before You Start

    PRIOR TO OPERATING THE APPLIANCE. SURFACE TEMPERATURES, ESPE- CIALLY THE FIREPLACE GLASS, AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION. IF THE BARRIER BECOMES DAMAGED, THE BARRIER SHALL BE REPLACED WITH THE MANUFACTURER'S BARRIER FOR THIS APPLIANCE. Grandview® G800EC Gas Fireplace...

  • Page 10: Lighting Procedure

    If the unit is being operated in IPI (intermittent pilot) mode, neither the above instructions nor the seven day timer will apply. See the instructions in this manual and on the Lighting Instructions plate on the appliance to light or re-light the pilot. Grandview® G800EC Gas Fireplace...

  • Page 11: Copy Of Lighting Plate Instructions

    If service is to be performed–you must disconnect power and shut off gas to the unit. Appuyer sur la touche ON/OFF de la télécommande ou faites glisser l'interrupteur mural sur la position "OFF". 920-126a Grandview® G800EC Gas Fireplace Part #: 920-126a - Side B...

  • Page 12: Proflame Ii Remote Control Operating Instructions

    (*) The receiver may be independent or integral to the IFC hearth ap- pliance control module. The receiver instruction may not be indepen- dent when part of the IFC. Figure 2: Transmitter LCD Display Grandview® G800EC Gas Fireplace Figure 3: Battery Compartment...
  • Page 13 Transmitter LCD display will only show the room temperature (Fig. 6). At the same time the Receiver will turn off the appliance. A single “beep” from the Receiver confi rms reception of the command. Figure 9 Figure 10 Grandview® G800EC Gas Fireplace 920-155 09.04.19...
  • Page 14 Pressing the Up Arrow Key will activate the light. Pressing the Down will confi rm reception of the command. Arrow Key will turn the light off. A single “beep” will confi rm the recep- tion of the command. Figure 13 Figure 14 Figure 17 Figure 18 Grandview® G800EC Gas Fireplace...

  • Page 15: Key Lock

    3. Reinstall battery removed in Step 1 while holding both buttons—keep holding buttons, then release the MODE button only. 4. The screen will show either "Clr" or "Set" as the fi rst option available is to disable or enable a mode. Grandview® G800EC Gas Fireplace 920-155 09.04.19...

  • Page 16: Installer's Information

    SAVE THESE INSTRUCTIONS 10. Be aware of electrical wiring locations in walls The G800EC Direct Vent Fireplace must be installed and ceilings when cutting holes for termination. in accordance with these instructions. Carefully read 11. Under no circumstances should this appliance all the instructions in this manual first.

  • Page 17: Installation Checklist

    1. Locate appliance for natural gas and propane), after burning Room location (Refer to "Locating Your appliance for 15 minutes. 5. The G800EC Gas Fireplace are approved for Gas fireplace" section) alcove installations, see "Clearances" section Clearances to Combustibles (Refer to 2.

  • Page 18: Clearance / Framing And Venting Configurations

    Clearance / Framing and Venting Configurations The G800EC is designed to allow for unique installation options—depending on the desired finish. Please review the options and follow the specific clearance, framing, and finishing options for that application. The applications are as follows: Cool Wall application: combustible materials can be installed right up to the fireplace opening with this option.

  • Page 19: Cool Wall Installation Part 1: Cool Wall Conversion

    • Combustible material can be used all around the fireplace • Combustible framing Clean Front Outside Finish w/ Finishing Trim Clean Front Standard Install (Non-Combustible Finishing) Standard Install: • Non-vented chase • Non-combustible board required • Combustible framing Outside Finish w/ Faceplate Clean Front Grandview® G800EC Gas Fireplace...

  • Page 20: Cool Wall Clearances

    5 . Bend the rear three (3) tabs up 90° towards the back of the unit. 3. Slide out tab as shown to remove—recycle part. 6. Flip top panel 180° and reinstall to top of unit with four(4) screws in loca- tions shown below. Grandview® G800EC Gas Fireplace...

