Tables, data records
3.3 Tables, PROFIBUS data records
Byte.Bit Status message
3.7
4.0 Trips - level monitoring
4.1
4.2
4.3
4.4
4.5
4.6
4.7
5.0
5.1
5.4
5.5
6.0 Faults - Miscellaneous
6.1
6.2
6.3
6.4
6.5
6.6
6.7
7.0
7.1
7.2
7.3
7.4
8.0 Warnings - Protection
8.1
8.2
8.3
8.4
8.5
8.6
8.7
9.0
9.1
9.2
9.3
9.4
9.5
9.6
154
Fault - EM+ short-circuit
Fault - trip I>
Fault - trip I<
Fault - trip P>
Fault - trip P<
Fault - trip cos phi<
Fault - trip U<
Fault - trip 0/4 - 20 mA>
Fault - trip 0/4 - 20 mA<
Fault - stalled rotor
Reserved
Fault - number of starts >
Reserved
Fault - external fault 1
Fault - external fault 2
Fault - external fault 3
Fault - external fault 4
Fault - external fault 5
Fault - external fault 6
Reserved
Reserved
Fault - analog module open circuit
Fault - test trip
DM-F safety-related tripping
Fault - DM-F wiring
Fault - DM-FL cross circuit
Warning - Overload operation
Warning - Unbalance
Warning - Overload
Warning - Overload + phase failure
Warning - internal ground fault
Warning - external ground fault
Reserved
Warning - Thermistor overload
Warning - Thermistor short circuit
Warning - Thermistor open circuit
Warning - TM warning T>
Reserved
Warning - TM sensor fault
Warning - TM out of range
Reserved
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Information
MM EM+
IM UM
IM UM
UM
UM
UM
UM
AM
AM
IM UM
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU0 BU1 BU2(+)
BU2(+)
BU2(+)
AM
BU0 BU1 BU2(+)
DM-FL DM-FP
DM-FL DM-FP
DM-FL
IM UM
IM UM
IM UM
IM UM
IM UM
EM MM
Th
Th
Th
TM MM
TM MM
TM MM
