© FPI Fireplace Products International Ltd.
G51 SUREFIRE
ZERO CLEARANCE KIT
KIT # 390-900
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Refer to this manual. For assistance
or additional information consult an
authorized installer, service agency
or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in
the vicinity of this or any other
appliance.
Installation and service must be
performed by an authorized installer,
service agency or the gas supplier.
Fireplace Products International Ltd.
6988 Venture St., Delta, B.C.
Canada, V4G 1H4
Masport Head Office - Australia
54 Boundary Rd. Braeside
P.O. Box 553
Mordialloc 3195
Ph. (03) 9586-7777
Fax. (03) 9586-2980
918-238
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any
appliance
Do
not
touch
electrical switch: do not
use any phone in your
building.
Immediately call your
gas supplier from a
neighbour's
Follow the gas supplier's
instructions.
If you cannot reach your
gas supplier, call the fire
department.
Australian Heating Distributors
10/46 James St.,
Guildford, Western Australia 6055
Masport Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Ph. (9) 570-9009
Fax. (9) 527-1294
any
phone.
11/06/03
Advertisement
Table of Contents
Related Manuals for Regency G51
Summary of Contents for Regency G51
-
Page 1: Zero Clearance Kit
G51 SUREFIRE ZERO CLEARANCE KIT KIT # 390-900 Owners & Installation PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY What to do if you smell gas: Improper installation, adjustment, alteration, service or maintenance Do not try to light any can cause injury or property damage. -