  • Page 21: Cool Wall Mantel Clearances

    The metal ends of the standoff may NOT be greatest importance that this fireplace and vent system be installed only in accordance recessed into combustible construction. with these instructions. G800EC Clearance Requirements—Cool Wall Installations Clearance: Cool Wall - Clean Front Measured From: **0"...

  • Page 22: Cool Wall Mantel Leg Clearances

    Note: If Faceplate or Finishing Trim is being installed, leave 3 3/8" clearance from from top of fireplace opening for installation and removal. Cool Wall Mantel Leg Clearances TopView 2" (51mm) 3" (76mm) Side opening of fireplace 1-3/4" (44mm) 32-1/2" (826mm) overall fireplace width Allowable mantel leg projection See framing dimensions on next page. Grandview® G800EC Gas Fireplace...

  • Page 23: Cool Wall Application-Framing

    * Important: Framing height requires consideration of the hearth depth. Dimension N = N + the thickness of the installed hearth. Combustible header Top Vent Rear Vent Corner=Top Vent Only IMPORTANT: Corner applications are vented from the top only - rear venting cannot be used. Grandview® G800EC Gas Fireplace...

  • Page 24: Chase Vent Installation

    This can be achieved in a number of ways including a reveal at the top of the chase. Side View Ceiling Ceiling Top of chase enclosure Grandview® G800EC Gas Fireplace 920-150 09.04.19...

  • Page 25: Clean Front Installation-Clearances

    F: Alcove Depth 36" (914mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Minimum Vent Clearances to Combustibles Horizontal Top 2" (51mm) Horizontal Side 1-1/2 " (38mm) Horizontal Bottom 1-1/2" (38mm) Vertical Vent 1-1/2" (38mm) Alcove Grandview® G800EC Gas Fireplace...

  • Page 26: Clean Front Installation Mantel Clearances

    Mantel Clearances Combustible 19" 12" 7" Non-Combustible Material Min.11-1/2"H (292mm) Material Min. 2"D (51mm) Inches Top of Fireplace Opening To Floor Mantel Clearances G800EC From Top of Fireplace 32-1/2" 20-1/2" 15-1/4" 11-1/2" Opening (826mm) (597mm) (470mm) (292mm) Grandview® G800EC Gas Fireplace...

  • Page 27: Clean Front Installation-Mantel Leg Clearances

    Clean Front Installation (non-Cool Wall)—Non-Combustible Requirements: 37-1/2" [953mm] 11-1/2" [292mm] No Combustible Materials in this Area NO FACING OR 30-7/8" FINISHING MATERIAL [784mm] IN THIS AREA 1-5/8" (41mm) 32-3/4" 832mm 3" 3" [76mm] [76mm] See framing dimensions on next page. Grandview® G800EC Gas Fireplace...

  • Page 28: Clean Front Installation-Framing (Non Cool Wall)

    Clean Front Installation—Framing (non Cool Wall) Framing Dimensions Description G800EC - Non Cool Wall Framing Width 37-1/2"(953mm) Framing Height 43" (1092mm) O (Top Vent) Framing Depth - Top Vent 19-1/4" (489mm) P (Rear Vent) Corner Facing Wall Width 61-1/4" (1556mm)

  • Page 29: Clean Front Finishing

    Tighten screws down. Slide the Bottom Tiling Flange against the bottom of the fireplace. Secure with a screw on each side. Finishing material can now be pressed against the flat edge created by the Clean Front Trim. Grandview® G800EC Gas Fireplace...

  • Page 30: Outside Finish Installation-Clearances

    The metal ends of the standoff may NOT be adhered to. It is of greatest importance that this fireplace and vent recessed into combustible construction. system be installed only in accordance with these instructions. G800EC Outside Finish Clearance Requirements Clearance: Dimension Measured From: A: Mantel Height (min.)

  • Page 31: Outside Finish Installation-Mantel Clearances

    **The non combustible board supplied with the appliance is 11 1/2" (292 mm) high. This may be cut to size if desired. Outside Finish Installation (non-Cool Wall)—Mantel Leg Clearances TopView (38mm) 1-1/2" Side opening 4-1/4" 3" of fireplace (108mm) (76mm) 32-1/2" (826mm) Overall Fireplace width 6-7/8" (175mm) Allowable mantel leg projection Grandview® G800EC Gas Fireplace...

