Communication
2.2 PROFINET communication
Figure 2-29
Configuration of OPC UA Send in SIMOCODE ES
OPC UA Send - Bit 0.0: "Status ON<"
OPC UA Send - Bit 0.1: "Status Off"
OPC UA Send - Bit 0.2: "Status ON>"
...
OPC UA Send - Bit 0.3: "Not connected"
OPC UA Send - Bit 1.7: "Not connected"
Note
Restarting the communication interface
Each change to the configuration of the OPC UA send data requires that the communication
interface be restarted.
A new start of the communication interface interrupts all Ethernet and PROFINET links and
reestablishes them afterward.
90
Representation in the object directory of the SIMOCODE pro V PN-OPC UA server
(see also table below)
Representation in the object directory of the
SIMOCODE pro V PN-OPC UA server
Acyclic Send → Status - On <
Acyclic Send → Status - Off
Acyclic Send → Status - On >
...
Acyclic Send → Not connected
Acyclic Send → Status - On <
