Draytek Vigor2862 Series User Manual page 73

3G/4G USB Modem
(DHCP mode)
3. Then, click Next for viewing summary of such connection.
4. Click Finish. A page of Quick Start Wizard Setup OK!!! will appear. Then, the system
status of this protocol will be shown.
5. Now, you can enjoy surfing on the Internet.
Vigor2862 Series User's Guide
the string you can set is 47 characters.
APN Name – APN means Access Point Name which is provided
and required by some ISPs. Type the name and click Apply.
SIM Pin code – Type PIN code of the SIM card that will be
used to access Internet.
Network Mode – Force Vigor router to connect Internet with
the mode specified here. If you choose 4G/3G/2G as network
mode, the router will choose a suitable one according to the
actual wireless signal automatically.
APN Name – APN means Access Point Name which is provided
and required by some ISPs.
57