  • Page 32: Outside Finish Installation-Clearances

    * Important: Framing height requires consideration of the hearth depth. Dimension N = N + the thickness of the installed hearth. Combustible header Top Vent Rear Vent Corner=Top Vent Only IMPORTANT: Corner applications are vented from the top only - rear venting cannot be used. Grandview® G800EC Gas Fireplace...

  • Page 33: Outside Finish-Finishing

    Outside Finish—Finishing Finishing Material may be brought to the top and side edges of the fireplace. Finishing material can protrude past the front face of the fireplace. Grandview® G800EC Gas Fireplace...

  • Page 34: Outside Finish-Faceplate Install

    fl ange These tabs are used to stop fi nishing material from interfering with the faceplate mounts. Mounting Tabs Top and Side Nailing Flange Tabs Grandview® G800EC Gas Fireplace 920-152 08.28.19...
  • Page 35 Adjust left and right to center the Face Plate. NOTE: Do not to touch the Face Plate without clean, soft, gloves. Dirt or oils can be transferred onto the finish and become permanent. Grandview® G800EC Gas Fireplace Critical Finishing Gap...

  • Page 36: Outside Finish-Finishing Trim Install

    2. Bend the two tabs on the top nailing fl ange down. 3. Bend the tabs on the left and right nailing fl anges forward. There are two tabs per nailing fl ange. Top and Side Nailing Flange Tabs Top and Side Nailing Flange Tabs 920-151 08.28.19 Grandview® G800EC Gas Fireplace...
  • Page 37 Adjust left and right to center the fi nishing trim. Top Nailing Flange Tabs folded down Side View Nailing Flange Tabs folded forward Mounting Tabs folded forward Top View " Mounting Tab Folded forward Nailing Flange folded forward Finishing Trim Grandview® G800EC Gas Fireplace 920-151 08.28.19...

  • Page 38: Unit Assembly Prior To Installation

    2. Once the setting has been chosen, install the Left and Right Nail- ing Flanges with 2 screws on each Top Nailing Flange Flange. Nailing Flange Parts Finishing Material Depth Flush 11/4” 3/4” 1/4” Setting 1” 1/2” Front of Fireplace Grandview® G800EC Gas Fireplace...

  • Page 39: Nailing Flange Installation

    Standoff Deflector CLEAN FRONT OUTSIDE FINISH *Distance to combustible material varies with install* Backing Material (Drywall etc.) Finishing Material Backing Material (Drywall etc.) Finishing Material Total Material Maximum Depth: 1 1/4” Flush Finishing Material Grandview® G800EC Gas Fireplace...

  • Page 40: Wall Board/Drywall Installation G800Ec

    Wall board materials 1/2 in. thick are specified in this installation manual to properly align with the optional finishing methods offered with this appliance. The G800EC may be finished to the appliance opening with 1/2 inch thick drywall. • Ensure that the back and side clearances are maintained.

  • Page 41: Conversion To Top Vent

    See Diagram 3. Diagram 4 - Top of Unit 5. Remove the insulation from the top of the unit as shown and discard. Diagram 2 - Back of Unit Diagram 5 Grandview® G800EC Gas Fireplace...
  • Page 42 8. Install the inner cover plate removed from the top in Step 7—to the back of the unit. Slide the plate onto the two (2) loosened screws and tighten all six (6) screws. 12. Reinstall vent cover plate (removed in Step 1) with six (6) screws. Diagram 7 Grandview® G800EC Gas Fireplace...

  • Page 43: Vent Restrictor Installation

    Fully Open Diagram 2: Vent restrictor located on top exhaust assembly Venting Introduction The G800EC uses the "balanced flue" technology Co-Axial system. The Set 1 inner liner vents products of combustion to the outside while the outer liner 2" Open...

  • Page 44: Exterior Vent Termination Requirements

    * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Grandview® G800EC Gas Fireplace...

