Data record 224 - Password protection

Description
● Password protection ON
If the data record is received with this control flag, the password protection is activated
and the password applied. If "Password protection on" applies and the password is not
identical at the time of receipt, the event "Event - Wrong password" is set and no change
will be made.
● Password protection OFF
If the data record is received with this control flag, the password protection is deactivated.
If the password is incorrect, the event "Event - Wrong password" is set and no change is
made.
Table 3- 44 Data record 224 - Password protection
Byte.Bit Designation
0.0 Reserved
4.0 Control flag:
0 = Password protection off, 1 = Password protection on
4.1 Reserved
8.0 Password
16.0 Reserved
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Tables, data records
3.3 Tables, PROFIBUS data records
Type Information
Byte[4]
BU0 BU1 BU2(+)
Bit
Bit[31]
Byte[8] BU0 BU1 BU2(+)
Byte[8]
201