  • Page 45: 4" X 6-5/8" Rigid Pipe

    Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved.
  • Page 46 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Olympia Ventis DV: www.olympiachimney.com Grandview® G800EC Gas Fireplace...

  • Page 47: Venting Arrangements For Horizontal Terminations

    Flex Vent or rigid pipe 4" x 6-5/8" The Diagrams show all allowable combinations of vent runs with 4" x 6-5/8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes.

  • Page 48: Rigid Pipe Venting Systems Horizontal Or Vertical Terminations

    Metal Products, Olympia Ventis DV, Security Secure Vent , AmeriVent Direct Vent. AstroCap is the proprietary trademark of FPI Fireplace Products ® International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Grandview® G800EC Gas Fireplace...

  • Page 49: Venting Arrangements - Horizontal Termination

    #:946-513 (2 foot), 946-515 (4 foot) • Horizontal vent must be supported every 3 feet. and 946-516 (10 foot) are only ap- • Firestops are required at each floor level and whenever passing through a wall. proved for horizontal terminations. Grandview® G800EC Gas Fireplace...

  • Page 50: Venting Arrangements Vertical Termination

    Vent must be supported at offsets. • Firestops are required at each floor level and whenever passing through a wall. • Maintain clearances to combustibles. Note: Must use optional rigid pipe adaptor when using rigid vent systems (Part # 510-994). Grandview® G800EC Gas Fireplace...

  • Page 51: Horizontal Terminations Two (2) 90°Elbows

    4' Max. 10' Min. 7' Max. 6' Min. 5' Max. 11' Min. 8' Max. 7' Min. 6' Max. 12' Min. 9' Max. No Vent Restrictor Installed *Required when using rigid venting Lengths do not include elbow indicated. Grandview® G800EC Gas Fireplace...

  • Page 52: Vertical Venting With Two (2) 90

    7' Min. foot between 90 elbows is required. 5' Min. 6' Max. 8' Min. 6' Min. 7' Max. 9' Min. 7' Min. 8' Max. 10' Min. Lengths do not include elbow indicated. *Required when using rigid venting Grandview® G800EC Gas Fireplace...

  • Page 53: Vertical Terminations

    6' Max. 8' Min. between 90 elbows is 6' Min. 7' Max. 9' Min. required. 7' Min. 8' Max. 10' Min. No Vent Restrictor Installed *Required when using rigid venting Lengths do not include elbow indicated. Grandview® G800EC Gas Fireplace...

  • Page 54: Venting Arrangements With Co-Linear Flex System

    Pipe Length See detailed venting arrangements, Co-Linear vertical terminations, co-linear flex system Flex into masonry fireplaces in this manual. Adapter with Kit# 946-563 Rigid Pipe Adapter 90 Degree # 510-994 Elbow Inner Pipe Adapter with Kit# 946-563 Grandview® G800EC Gas Fireplace...

  • Page 55: Venting Arrangement - Vertical Terminations Co-Linear Flex System Into Masonry Fireplaces

    Co-linear Flex System Into Masonry Fireplaces FOR BOTH RESIDENTIAL & MANUFACTURED HOMES IMPORTANT: As shown below, the unit can only be vented from the top, not from the rear. Horizontal Distance (Feet) Horizontal Distance (Feet) Horizontal Distance (Feet) Grandview® G800EC Gas Fireplace...

  • Page 56: Unit Installation With Horizontal Termination

    “Mill- Pac” sealant (supplied) to every inner pipe connection. Failure to do so may result in drafting or performance issues not covered under warranty. Diagram 2 Grandview® G800EC Gas Fireplace...

  • Page 57: Unit Installation With Vertical Termination

    10" murale square and attach over 16/12 to 18/12 2.13 Attache with wood screws Diagram 3 murale over 18/12 to 20/12 2.29 walstrpf.eps (Diagram 7). Diagram 7 Coudes de 45 over 20/12 to 21/12 2.44 french Grandview® G800EC Gas Fireplace...

  • Page 58: Direct Vent System (Flex) Installation Procedures

    We recommend fram- ing a 10"(254mm) x 10"(254mm) Wall Thimble Screws (inside dimensions) hole to give 2 pieces (3 per connection) (10" Outer structural rigidity for mounting Diameter) the termination. Grandview® G800EC Gas Fireplace...

  • Page 59: Vertical Termination 4' X 6-7/8' Venting - Vertical Flex Vent Kit (946-755)

    10. Attach the rigid pipe section to the adaptor by using Mill-Pac on the inner/ Note: Any closets or storage spaces which the vent passes through must outer pipe. Use 3 screws to secure outer pipe. be enclosed. 919-695 08.10.16 Grandview® G800EC Gas Fireplace...

  • Page 60: Vertical Flue Extension Kit (Part #946-756)

    Note: The ceiling firestop/firestop spacer may be cut down to size if this shield Flashing Ceiling firestop is too high for the application. Firestop spacer to prevent debris from falling into the ceiling Diagram 1 Roof support firestop Ceiling firestop Enclosure Ceiling firestop Diagram 1a Grandview® G800EC Gas Fireplace 919-696 08.10.16 919-698 06.12.18...

  • Page 61: Pilot Adjustment

    Ignitor Pilot ports on the valve. G800EC - LP System Data Note: If you have an incorrect flame 1. Make sure the valve is in the "OFF" position. pattern, contact your Regency ®...

  • Page 62: Conversion From Ng To Lp

    Conversion from NG to LP G800EC for G800EC using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Each Kit contains one LP Conversion Kit 7.

  • Page 63: Panel Installation

    fireplace when installing. NOTE: Shorter row of bricks should be positioned at the bottom om both back and side panels. 10. Reinstall upper baffle. Grandview® G800EC Gas Fireplace 920-128 08.29.19 920-149 09.17.19...

  • Page 64: Log Set Installation

    2. Install the log grate—secure with 2 screws in locations show below. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The G800EC log set (#761-930/761-932) contains the following pieces Rear Log...
  • Page 65 Final position of the log should be pulled forward and to the right while contacting the end and curved parts of the burner. Diagram 7—Log 1 installation Grandview® G800EC Gas Fireplace 920-127 Page 2 of 4 06.17.19...
  • Page 66 Log 6—the opposite end of Log 6 will rest the 2nd prong from the right on the log grate. in the notch in Log 4. Diagram 16—Install Log 9 Diagram 13—Install Log 6 Grandview® G800EC Gas Fireplace 920-127 Page 3 of 4 06.17.19...
  • Page 67 17. Test fi re to ensure proper light off (make sure fl ame fl ows smoothly). If there is any fl ame hesitation, check that area for any blockage of the burner ports. Diagram 18—Install Log 11 Diagram 20—Final Installation Grandview® G800EC Gas Fireplace 920-127 Page 4 of 4 06.17.19...

  • Page 68: Wall Mount On / Off Switch Battery Holder

    11. Using the two (2) screws provided secure the cover plate to the Battery Holder. 12. For coding instructions, see full details in this manual. Proflame Battery Holder J-Box Battery Holder Slider Switch Wall Plate Diagram 1 Grandview® G800EC Gas Fireplace...

  • Page 69: Aeration Adjustment

    Screw the receptacle cover to gang box. Reinstall panel by removing three (3) screws. The 120 volt power cord supplied with appliance will need to be plugged into the receptacle only once the install is complete. Grandview® G800EC Gas Fireplace...

  • Page 70: Wiring Diagram Without Thermostat

    The fan will not operation after servicing, grounded three-prong recep- operate during a power outage. tacle. Do not cut or remove the grounding prong from this plug. TOP LIGHT WHITE BLACK BLACK YELLOW YELLOW BOTTOM LIGHTS Grandview® G800EC Gas Fireplace...

  • Page 71: Optional Wall Thermostat

    5 degrees above the set point on the wall thermostat. The burner will fire until the set point on the wall thermostat is satisfied. The remote will remain connected and allow full control of all accessories. Grandview® G800EC Gas Fireplace...

  • Page 72: Installing The Optional Fan

    7. Secure fan access panel back onto the unit with 4 screws (locations shown below). Diagram 3- fan wires 06.24 920-133 5. Connect fan ground cable to ground lug (located in lower right corner of unit). Refer to wiring diagram. Grandview® G800EC Gas Fireplace...
  • Page 73 10. Loosen 2 screws off from the IFC box and set aside. Diagram 8 11. Lift out panel with light assembly and set aside, be careful of light assembly wiring. Diagram 9 920-133 06.24.19 Grandview® G800EC Gas Fireplace...

  • Page 74: Safety Screen Removal / Installation

    3. Lift the door up and out of lower slots to remove. 4. Swing screen outwards while keeping the screen level and remove. Safety screen Installation Glass door Installation 1. To install the safety screen—Reverse steps above. 1. To install the door—Reverse steps above. Grandview® G800EC Gas Fireplace...

  • Page 75: Operating Instructions

    The glass should be cleaned after the unit has cooled down or the film will bake on and become very difficult to remove. Use a non-abrasive cleaner and DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS HOT. Grandview® G800EC Gas Fireplace...

  • Page 76: Battery Backup

    3. Install 4 AA batteries ensuring the polarity is correct. See Diagram 4. 4. Reverse steps 3-1. Battery compartment door Diagram 2 2. Press down on both tabs to remove battery compartment door. See diagrams 2 and 3. Grandview® G800EC Gas Fireplace...

  • Page 77: Copy Of Lighting Plate Instructions

    If service is to be performed–you must disconnect power and shut off gas to the unit. Appuyer sur la touche ON/OFF de la télécommande ou faites glisser l'interrupteur mural sur la position "OFF". 920-126a Grandview® G800EC Gas Fireplace Part #: 920-126a - Side B...

  • Page 78: Maintenance Instructions

    For relighting, refer to lighting instructions. Keep corrosion of caps, pipe, and fittings. It may Regency dealer only. Replacement glass (Part the burner and control compartment clean by be caused by having excessive lateral runs, #940-506/P) is shipped already installed into the brushing and vacuuming at least once a year.

  • Page 79: Light Bulb Replacement-Bottom Lights + Top Light

    8. Reverse steps to re-install. NOTE: Be careful not to pinch the wiring when re-installing the Top Light Casing. There is a cut-out for the wiring to route through. 5. Reverse steps to reassemble unit. Grandview® G800EC Gas Fireplace...

  • Page 80: Valve Replacement

    (Diagram 6) and then lift out entire assembly. Diagram 2: Slide burner assembly to the right—then remove. 8. Remove 2 screws securing the light assembly (Diagram 3) and rotate the assembly counter- Diagram 6 clockwise (Diagram 4). Diagram 3 Grandview® G800EC Gas Fireplace...

  • Page 81: Ifc Replacement

    Plate to the IFC Mount. Then remove the Cover Plate. 5. Loosen the two Phillips-head screws as shown. They do not need to be removed. 10. The IFC can now be slid out from under the fire- box. Grandview® G800EC Gas Fireplace...

  • Page 82: Main Assembly

    Main Assembly Grandview® G800EC Gas Fireplace...

  • Page 83: Main Assembly-Parts List

    761-574/P Valve Assembly - NG Paart Description 761-576/P Valve Assembly - LP 918-835 Decal Logo Regency / Flame Sit Remote 911-188 Valve NG 885 SIT IPI 0.885.009 918-876 Decal Remote Quick Reference GTMF 911-085 Valve LP 885 SIT IPI 0.885.002...

  • Page 84: Accessory Parts List

    Deflector Header 761-050 Front Cover Access Panel 761-110 Gasket Fan Access Tray 761-122 Gasket Light Wire 761-123 Board Calcium Silicate 36"X 11-1/2" 761-129 Gasket Top Light G800 761-088 Insulation Rear Enamel/Steel Panel 911-290/P Fan motor Only Grandview® G800EC Gas Fireplace...

  • Page 85: Warranty

    FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. Revision Date: February 2019 Regency Gas Products Warranty Grandview® G800EC Gas Fireplace...
  • Page 86 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Grandview® G800EC Gas Fireplace Revision Date: February 2019 Regency Gas Products Warranty...
  • Page 87 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 88 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
